Ballard Designs Martin MS122 Manual

2 door console 36”h x 39 1/2”w x 10 3/4”d

Download this manual

PRODUCT NAME: Martin 2 Door Console

ITEM NUMBER: MS122

ASSEMBLED DIMENSIONS : 36"H x 39 1/2"W x 10 3/4"D

PRODUCTS ARE NOT INTENDED

FOR COMMERCIAL USE.

UPDATED: 4-20-2021

Prevent accidentally discarding small parts or

hardware. Retain all carton contents until assembly

and installation are complete.

Customer Service: 800-367-2810

Online: www.ballarddesigns.com

MADE IN CHINA

Page 1 of 4

Need help?

Do you have a question about the Martin MS122 and is the answer not in the manual?

Page 1 Customer Service: 800-367-2810 Online: www.ballarddesigns.com PRODUCT NAME: Martin 2 Door Console ITEM NUMBER: MS122 ASSEMBLED DIMENSIONS : 36”H x 39 1/2”W x 10 3/4”D Prevent accidentally discarding small parts or hardware. Retain all carton contents until assembly and installation are complete. PRODUCTS ARE NOT INTENDED MADE IN CHINA FOR COMMERCIAL USE.
Page 2 Assemble in location for intended use. REQUIRED TOOLS: Ltr. Qty. Hardware Included Phillips Screwdriver, Allen Wrench (included) Allen Wrench -Two person assembly suggested. Allen Bolts Remove all parts, hardware and Lock Washers protective packaging from carton and carefully arrange on a clean, Flat Washers level, padded surface.
Page 3 Assemble in location for intended use. STEP 1: Place Console (G) backside down onto a level, padded surface then insert, turn and tighten both Feet (H) into embedded T-nuts in each front corner. Next, orient Back Feet (I) as illustrated and secure using Allen Bolt (B), Lock Washer (C) and Flat Washer (D).
Page 4 WALL ANCHORING HARDWARE (ANTI-TIP) Ltr. Qty. Hardware Included Large Screw Small Screw WARNING Tip-Over Hazard Bracket Serious or fatal crushing injuries can occur from a furniture tip-over Prevent tipping accidents. Anchor your furniture. Retention Belt Installation: 1. Place furniture against wall at desired location then locate and mark a Wall Stud behind unit. 2.
