BLAUBERG BOX-D 100 L User Manual

Centrifugal ceiling fan

Advertisement

Quick Links

Centrifugal Ceiling fan
BOX-D 100 l
BOX-D 125 l
BOX-D 100
BOX-D 125
BOX-D 150
EN
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BOX-D 100 L and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for BLAUBERG BOX-D 100 L

  • Page 1 Centrifugal Ceiling fan BOX-D 100 l BOX-D 125 l BOX-D 100 BOX-D 125 BOX-D 150 USER’S MANUAL...
  • Page 2: Table Of Contents

    BOX-D www.blaubergventilatoren.de CONTENTS Safety requirements ..................................2 Purpose ........................................ 4 Delivery set ......................................4 Designation key ....................................4 Technical data ....................................5 Design and operating principle ............................6 Mounting and set-up .................................. 6 Connection to power mains ..............................8 Technical maintenance ................................9 Troubleshooting .....................................
  • Page 3 BOX-D www.blaubergventilatoren.de If the supply cord is damaged, it must be replaced by the manufacturer, its service agent, or similarly qualified persons in order to avoid a safety hazard. Ensure that the unit is switched off from the supply mains before removing the guard. All operations described in this manual must be performed by qualified personnel only, properly trained and qualified to install, make electrical connections and maintain ventilation units.
  • Page 4: Purpose

    Transported air must not contain any flammable or explosive mixtures, evaporation of chemicals, sticky substances, fibrous materials, coarse dust and oil particles or environments favourable for the formation of hazardous substances (toxic substances, dust, pathogenic germs). DELIVERY SET BOX-D 100 L, BOX-D 100, BOX-D 125 L, BOX-D 150 BOX-D 125 1 pc.
  • Page 5: Technical Data

    Ingress protection rating against access to hazardous parts and water ingress is IPX4. The unit design is constantly being improved, thus some models may slightly differ from those described in this manual. BOX-D 100 L, BOX-D 100, BOX-D 125 L, BOX-D 125 BOX-D 150...
  • Page 6: Design And Operating Principle

    The electric motor has integrated thermal protection and restarts automatically. MOUNTING AND SET-UP The fan is installed between the floor slab and suspended ceiling. BOX-D 100 L, BOX-D 100, BOX-D 125 L, BOX-D 125 BOX-D 150...
  • Page 7 BOX-D www.blaubergventilatoren.de FAN MOUNTING Mounting using two holders Mounting using a fastening kit for wall Mounting using four holders side mounting 250 mm 403,5 mm 280 mm...
  • Page 8: Connection To Power Mains

    BOX-D www.blaubergventilatoren.de CONNECTION TO POWER MAINS ANY TAMPERING WITH THE INTERNAL CONNECTIONS IS PROHIBITED AND WILL VOID THE WARRANTY. The unit is rated for connection to power mains with the parameters specified in the “Technical data” section, according to the wiring diagram.
  • Page 9: Technical Maintenance

    BOX-D www.blaubergventilatoren.de TECHNICAL MAINTENANCE DISCONNECT THE UNIT FROM POWER SUPPLY BEFORE ANY MAINTENANCE OPERATIONS! MAKE SURE THE UNIT IS DISCONNECTED FROM POWER MAINS BEFORE REMOVING THE PROTECTION. The technical maintenance of the fan includes periodic cleaning of the fan surfaces from dust and dirt. The fan must remain disconnected during the procedure.
  • Page 10: Troubleshooting

    BOX-D www.blaubergventilatoren.de TROUBLESHOOTING TROUBLE POSSIBLE REASONS TROUBLESHOOTING No power supply. Check the electrical connections and the power switch status. When switching on, the fan does Turn off the fan. not start. Jammed motor. Troubleshoot the impeller jamming Restart the fan. Overcurrent as a result of short circuit Automatic circuit breaker tripping Disconnect the fan from power mains and contact the Seller.
  • Page 11: Storage And Transportation Regulations

    BOX-D www.blaubergventilatoren.de STORAGE AND TRANSPORTATION REGULATIONS • Store the unit in the manufacturer’s original packaging box in a dry closed ventilated premise with temperature range from +5 °C to + 40 °C and relative humidity up to 70 %. • Storage environment must not contain aggressive vapors and chemical mixtures provoking corrosion, insulation, and sealing deformation.
  • Page 12: Manufacturer's Warranty

    BOX-D www.blaubergventilatoren.de MANUFACTURER’S WARRANTY The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility. We hereby declare that the product complies with the provisions of Electromagnetic Compatibility (EMC) Directive 2014/30/EU of the European Parliament and of the Council, Low Voltage Directive (LVD) 2014/35/EU of the European Parliament and of the Council and CE-marking Council Directive 93/68/EEC.
  • Page 13: Certificate Of Acceptance

    BOX-D www.blaubergventilatoren.de CERTIFICATE OF ACCEPTANCE Unit Type Centrifugal ceiling fan Model Serial Number Manufacture Date Quality Inspector’s Stamp SELLER INFORMATION Seller Address Phone Number E-mail Purchase Date This is to certify acceptance of the complete unit delivery with the user’s manual. The warranty terms are acknowledged and accepted.
  • Page 14 BOX-D www.blaubergventilatoren.de...
  • Page 15 BOX-D www.blaubergventilatoren.de...
  • Page 16 www.blaubergventilatoren.de B69EN-04...
