Crank Height Adjustable 55" Desk - Black
Instruction Manual
SKU: DESK-M55TB
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/desk-m55tb
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Related Manuals for Vivo DESK-M55TB
Summary of Contents for Vivo DESK-M55TB
- Page 1 Crank Height Adjustable 55” Desk - Black Instruction Manual SKU: DESK-M55TB Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/desk-m55tb GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual and do not exceed weight capacity. -
Page 3: Assembly Steps
ASSEMBLY STEPS STEP 1 Stand up the lifting columns (A) and insert the sync rod (B) into the socket on each column. Use the crank (F) to align columns if needed. STEP 2 Assemble the upper crossbar (C) to the top of the columns using the long hex head bolts (S-C) and the lower crossbar (D) to the back using short hex head bolts (S-A). - Page 4 STEP 3 Apply the pads (S-D) to the top of the assembled frame. STEP 4 Place the desktop (E) on top of the frame. Secure using the Phillips head bolts (S-B) with washers (S-E), and tighten with a Phillips screwdriver.
- Page 5 STEP 5 Insert the crank (F) into the hex socket of the lifting column. Figure 1: Turn the crank to raise or lower the desk. Figure 2: Store the crank in the rear of the desk support bracket on the column as shown. Figure 3: Turn the foot pads to adjust the desk level.
- Page 6 STEP 5 (Continued)
