- Page 1 DN:KD-5920BT-SMSY01 V1.0 Operation Guide Operation Guide (V1.0) Product/project name： Blood Pressure Monitor Model name KD-5920BT ： Drafted Date Reviewed by: Date Approved by: Date...
-
Page 2: Table Of Contents
DN:KD-5920BT-SMSY01 V1.0 Operation Guide MODEL KD-5920BT Wireless Blood Pressure Monitor (ELECTRONIC SPHYGMOMANOMETER) OPERATION GUIDE __________________________________________________________________________ INDEX IMPORTANT INFORMATION ................. 2 CONTENTS AND DISPLAY INDICATORS .............2 INTENDED USE ....................3 PACKAGE CONTENTS .................. 3 CONTRAINDICATION ..................3 PRODUCT DESCRIPTION ................3 SPECIFICATIONS ................... 4 NOTICE ...................... -
Page 3: Important Information
DN:KD-5920BT-SMSY01 V1.0 Operation Guide IMPORTANT INFORMATION NORMAL BLOOD PRESSURE FLUCTUATION All physical activity, excitement, stress, eating, drinking, smoking, body posture and many other activities or factors (including taking a blood pressure measurement) will influence blood pressure value. Because of this, it is mostly unusual to obtain identical multiple blood pressure readings. -
Page 4: Intended Use
DN:KD-5920BT-SMSY01 V1.0 Operation Guide INTENDED USE Fully Automatic Electronic Sphygmomanometer is for use by medical professionals or at home and is a non-invasive blood pressure measurement system intended to measure the diastolic and systolic blood pressures and pulse rate of an adult individual by using a non-invasive technique in which an inflatable cuff is wrapped around the upper arm. -
Page 5: Specifications
DN:KD-5920BT-SMSY01 V1.0 Operation Guide SPECIFICATIONS 1. Product name:Wireless Blood Pressure Monitor 2. Model: KD-5920BT 3. Classification: Internally powered, Type BF applied part,IP21,No AP or APG,Continuous operation 4. Machine size: Approx.150mm×95mm×41mm( 5 29/32″x 3 3/4″x 1 5/8″) 5. Cuff circumference:22cm-42cm(8 21/32 ″ - 16 17/32 ″ ), 17cm-22cm （ 6 11/16 ″ ~8 21/32 ″... - Page 6 DN:KD-5920BT-SMSY01 V1.0 Operation Guide 4. During measurement, neither speak nor move your body and arm. 5. Measuring on same arm for each measurement. 6. Please always relax at least 1 or 1.5 minutes between measurements to allow the blood circulation in your arm to recover. Prolonged over-inflation (cuff pressure exceed 300 mmHg or maintained above15 mmHg for longer than 3 minutes) of the bladder may cause ecchymoma of your arm.
-
Page 7: Setup And Operating Procedures
DN:KD-5920BT-SMSY01 V1.0 Operation Guide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 8: Clock And Date Adjustment And Bluetooth Set
DN:KD-5920BT-SMSY01 V1.0 Operation Guide b. Load four “AAA” size batteries. Please pay attention to polarity. c. Close the battery cover. When LCD shows battery symbol , replace all batteries with new ones. Rechargeable batteries are not suitable for this monitor. -
Page 9: Connecting The Cuff To The Monitor
DN:KD-5920BT-SMSY01 V1.0 Operation Guide Picture 2-7 Once you change the batteries, you should readjust the time and date. 3. CONNECTING THE CUFF TO THE MONITOR Insert the cuff tubing connector into the socket in the left side of the monitor. Make certain that the connector is completely inserted to avoid air leakage during blood pressure measurements. -
Page 10: Body Posture During Measurement
DN:KD-5920BT-SMSY01 V1.0 Operation Guide Note: Please refer to the cuff circumference range in “ SPECIFICATIONS ” to make sure that the appropriate cuff is used. Measuring on same arm each time. Do not move your arm, body, or the monitor and do not move the rubber tube during measurement. -
Page 11: Displaying Stored Results
DN:KD-5920BT-SMSY01 V1.0 Operation Guide b. Then the current memory bank ( ) is shown. See Picture 6-2. Press “MEM” button to change over to other bank. Confirm your selection by pressing “START” button. The current bank can also be confirmed automatically after 5 seconds with no operation. - Page 12 DN:KD-5920BT-SMSY01 V1.0 Operation Guide Picture 7-1 Picture 7-2 Picture 7-3 Picture 7-4 Picture 7-5 Picture 7-6 Picture 7-7 In Standby Mode, press “MEM” button to display the stored results. The current memory bank will blink and the amount of results in this bank will be displayed. Press “START”...
-
Page 13: Deleting Measurements From The Memory
DN:KD-5920BT-SMSY01 V1.0 Operation Guide 8. DELETING MEASUREMENTS FROM THE MEMORY When any result is displaying, keeping on pressing button “MEM” for three seconds, all results will be deleted. Press the button “MEM” or “START”, the monitor will turn off. Picture 8-1 Picture 8-2 9. -
Page 14: Troubleshooting (1)
DN:KD-5920BT-SMSY01 V1.0 Operation Guide The technical alarm is non-latching and need no reset. The signal displayed on LCD will disappear automatically after about 8 seconds. 11. TROUBLESHOOTING (1) PROBLEM POSSIBLE CAUSE SOLUTION The cuff position was not Apply the cuff correctly and... - Page 15 DN:KD-5920BT-SMSY01 V1.0 Operation Guide “Er 7” LCD shows Device parameter checking error “Er 8” LCD shows Pressure sensor parameter error “Er A” LCD shows Bluetooth connection Reset iOS/Android device. Reset “Er b” unsuccessful, monitor is monitor. Make sure the monitor...
-
Page 16: Maintenance
DN:KD-5920BT-SMSY01 V1.0 Operation Guide MAINTENANCE Do not drop this monitor or subject it to strong impact. Avoid high temperature and solarization. Do not immerse the monitor in water as this will result in damage to the monitor. If this monitor is stored near freezing, allow it to acclimate to room temperature before use. -
Page 17: Warranty Information
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, In c and any use of such marks by ANDON HEALTH CO., LTD. is under license. Other trademarks and trade names are those of their respective owners. -
Page 18: Electromagnetic Compatibility Information
DN:KD-5920BT-SMSY01 V1.0 Operation Guide ELECTROMAGNETIC COMPATIBILITY INFORMATION This product is applicable to the equipment and system requirements for the purpose of receiving radio frequency energy for the purpose of the work, Bluetooth receive bandwidth 2M. This product can also be used to include RF transmitter equipment and system requirements and emission frequency of 2.4GHz ISM band, Bluetooth modulation... - Page 19 DN:KD-5920BT-SMSY01 V1.0 Operation Guide Proximity fields IEC 61000-4-3 Refer to table 3 from RF wireless communications equipment Rated power IEC 61000-4-8 30A/m frequency 50Hz or 60Hz magnetic fields Table 3 – Proximity fields from RF wireless communications equipment Test frequency...
