Dawlish Tap Range
Installation Instructions
and User Guide
Models covered:
Basin Mixer
TDCC04 / TDCG04 / TDCN04
Bidet Mixer
TDCC05 / TDCG05
3 Hole Basin Mixer
TDCC06 / TDCG06/ TDCN06
Please keep this booklet for future reference.
Installer: when you have read these
instructions please ensure you leave them
with the user.
Advertisement
Table of Contents
Related Manuals for Heritage Bathrooms Dawlish TDCC04
Summary of Contents for Heritage Bathrooms Dawlish TDCC04
- Page 1 Dawlish Tap Range Installation Instructions and User Guide Models covered: Basin Mixer TDCC04 / TDCG04 / TDCN04 Bidet Mixer TDCC05 / TDCG05 3 Hole Basin Mixer TDCC06 / TDCG06/ TDCN06 Please keep this booklet for future reference. Installer: when you have read these instructions please ensure you leave them with the user.
-
Page 2: Table Of Contents
Contents When you buy a Heritage product, you can be confident that it not only features a beautiful, distinctive, classic design, but that it has also been made to the very highest quality standards. To ensure that it works to its full potential, it needs to be fitted correctly. These fitting instructions have been created to give you all of the information you need and, if you need any further help, please do not hesitate to give us a call on 0330 026 8503. -
Page 3: Safety Notice
NOTE:- Nominally equal (balanced) inlet supply pressures are recommended for optimum Performance of mixer taps. All products manufactured and supplied by Heritage Bathrooms are safe to use provided that they are installed, operated and receive regular maintenance in accordance with these instructions. This product needs to be installed in accordance with, and meet the requirements of the Water Supply (Water Fittings) Regulations 1999 and current by- laws. -
Page 4: Dimensions
Dimensions Basin Mixer (TDCC04 / TDCG04/TDCN04) Bidet Mixer (TDCC05 / TDCG05) 3 Hole Basin Mixer (TDCC06 / TDCG06/TDCN06) -
Page 5: Installation Requirements
Installation Requirements Care must be taken when connecting the flexible connecting pipes to the household pipework to ensure they do not bend sharply, kink or twist. See below for recommended ways to fit the flexible connecting pipes. Important: Failure to follow these guidelines may result in poor performance and damage to the flexible connecting pipes. -
Page 6: Installation
Installation Basin and Bidet Mixer 1. Identify all components are present prior to starting installation. 2. Screw in copper pipes (19) and fixing kit rod (15) to tap. Fit the mixer body to the basin/bidet using the ‘C’ plate fixing kit. The full rubber washer (12) goes between the fitting and the basin/bidet, and the ‘C’... -
Page 7: Basin / Bidet Mixer 05
Installation Cont. Basin and Bidet Mixer... -
Page 8: Installation
Installation 3 Hole Basin Mixer 1. Identify all components and check for completeness particularly before arranging fitting. 2. Disassemble the two side bodies and remove the T joint assembly(20) from the mixer body (03) then feed the brass parts (labelled H & C) from the underside of the basin. Secure with shroud at the top (12) and backnut and washers at bottom (13, 14, 15). - Page 9 Installation Cont. 3 Hole Basin Mixer...
-
Page 10: Maintenance
Maintenance General Cleaning Heritage products are made from premium materials, with hand polishing, PVD, EPD and electroplated finishes. Your product should be regularly cleaned with warm water, a mild pH-neutral liquid soap, and polished with a soft cloth. Any residues from soap, toiletries etc. should be rinsed off straight after use. -
Page 11: Troubleshooting
Troubleshooting Symptom Cause Remedy No flow or poor flow rate. Partially closed isolation valve. Open isolation valve. Instantaneous water heater cycles on Increase water flow rate or pressure and off as flow rate or pressure is too through system. low. Head of water is below the Refer to specification for minimum minimum distance required. -
Page 12: Guarantee
Heritage Bathrooms Guarantee G UA R A N T E E The confidence we have in the quality of our products and services enables us to offer a free peace-of-mind product guarantee from 2 years up to a lifetime guarantee against any manufacturing faults, with proof of purchase. - Page 13 Email us 0330 026 8503 Call us www.heritagebathrooms.com Website UK: Heritage Bathrooms, Pooley Hall Drive, Birch Coppice Business Park, Dordon, Tamworth B78 1SG EU: Masco Europe S.à.r.l., 14 Rue Strachen, 6933 Mensdorf, Luxembourg.
