- Page 1 ERMINAL AYMENT EVICE XCL_AT-150 SERIES INSTALLATION GUIDE xCL_AT-150 series: xCL_AT-150-E-18U xCL_AT-150-E-18E...
-
Page 2: Package Content
This symbol is intended to alert the user before starting using the POS. 1. PACKAGE CONTENT Paper Roll Power adaptor Power cable AT-150 2. DEVICE OVERVIEW Device Overview (Figure 1): FRONT LEFT REAR Figure 1... -
Page 3: Power On/Off The Device
Output: 5V /2A (USB-C port) /3A (Pogo charging port) Caution: Use only the AC adapter approved and provided by XAC Automation Corporation for use with this device. Use of any other AC adapter may cause a risk of fire or explosion. -
Page 4: Using The Magnetic Card Reader
NOTE:When there is no action on AT-150 after 30sec (adjustable), the device will enter sleep mode. Please short press power button to wake up the device. 4. USING THE MAGNETIC CARD READER Swipe the card through the slot with magnetic stripe side facing the same direction as the display. -
Page 5: Replace The Battery
Figure 6 7. USING THE CONTACTLESS CARD READER Tap the contactless card on top of the contactless logo (Figure7). Figure 7 8. REPLACE THE BATTERY 8-1 REMOVE THE BATTERY STEP 1: Remove the screw (head size: M2) of battery cover from AT-150 as Figure 8. STEP 2: After removing the screw, pull up the battery as below Figure 9to change a new battery. - Page 6 Figure 8 Figure 9 8-2INSTALL THE BATTERY STEP 1: Insert the battery connector into AT150 with correct direction as Figure 10. STEP 2: After install the battery, close the bottom cover with screw as Figure Figure 10 Figure 11 Bottom Cover Removal Warning When removing the bottom cover and screws for the purposes of changing battery, remember to put back the cover and screws before power on the POS.
- Page 7 CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS. Warning for internal battery pack To reduce risk of fire or burns: Do not attempt to open, disassemble, or service the battery pack. Do not crush, puncture, short external contacts, or dispose of in fire or water.
- Page 8 XAC Automation Corporation. XAC AUTOMATION CORP. shall not be held liable for technical and editorial omissions or errors made herein; nor for incidental or consequential damages resulting from the furnishing, performance or use of his material.
