- Page 1 Range Name: Willow Box 1 dimensions: W101xD47xH10.5(cm) Product Dimension: W90xD35xH49(cm) Willow Shoe Storage Bench Up to 30 minutes Two person assembly time assembly This product is intended for domestic use only, not for commercial purposes. P-1/12 V-2.0...
- Page 2 IMPORTANT ASSEMBLY TIP Before you begin, it's best to identify all of the parts and fittings to build your shoe storage bench frame. We advise laying these out on the floor to check you have everything, and to familiarise yourself with all of the parts and fittings before building. TOP TIP We recommend that you assemble the shoe storage bench in the room you'd like it to be located.
- Page 3 Parts list P-3/12...
- Page 4 Parts list Before you begin building your Willow Shoe Storage Bench, please take a moment to read through the instructions and make sure that you have all the relevant parts listed on the parts check list. Part Description Quantity Part Number...
- Page 5 1. Attach the Leg Supports to the Bottom Panel. Allen Key M6*30mm Bolt 4pcs 2. Attach the Leg Supports to the Legs. Allen Key M6*40mm Bolt 8pcs P-5/12...
- Page 6 3. Attach the Right Side Panel onto the Frame. Allen Key M7*48mm Screw 2pcs 4. Attach the Left Side Panel onto the Frame. Ø8*30mm Dowel 2pcs Allen Key M7*48mm Screw P-6/12 2pcs...
- Page 7 5. Attach the Shelf Panel to the Left Side Panel and attach the Stickers. Ø8*30mm Dowel 2pcs Allen Key M7*48mm Screw Ø20mm Sticker 2pcs 2pcs 6. Attach the Bolts to the Shelf Panel. Allen Key M6*30mm Bolt P-7/12 2pcs...
- Page 8 7. Assemble the Back Panel into the Frame. 8. Attach the Bolts to the Top. M6*35mm Bolt P-8/12 4pcs...
- Page 9 9. Attach the Top onto the Frame. Ø8*30mm Dowel 4pcs Allen Key M6*30mm Bolt 4pcs 10. Tighten the Bolts and Cam Locks fully and attach the Stickers. A&B&C 100% Ø15*12mm Cam Lock Ø20mm Sticker P-9/12 4pcs 4pcs...
- Page 10 11. Attach the Plastic Buckles. Plastic Buckle M3.5*14mm Screw 4pcs 4pcs 12. Attach the Hinges to the Door. Hinge M3.5*14mm Screw P-10/12 4pcs 2pcs...
- Page 11 13. Assemble the Handle. Handle M4*20mm Bolt 14. Attach the Door to the Right Side Panel. M3.5*14mm Screw P-11/12 8pcs...
- Page 12 15. Adjust the Door. P-12/12...
