- Page 1 AXIAL FAN Moon Hi-Fi Bavaria Moon One Hi-Fi One Bavaria One USER’S MANUAL...
-
Page 2: Table Of Contents
The manual contains information about purpose, technical details, operating principle, design, and installation of the Moon/Hi-Fi/Bavaria/Moon One/Hi-Fi One/Bavaria One unit and all its modifications. Technical and maintenance staff must have theoretical and practical training in the field of ventilation systems and should be able to work in accordance with workplace safety rules as well as construction norms and standards applicable in the territory of the country. - Page 3 All operations described in this manual must be performed by qualified personnel only, properly trained and qualified to install, make electrical connections and maintain ventilation units. Do not attempt to install the product, connect it to the mains, or perform maintenance yourself. This is unsafe and impossible without special knowledge.
- Page 4 of any foreign objects that can damage the impeller blades. While mounting the unit, avoid compression of the casing! Deformation of the casing may result in motor jam and excessive noise. Misuse of the unit and any unauthorised modifications are not allowed.
- Page 5 order to incorporate the latest technological developments. Never touch the unit with wet or damp hands. Never touch the unit when barefoot. BEFORE INSTALLING ADDITIONAL EXTERNAL DEVICES, READ THE RELEVANT USER MANUALS. This unit is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the unit by a person responsible for...
- Page 6 Cleaning and user maintenance shall not be made by children without supervision. Children shall not play with the appliance. Precautions must be taken to avoid the back-flow of gases into the room from the open flue of gas or other fuel-burning appliances. The appliance may adversely affect the safe operation of appliances burning gas or other fuels (including those in other rooms) due to back flow of combustion gases.
- Page 7 Ensure that the unit is switched off from the supply mains before removing the guard. THE PRODUCT MUST BE DISPOSED SEPARATELY AT THE END OF ITS SERVICE LIFE. DO NOT DISPOSE THE UNIT AS UNSORTED DOMESTIC WASTE.
-
Page 8: Delivery Set
DELIVERY SET - 1 pc. Screws with dowels - 4 pcs. Plastic screwdriver - 1 pc. (only for the models with a timer) User’s manual - 1 pc. Packing box - 1 pc. Insulating gasket - 1 pc. BRIEF DESCRIPTION The product is an axial fan for exhaust ventilation of small and medium-sized premises heated in winter. -
Page 9: Designation Key
H (for V2) - humidity sensor and turn-off/turn-on delay timer Outlet duct diameter [mm] 100/125 Motor type _ — single-speed motor V2 — double-speed motor Fan series Moon/Hi-Fi/Bavaria Moon One/Hi-Fi One/Bavaria One Availability of options depending on the fan model Moon/Hi-Fi/Bavaria Moon One/Hi-Fi One/Bavaria One – –... -
Page 10: Mounting
MOUNTING The fan is designed for wall or ceiling mounting and can be used for direct outdoor air exhaust through a round duct or a duct system. In case of installation through a duct system, select the duct cross section in accordance with the fan size (Fig. 1). 1. - Page 11 60364-7-701 (in the current version), as well as in accordance with the requirements of the national standards of the country of its installation. Moon One/Hi-Fi One/Bavaria One models may be installed in Zone 1 of bathrooms where the product cannot be exposed to water jets other than shower spray.
-
Page 12: Electronic System Operation Algorithm
ELECTRONIC SYSTEM OPERATION ALGORITHM The T model fans equipped with a timer are activated by control voltage application to input terminal S by an external switch (e.g. indoor light switch). Upon control voltage removal the fan continues to operate for the period of time set by the timer within the range from 2 to 30 minutes. -
Page 13: Maintenance
— To adjust the fan activation delay time, turn the T potentiometer knob clockwise (+) or counter-clockwise (-) which sets the activation delay time within the range from 0 to 2 minutes. — To adjust the fan deactivation delay time, turn the T potentiometer knob clockwise (+) or counter-clockwise (-) which sets the activation delay time within the range from 2 to 30 minutes. -
Page 14: Troubleshooting
TROUBLESHOOTING Problem Possible reasons Troubleshooting Make sure the power supply line When the unit is connected to power No power supply. is connected correctly, otherwise troubleshoot the connection error. mains, the fan does not rotate and does not respond to any controls. Internal connection fault. -
Page 15: Manufacturer's Warranty
MANUFACTURER’S WARRANTY The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility. We hereby declare that the product complies with the provisions of Electromagnetic Compatibility (EMC) Directive 2014/30/ EU of the European Parliament and of the Council, Low Voltage Directive (LVD) 2014/35/EU of the European Parliament and of the Council and CE-marking Council Directive 93/68/EEC. - Page 16 • Redesign or engineering changes to the unit. • Replacement and use of any assemblies, parts and components not approved by the manufacturer. • Unit misuse. • Violation of the unit installation regulations by the user. • Violation of the unit control regulations by the user. •...
- Page 17 ø D D, mm A, mm B, mm L, mm L1, mm Moon 100 (One) Hi-Fi 100 (One) Bavaria 100 (One) Moon 125 123.5 Hi-Fi 125 123.5 Bavaria 125 123.5...
- Page 18 ˚ ˚ ...2...
- Page 20 ... 100/125 ... 100/125 T ... 100/125 S(T) ... 100/125 T(ST) Fan does not run Contact of the S1 switch or the pull cord switch is CLOSED Fan runs Contact of the S1 switch or the pull cord switch is OPENED Activation of turn-off...
- Page 21 ... 100/125 TR ... 100/125 STR Fan does not run Contact of the S1 switch or the pull cord switch is CLOSED Activation of turn-off delay timer (0-2 minutes) Switch is OFF during countdown of turn-on delay timer Fan runs Contact of the S1 switch or the pull cord switch is OPENED...
- Page 22 ... 100/125 H ... 100/125 SH Fan does not run Contact of the S1 switch or the pull cord switch is CLOSED Humidity exceeds set point Fan runs Contact of the S1 switch or the pull cord switch is OPENED Fan runs Humidity is below set point Activation of turn-off...
- Page 23 ... V2 100/125 speed 1 and 2 Fan does not run Contact of the S1 switch or the pull cord switch is CLOSED S switch is in Speed position Fan runs at speed 1 Fan runs at speed 2 Contact of the S1 switch or the pull cord switch is OPENED...
- Page 24 ... V2 100/125 TR Fan runs at speed 1 Contact of the S1 switch or the pull cord switch is CLOSED Activation of turn-on delay timer (0-2 minutes) Fan runs at speed 2 Contact of the S1 switch or the pull cord switch is OPENED Activation of turn-off...
- Page 25 ... V2 100/125 H Fan runs at speed 1 Contact of the S1 switch or the pull cord switch is CLOSED Humidity exceeds set point Activation of turn-on delay timer (45 seconds) The contact of the S1 switch or the pull cord switch is OPENED during the turn-on delay timer operation Fan runs at speed 2...
- Page 27 Quality Inspector’s Stamp Seller (name and stamp of the seller) Manufacture Date Purchase Date...
- Page 28 ______________________________ www.blaubergventilatoren.de B160EN-07...
