- Page 1 AXIAL WALL / CEILING FAN BLABQUATRO 100, 125, 150 150QP, 150T USER’S MANUAL...
-
Page 3: Table Of Contents
CONTENTS Safety requirements ............................................4 Delivery set ................................................8 Brief description ..............................................8 Operation guidelines ............................................8 Installation and set-up............................................. 8 Fan setup ................................................. 9 Technical maintenance ........................................... 10 Storage and transportation regulations ....................................10 Manufacturer’s warranty ..........................................11 This user’s manual is a main operating document intended for technical, maintenance, and operating staff. The manual contains information about purpose, technical details, operating principle, design, and installation of the BLABQUATRO unit and all its modifications. -
Page 4: Safety Requirements
FOLLOW THE USER’S MANUAL REQUIREMENTS TO ENSURE DURABLE AND TROUBLE-FREE OPERATION OF THE UNIT SAFETY REQUIREMENTS All operations described in this manual must be performed by qualified personnel only, properly trained and qualified to install, make electrical connections and maintain ventilation units. Do not attempt to install the product, connect it to the mains, or perform maintenance yourself. - Page 5 Connection of the unit to power mains is allowed by a qualified electrician with a work permit for the electric units up to 1000 V after careful reading of the present user’s manual. Check the unit for any visible damage of the impeller, the casing, and the grille before starting installation.
- Page 6 Do not sit on the unit and do not put objects on it. The information in this user’s manual was correct at the time of the document’s preparation. The Company reserves the right to modify the technical characteristics, design, or configuration of its products at any time in order to incorporate the latest technological developments.
- Page 7 Precautions must be taken to avoid the back-flow of gases into the room from the open flue of gas or other fuel-burning appliances. The appliance may adversely affect the safe operation of appliances burning gas or other fuels (including those in other rooms) due to back flow of combustion gases.
-
Page 8: Delivery Set
DELIVERY SET — 1 pc. Screws with dowels — 4 pcs. Plastic screwdriver (for all models with a timer) — 1 pc. User’s manual — 1 pc. Packing box — 1 pc. BRIEF DESCRIPTION The unit described herein is an axial fan for exhaust ventilation of small to medium-sized premises heated during winter. It is designed for wall or ceiling mounting (Fig. -
Page 9: Fan Setup
Terminal designations on wiring diagrams: L — phase QF — automatic circuit breaker S — external switch LT — timer control line N — neutral FAN SETUP — to adjust the fan turn-off delay time, turn the control knob T clockwise to increase and counter-clockwise to decrease the turn-off delay time respectively, adjustable from 2 up to 30 minutes. -
Page 10: Technical Maintenance
TECHNICAL MAINTENANCE The fan maintenance periodicity is at least once per 6 months. Maintenance steps: • Disconnect the fan from power supply and make sure electricity has been turned off (Fig. 14). • Remove the front and the decorative panels, wipe the fan with a dry cloth or a brush (Fig. 15). •... -
Page 11: Manufacturer's Warranty
Our ventilation products also come with a two year limited warranty given by Blauberg Australasia Pty Ltd, with an office at Unit 5, 45A Eastern Creek Drive, Eastern Creek, New South Wales 2766, as set out in the instruction manual in the box. - Page 12 FOLLOWING THE REGULATIONS STIPULATED HEREIN WILL ENSURE A LONG AND TROUBLE-FREE OPERATION OF THE UNIT USER’S WARRANTY CLAIMS SHALL BE SUBJECT TO REVIEW ONLY UPON PRESENTATION OF THE UNIT, THE PAYMENT DOCUMENT AND THE USER’S MANUAL WITH THE PURCHASE DATE STAMP...
- Page 13 Dimensions [mm] Weight Model [kg] 171 151 108 128 100 0.56 201 178 113 136 125 0.73 236 207 165 157 150...
- Page 16 Fan does not run BLABQUATRO Contact of the S switch is CLOSED Fan runs Contact of the S switch is OPENED Fan does not run BLABQUATRO T Contact of the S switch is CLOSED Fan runs Contact of the S switch is OPENED Activation of turn-off...
- Page 19 Quality Inspector’s Stamp Sold by (name and stamp of the seller) Manufacture Date Purchase Date...
- Page 20 BLABQUATRO ____________________________________ www.blaubergventilation.com.au Blauberg_Australasia_B174EN-02 BLABQUATRO...
