Blenda
Single footswitch
Blend-a-Fenda
Contents of this document are ©2023 Pedal Parts Ltd.
No reproduction permitted without the express written
permission of Pedal Parts Ltd. All rights reserved.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Blenda and is the answer not in the manual?

Questions and answers

Summary of Contents for FuzzDog Blenda

  • Page 1 Blenda Single footswitch Blend-a-Fenda Contents of this document are ©2023 Pedal Parts Ltd. No reproduction permitted without the express written permission of Pedal Parts Ltd. All rights reserved.
  • Page 2 Before you dig in, ensure you download and read the General Build Guide. It contains all the information you need for a successful outcome.
  • Page 3 Schematic + BOM 100n 1N5817 150K D2-5 Ge/BAT46* 560K 100n 10u elec Q1-5 2N5088** 10u elec 120K 10u elec BLEND 100KB 10u elec LEVEL 50KA 680R 10u elec SUST 10KA 220K 10u elec TONE 25KB 150K 100n SPDT ON-ON 10u elec The toggle switch engages 10u elec ‘Expand’...
  • Page 5: Toggle Switch

    Snap the small metal tag off the pots so they can be mounted flush in the box. You should solder all other board-mounted components before you solder the pots. Once they’re in place you’ll have no access to much of the board.
  • Page 6: Drilling Template

    3 mm This template is a rough guide only. You should ensure correct marking of your enclosure before drilling. You use this template at your own risk. Pedal Parts Ltd can accept no responsibility for incorrect drilling of enclosures. FuzzDog.co.uk...
