DUSK.COM
LIVING I BEDROOM I DINING
Up to 60 minutes
assembly time
This product is intended for domestic use only,not for commercial purposes.
illow
ardrobe
Two person
assembly
Range Name :
illow
Box 1 dimensions : 177x66x19cm
Box 2 dimensions : 148x66x13cm
P-1-31
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for DUSK Willow WIL-WOO-3D2DWAR
Summary of Contents for DUSK Willow WIL-WOO-3D2DWAR
- Page 1 DUSK.COM Range Name : illow Box 1 dimensions : 177x66x19cm LIVING I BEDROOM I DINING Box 2 dimensions : 148x66x13cm illow ardrobe Two person Up to 60 minutes assembly assembly time This product is intended for domestic use only,not for commercial purposes.
- Page 2 IMPORTANT ASSEMBLY TIP Before you begin, it's best to identify all of the parts and fittings to build your Willow Wardrobe frame. We advise laying these out on the floor to check you have everything, and to familiarise yourself with all of the parts and fittings before building. TOP TIP We recommend that you assemble the Willow Wardrobe in the room you'd like it to be located.
- Page 3 Parts list Before you begin building your Willow Wardrobe, please take a moment to read through the instructions and make surethat you have all the relevant parts listed on the parts check list. Part Number Part Description Part Number Part Description Quantity Quantity Left Side Panel...
- Page 4 Fittings Please check you have all the fittings listed below with your product. M6*35mm Bolt Ø15x9.5mm Cam Lock Ø8x30mm Dowel M3.5*12mm Screw M3*14mm Screw 38pcs+2pcs extra 38pcs+2pcs extra 26pcs+2pcs extra 28pcs+2pcs extra 14pcs+1pc extra M4*20mm Screw 15x9mm Plastic Buckle Handle M4*35mm Screw M5*40mm Screw 10pcs+1pc extra...
-
Page 5: Parts List
Parts list P-5-31... - Page 6 Slides Must Be Separated Before Assembly. After Separated, Set Aside Until Needed for Assembly. Pay attention when connecting ! The sliding module must be at the front end. STEP 1 : Extend Slide Mount Lever STEP 2: Push Lever UP Push lever for the left of drawer , press the lever for the right of drawer .
- Page 7 1. Attach parts to the boards. D x 12 X x 4 A x 10 Orbit M6*35mm Bolt M3.5*12mm Screw 10pcs 12pcs 4pcs P-7-31...
- Page 8 2. Attach parts to the boards. A x 18 M6*35mm Bolt 18pcs P-8-31...
- Page 9 3. Attach parts to the boards. G x 3 M x 2 3mm Allen Key Ø8x50mm Dowel M5*40mm Screw 2pcs 3pcs P-9-31...
- Page 10 4. Attach parts to the boards. B x 8 O x 4 Ø15x9.5mm Cam Lock Cover Ø8x30mm Dowel Ø8x50mm Dowel 8pcs 5pcs 3pcs 4pcs P-10-31...
- Page 11 5. Attach parts to the boards. B x 8 O x 4 C x 5 Ø15x9.5mm Cam Lock Cover Ø8x30mm Dowel 8pcs 5pcs 4pcs P-11-31...
- Page 12 6. Attach parts to the boards. C x 8 Ø8x30mm Dowel 8pcs P-12-31...
- Page 13 7. Assemble the top to the frame. O x 9 B x 10 Ø15x9.5mm Cam Lock Cover 10pcs 9pcs P-13-31...
- Page 14 8. Attach parts to the boards. B x 2 Ø15x9.5mm Cam Lock 2pcs P-14-31...
- Page 15 9. Assemble boards to the frame. P-15-31...
- Page 16 10. Attach parts to the boards. C x 6 Ø8x30mm Dowel 6pcs P-16-31...
- Page 17 11. Assemble boards to the frame. G x 9 3mm Allen Key M5*40mm Screw 9pcs P-17-31...
- Page 18 12. Assemble the leg. V x 4 4mm Allen Key M6*35mm Screw 4pcs P-18-31...
- Page 19 13. Assemble leg to the frame. U x 12 M6*30mm Screw 12pcs P-19-31...
- Page 20 14. Adjust the middle support leg. K x 4 M4*14mm Screw 4pcs P-20-31...
- Page 21 15. Assemble parts to the frame. Q x 4 D x 8 M3.5*12mm Screw Clothes Tray 8pcs 4pcs P-21-31...
- Page 22 16. Attach parts to the boards. S x 6 T x 3 M4*14mm Screw Hinge Handle M4*20mm Screw 18pcs 9pcs 3pcs 3pcs P-22-31...
- Page 23 17. Assemble doors to the frame. S x 36 M4*14mm Screw 36pcs P-23-31...
- Page 24 18. Attach parts to the boards. A x 10 H x 2 J x 2 Handle M6*35mm Bolt M4*20mm Screw 10pcs 2pcs 2pcs 19. Attach parts to the boards. F x 8 Ø15x9.5mm Cam Lock M4*35mm Screw Ø8x30mm Dowel 8pcs P-24-31...
- Page 25 20. Assemble the drawers. 21. Assemble the drawers O x 8 B x 9 Ø15x9.5mm Cam Lock Cover Ø8x30mm Dowel 9pcs 8pcs P-25-31...
- Page 26 22. Attach parts to the boards. D x 8 Y x 4 Orbit M3.5*12mm Screw 8pcs 4pcs P-26-31...
- Page 27 23. Assemble drawers to the frame. P-27-31...
- Page 28 24. Attach the plastic buckle to the frame. I x 14 E x 14 15x9mm Plastic Buckle M3*14mm Screw 14pcs 14pcs P-28-31...
- Page 29 25. Attach parts to the frame. R x 18 M3*14mm Screw 18pcs P-29-31...
- Page 30 26. Adjust the legs. P-30-31...
- Page 31 27. Fix the L-shape Bracket to the wall. Ø6x30mm Wall Plug Wall Bracket M4*35mm Screw M4*14mm Screw 2pcs 2pcs 2pcs 2pcs P-31-31...
