- Page 1 DN:KD-927-SMSY01 V2.0 Operation Guide History Revision Revision Revision Description Version Drafter Approver date 王成正 张 飞 01 2013/09/09 Originated V1.0 费凡 张飞 02 2014/9/5 Update the address V2.0 of EUROPEAN REPRESENTATION...
- Page 2 DN:KD-927-SMSY01 V2.0 Operation Guide Operation Guide (V2.0) Product/project name： Blood Pressure Monitor ： Model name KD-927 ： 2012-066-RJ17 Project number Drafted Date Reviewed by: Date Approved by: Date...
-
Page 3: Table Of Contents
DN:KD-927-SMSY01 V2.0 Operation Guide MODEL KD-927 Fully Automatic Arm Cuff Blood Pressure Monitor (ELECTRONIC SPHYGMOMANOMETER) OPERATION GUIDE __________________________________________________________________________ INDEX IMPORTANT INFORMATION ................. 2 CONTENTS AND DISPLAY INDICATORS ............. 2 INTENDED USE ....................3 CONTRAINDICATION ..................3 PRODUCT DESCRIPTION ................3 SPECIFICATIONS ................... -
Page 4: Important Information
DN:KD-927-SMSY01 V2.0 Operation Guide IMPORTANT INFORMATION NORMAL BLOOD PRESSURE FLUCTUATION All physical activity, excitement, stress, eating, drinking, smoking, body posture and many other activities or factors (including taking a blood pressure measurement) will influence blood pressure value. Because of this, it is mostly unusual to obtain identical multiple blood pressure readings. -
Page 5: Intended Use
DN:KD-927-SMSY01 V2.0 Operation Guide INTENDED USE Fully Automatic Electronic Sphygmomanometer is for use by medical professionals or at home and is a non-invasive blood pressure measurement system intended to measure the diastolic and systolic blood pressures and pulse rate of an adult individual by using a non-invasive technique in which an inflatable cuff is wrapped around the upper arm. -
Page 6: Specifications
Operation Guide SPECIFICATIONS 1. Product name: Blood Pressure Monitor 2. Model: KD-927 3. Classification:ClassⅡ, Type BF applied part,IPX0,No AP or APG,Continuous operation 4. Machine size: Approx. 175.7mmX99.8mmX60mm ( 3 3/4″x 7 5/16″x 2 7/32″) 22cm-36cm(8-21/32 ″ ~14-3/16 ″ ),35cm-44cm(13-25/32 ″... - Page 7 DN:KD-927-SMSY01 V2.0 Operation Guide 7. Consult your physician if you have any doubt about below cases: 1) The application of the cuff over a wound or inflammation diseases; 2) The application of the cuff on any limb where intravascular access or therapy, or an arterio-venous (A-V) shunt, is present;...
-
Page 8: Setup And Operating Procedures
DN:KD-927-SMSY01 V2.0 Operation Guide user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Page 9 DN:KD-927-SMSY01 V2.0 Operation Guide Picture 2-1 c. In clock and date adjustment Mode , the time format will blink at first , See picture2-2 .If the monitor has no memory and not set the time format , the default time format is 24h and the default clock and date is 2013-1-1 1:00,else the default time format is the last confirmed、clock and date is the most recent result’s.
-
Page 10: Connecting The Cuff To The Monitor
DN:KD-927-SMSY01 V2.0 Operation Guide The display of time and date in 12 hour format is different from 24 hour format. For example, the date is November 15 and time is 6 o’clock p.m., LCD shows picture 2-9 in 12 hour format, however, LCD shows picture 2-10 in 24 hour format. -
Page 11: Applying The Cuff
DN:KD-927-SMSY01 V2.0 Operation Guide Avoid compression or restriction of the connection tubing during measurement， which may cause inflation error, or harmful injury due to continuous cuff pressure. 4. APPLYING THE CUFF a. Pulling the cuff end through the medal loop (the cuff is packaged like this already), turn it outward (away from your body) and tighten it and close the Velcro fastener. -
Page 12: Taking Your Blood Pressure Reading And Bluetooth
DN:KD-927-SMSY01 V2.0 Operation Guide c. The cuff should be placed at the same level as your heart. 6. TAKING YOUR BLOOD PRESSURE READING AND BLUETOOTH a. In Standby Mode, you can only activate the device by pressing “START/STOP” button and the LCD full display .You can check the LCD display according to the picture 6-1. -
Page 13: Displaying Stored Results And Bluetooth
DN:KD-927-SMSY01 V2.0 Operation Guide Picture 6-3 Picture 6-4 After measurement, the backlight will turn off automatically after 10 seconds and the device will turn off automatically after 3 minutes with no operation. Alternatively, you can press the “START/STOP” button to turn off the monitor manually. - Page 14 DN:KD-927-SMSY01 V2.0 Operation Guide Picture 7-1 Picture 7-2 Picture 7-3 b. Press the “M1” button, LCD will display the average value of all the results which is measured from 5 o’clock to 9 o’clock in last 7 days in the current user. See picture 7-4.
-
Page 15: Deleting Measurements From The Memory
DN:KD-927-SMSY01 V2.0 Operation Guide Picture 7-8 Picture 7-9 Picture 7-10 f. When displaying the oldest result measured, if you press the button”M1”, LCD will display the average value of all results in the current user , the memory circle starts again. -
Page 16: Download The Records To Your Computer
DN:KD-927-SMSY01 V2.0 Operation Guide Picture 8-1 Picture 8-2 9. DOWNLOAD THE RECORDS TO YOUR COMPUTER a. Ensure that your computer has installed the software “BPM comm” . b. While the monitor is in any Mode except the measurement Mode and bluetooth Mode , connect the monitor to your computer by USB cable, the device display “PC”... -
Page 17: Assessing High Blood Pressure For Adults
DN:KD-927-SMSY01 V2.0 Operation Guide Picture 9-2 Picture 9-3 e. The device display “PC” and keep the digits below moving in a circle as long as the data is transmitted, See picture 9-4. The device display “PC” and full circle when transmission is successful. -
Page 18: Technical Alarm Description
DN:KD-927-SMSY01 V2.0 Operation Guide Note: It is not intended to provide a basis of any type of rush toward emergency conditions/diagnosis based on the color scheme and that the color scheme is meant only to discriminate between the different levels of blood pressure. -
Page 19: Troubleshooting (2)
DN:KD-927-SMSY01 V2.0 Operation Guide It is inappropriate for people with serious arrhythmia to use Irregular heartbeat (arrhythmia) this Electronic Sphygmomanometer. 13. TROUBLESHOOTING (2) PROBLEM POSSIBLE CAUSE SOLUTION LCD Display shows battery Low Battery charge the lithium battery symbol LCD shows Pressure system is unstable “Er 0”... -
Page 20: Explanation Of Symbols On Unit
DN:KD-927-SMSY01 V2.0 Operation Guide If this monitor is stored near freezing, allow it to acclimate to room temperature before use. Do not attempt to disassemble this monitor. It is recommended the performance should be checked every 2 years or after repair. -
Page 21: Warranty Information
Guidance and manufacture’s declaration - electromagnetic emissions The KD-927 is intended for use in the electromagnetic environment specified below. The customer or the user of the KD-927 should assure that it is used in such an environment. Emissions test Compliance Electromagnetic environment - guidance The KD-927 uses RF energy only for its internal function. - Page 22 Guidance and manufacturer’s declaration - electromagnetic immunity The KD-927 is intended for use in the electromagnetic environment specified below. The customer or the user of the KD-927 should assure that it is used in such an environment. IMMUNITY IEC 60601test...
- Page 23 Guidance and manufacturer’s declaration - electromagnetic immunity The KD-927 is intended for use in the electromagnetic environment specified below. The customer or the user of the KD-927 should assure that it is used in such an environment. IMMUNITY IEC 60601test...
- Page 24 RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the KD-927 is used exceeds the applicable RF compliance level above, the KD-927 should be observed to verify normal operation. If abnormal performance is observed, additional measures may be necessary, such as re-orienting or relocating the KD-927.
