Package Contents A (x1) B (x1) C (x2) Leg with Left Leg Leg Support Gearbox D (x1) E (x1) F (x2) Sync Rod Inner Crossbar Side Bracket G (x1) H (x1) I (x1) J (x1) Crank Handle Bracket Crank Handle Left Crossbar Right Crossbar K (x4)
Assembly Steps STEP 1 Attach Left Crossbar (G) to the Left Leg (B) and Right Crossbar (H) to Leg with Gearbox (A) using M6x11mm Screws (S-A) and 5mm Allen Wrench (T-B).
Page 7
STEP 2 Insert Inner Crossbar (E) into Left and Right Crossbars (G,H) as shown. Ensure the Slots on Inner Crossbar are facing in towards the legs. Slot...
Page 8
STEP 3 Thread all four Feet (K) into Leg Supports (C), then attach Leg Supports to Legs (A,B) using M6x35mm Screws (S-D) and 5mm Allen Wrench (T-B).
Page 9
STEP 4 Side Brackets (F) have the same installation process on both Legs (A,B). Left Leg (B) is shown below. Insert M8x12mm Screws (S-B) through Side Using 5mm Allen Wrench, install M6x11mm Bracket (F) into Leg (A,B). Partially tighten using Screws (S-A) through the Side Bracket and into 5mm Allen Wrench (T-B), leaving a gap between Leg.
Page 10
STEP 5 5.1 Loosen the Knob on Sync Rod (D) and extend the Hex Shaft. 5.2 Insert the hex shaft end into the Left Leg (B). Ensure both legs are at the same height. If they are not, rotate the sync rod clockwise to raise and counterclockwise to lower the leg. 5.3 Extend the Sync Rod (D) and fit into Leg with Gearbox (A) as shown, then tighten the set screw using 2mm Allen Wrench (T-A).
Page 11
STEP 6 Flip the frame onto your desktop (not included). Extend the frame until the holes on Side Brackets (F) line up with the pilot holes on your desktop. Secure the frame to the desktop using ST5x15mm Screws (S-C) and a Phillips screwdriver or drill. Note: If your desktop does not have pilot holes, extend the frame to the length of the desktop or until the Slots on Inner Crossbar (E) are exposed.
Page 12
STEP 7 Secure the Inner Crossbar (E) using M8x11mm Screws (S-A) and 5mm Allen Wrench (T-B). Attach Crank Handle Bracket (I) to the desktop as shown using ST5x15mm Screws (S-C) and a Phillips screwdriver or drill.
Page 13
STEP 8 Insert Crank Handle (J) through the Crank Handle Bracket (I) and into the Leg with Gearbox (A). Turn the Crank Handle (J) to adjust the desk up or down.
