1:4 HD-SDI Distribution Amplifier
One SDI Input Becomes 4 SDI Outputs for Real-Time Multi-Viewing
The 1:4 HD-SDI Distribution Amplifier is a reliable video splitting device that allows a single SDI or
HD-SDI video source to send data to four SDI or HD-SDI displays at the same time. Crisp, highly
defined visuals are generated for each distributed output, and multiple formats (NTSC, PAL) plus
high definition video resolutions (720 to 1080p) are fully supported.
SDI
SDI (serial digital interface), used primarily in broadcasting, converts and transmits digital video
through SDI connectors. It processes high quality standard or high definition video.
How It Works
You simply connect your source to the 1:4 HD SDI Splitter's HD-SDI input, then connect your four
displays to the Splitter's HD-SDI outputs. Once the source, the displays and the Splitter are
powered and connected, your source's video appears on all four displays simultaneously.
Features:
Easily distribute one HD-SDI source to four HD-SDI displays
Streamlines equipment; unnecessary hardware is eliminated
Distributes video instantaneously

Specifications:

Input/Output: SDI - SMPTE 259M-C (270Mbps); HD-SDI -SMPTE 292M (1.485,
1.485/1.001 Gbps)
Supports NTSC, PAL & and all HD formats
2048x1024 maximum input/output resolution
Power Consumption: 10 watts (max)
Dimensions: 7.5"W x 1.1"H x 3.5"D
Power Supply: 5V DC
Shipping Weight: 4 lbs.
Package Includes:
1:4 HD-SDI Distribution Amplifier
One 5v Power Supply
Owner's Manual
Dystrybucja i sprzedaż: Meditronik Sp. z o.o.
02-952 Warszawa, ul. Wiertnicza 129, tel. (+48 22) 651-72-42, fax (+48 22) 651-72-46
http://www.meditronik.com.pl
e-mail: office@meditronik.com.pl
EXT-HDSDI-144N

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EXT-HDSDI-144N and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Gefen EXT-HDSDI-144N

  • Page 1: Specifications

    Shipping Weight: 4 lbs. Package Includes: 1:4 HD-SDI Distribution Amplifier One 5v Power Supply Owner's Manual EXT-HDSDI-144N Dystrybucja i sprzedaż: Meditronik Sp. z o.o. 02-952 Warszawa, ul. Wiertnicza 129, tel. (+48 22) 651-72-42, fax (+48 22) 651-72-46 http://www.meditronik.com.pl e-mail: office@meditronik.com.pl...
  • Page 2 HD-SDI 1x4 Splitter U S E R M A N U A L www.gefen.com...
  • Page 3 Chatsworth CA 91311 support@gefen.com -- www.gefen.com Notice Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. 1x4 HD-SDI Splitter is a trademark of Gefen Inc.
  • Page 4: Table Of Contents

    TABLE OF CONTENTS Introduction Features Panel Desciptions Connecting and Operating the 1x4 HD-SDI Splitter Specifi cations Warranty...
  • Page 5: Introduction

    INTRODUCTION Congratulations on your purchase of the ex•tend•it 1x4 HD-SDI Splitter. Your complete satisfaction is very important to us. Splits one HD-SDI Source Signal Four Times 1 SDI Input = 4 SDI Outputs for Real-Time Multi-Viewing The 1:4 HD-SDI Distribution Amplifi er is a reliable video splitting device that allows a single SDI video source to send data to four HD-SDI displays at the same time.
  • Page 6: Features

    FEATURES Features • Easily distribute one HD-SDI source to four HD-SDI displays • Streamlines equipment as unnecessary hardware is eliminated • Distrubutes video instantaneously Includes: (1) 1:4 HD-SDI Distribution Amplifi er (1) 5v Power Supply (1) Users Manual...
  • Page 7: Panel Desciptions

    PANEL DESCRIPTIONS Active Video Power LED Indicator Indicator Connects to SDI Inputs 5V Power SDI Outputs Supply...
  • Page 8: Connecting And Operating The 1X4 Hd-Sdi Splitter

    CONNECTING AND OEPRATING THE 1x4 HD-SDI SPLITTER How to Connect the 1x4 HD-SDI Splitter to your devices 1 Connect your HD-SDI input into Input 1 on the 1x4 HD-SDI Splitter. 2 Connect your displays into outputs 1 thru 4. 3 Connect the 5VDC power supply into the 1x4 HD-SDI Splitter.
  • Page 9: Specifi Cations

    SPECIFICATIONS Input/Output..............SDI - SMPTE 259M-C (270Mbps) Input/Output........HD-SDI -SMPTE 292M (1.485, 1.485/1.001 Gbps) Supports NTSC & PAL formats 720p @ 60, 59.94, 50Hz 1080p @ 30, 29.97, 25, 24 & 23.98Hz 1080i @ 60, 59.94, 50, 48 & 47.95Hz Power Supply......................5V DC Power Consumption..................10 watts (max) Dimensions................7.5”W x 1.25”H x 4.125”D Shipping Weight......................4 lbs.
  • Page 10: Warranty

    If equipment fails because of such defects and Gefen Inc. is notifi ed within two (2) year from the date of shipment, Gefen Inc. will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifi...
