White Manual Height Adjustable Desk
Instruction Manual
SKU: DESK-MW43TW
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/desk-mw43tw
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivo DESK-MW43TW
Summary of Contents for Vivo DESK-MW43TW
- Page 1 White Manual Height Adjustable Desk Instruction Manual SKU: DESK-MW43TW Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/desk-mw43tw GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual and do not exceed weight capacity. -
Page 3: Assembly Steps
ASSEMBLY STEPS STEP 1 Position the desktops (I, J, K) upside down on a flat surface. STEP 2 Assemble the desktops (I, J, K) using the desktop connectors (N) and flat head screws (M). Tighten screws with a Phillips screwdriver. STEP 3 Loosen the two set screws on the telescopic crossbar (A) using the Allen wrench (S-E) and partially extend the crossbar. - Page 4 STEP 4 Place the crossbar spacer (D) on the leg (B) as shown. Attach the telescopic crossbar to the legs (B, C) as shown using M6x12mm bolts (S-A), and tighten with the Allen wrench (S-E). NOTE: Insert all necessary screws into holes before tightening. STEP 5 Attach the side brackets (E) to both ends of the frame using four M6x12mm bolts (S-A).
- Page 5 STEP 7 Loosen the knob on the other end of the sync rod and extend the hex shaft into the socket in the leg, making sure the shaft is fully inserted with the red O-ring bumper spaced no more than 0.5” from the leg.
- Page 6 STEP 10 Place the assembled frame on the desktop, making sure the holes are aligned with the desk frame, and secure the frame using ST4.2x20 screws (S-C). STEP 11 Loosen the set screw on the crank (G) using the Allen wrench (S-E). Extend the crank into the gearbox, and with the front of the support plate flush with the front of the desktop, retighten the set screw.
- Page 7 STEP 12 Place the feet (H) on the legs as shown. Insert and tighten bolts (S-A) using the Allen wrench (S-E). STEP 13 Pull crank out when raising/lowering the desk height. Push back in when not in use. If necessary, adjust foot pads to level the desk. CAUTION: When moving desk, ALWAYS carry the desk by the frame part ONLY and never by the divided desktop.
