- Page 1 *Preferred HDMI Super Booster Cable EXT-HDMISB-150 • EXT-HDMISB-125 EXT-HDMISB-100 • EXT-HDMISB-75 EXT-HDMISB-50 User Manual Release A3...
-
Page 2: Important Safety Instructions
Important Safety Instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this product near water. Clean only with a dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. -
Page 3: Warranty Information
Gefen warrants the equipment it manufactures to be free from defects in material and workmanship. If equipment fails because of such defects and Gefen is notified within two (2) years from the date of shipment, Gefen will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifications. -
Page 4: Contacting Gefen Technical Support
(800) 545-6900 (818) 772-9120 Email support@gefen.com http://www.gefen.com Mailing Address Gefen, LLC c/o Customer Service 20600 Nordhoff St. Chatsworth, CA 91311 Product Registration Register your product online by visiting the Register Product page under the Support section of the Gefen Web site. -
Page 5: Operating Notes
© 2014 Gefen, LLC. All Rights Reserved. All trademarks are the property of their respective owners. Gefen, LLC reserves the right to make changes in the hardware, packaging, and any accompanying documentation without prior written notice. This product uses UL or CE listed power supplies. - Page 6 Packing List The HDMI Super Booster Cable ships with the items listed below. If any of these items are not present in the box when you first open it, immediately contact your dealer or Gefen. • 1 x HDMI Super Booster Cable •...
-
Page 8: Table Of Contents
Table of Contents Getting Started Introduction......................2 Front ......................2 Bottom ......................2 Back ......................2 Installation ......................4 Connection Instructions ................. 4 Sample Wiring Diagram ................4 Basic Operation DIP Switch Configuration ..................8 Default Settings ..................... 8 Manual and Automatic Equalization .............. 8 Adjusting the Signal Quality .................. -
Page 11: Getting Started
HDMI Super Booster Cable Getting Started Introduction......................2 Front ......................2 Bottom ......................2 Back ......................2 Installation ......................4 Connection Instructions ................. 4 Sample Wiring Diagram ................4... -
Page 12: Introduction
Introduction Page Title Front Bottom ON KE ON KE ON KE Back page | 2... - Page 13 Introduction Page Title Name Description Power Indicator This LED indicator will glow solid green when the HDMI Super Booster Cable is powered. Connection Instructions (page 4) for more information. HDMI Out Use an HDMI cable to connect an HD display to this HDMI port. EQ Trim Pot Use a Phillips-type screwdriver to turn this trim pot and adjust the output signal.
-
Page 14: Installation
Installation Page Title Connection Instructions ► Video Connect the HDMI cable from the HD display to the HDMI Out port on HDMI Super Booster Cable. The HDMI cable should not exceed 6 feet (2 meters) in length. Connect the opposite end of the HDMI Super Booster cable to the source device. ►... -
Page 17: Basic Operation
HDMI Super Booster Cable Basic Operation DIP Switch Configuration ..................8 Default Settings ..................... 8 Manual and Automatic Equalization .............. 8 Adjusting the Signal Quality .................. 9... -
Page 18: Dip Switch Configuration
DIP Switch Configuration On the bottom of the HDMI Super Booster Cable are a bank of 2 DIP switches. These DIP switches provide two functions. 1) Setting the cable length. 2) Switching between manual and automatic EQ modes. See Manual and Automatic Equalization, below, for information on using DIP switch 2. -
Page 19: Adjusting The Signal Quality
Adjusting the Signal Quality The HDMI Super Booster Cable has a trim pot that is used to fine-tune the output signal. If there is no output video or if output video contains video artifacts and/or video noise such as snow, use the steps below to adjust the trim pot. Make sure DIP switch 2 is in the OFF position. -
Page 21: Appendix
HDMI Super Booster Cable Appendix Specifications ...................... 12... -
Page 22: Specifications
Specifications Supported Formats Video • 1080p Full HD • 1920 x 1200 (WUXGA) • Audio • 7.1 Linear PCM • Dolby® TrueHD • DTS-HD Master Audio™ Connectors, Indicators, and Controls Video Input • 1 x HDMI Type A, 19-pin, male Video Output •... - Page 23 Specifications 21.0 mm 21.0 mm 13.0 mm 13.0 mm 41.0 mm 41.0 mm 63.1 mm 63.1 mm ON KE ON KE 41.7mm 41.7mm 13.0 mm page | 13 13.0 mm 21.0 mm...
