Installation information
KERN KMB/KMS/KMT-TM
Version 2.0 01/2007
KERN & Sohn GmbH
Ziegelei 1
D-72336 Balingen-Frommern
Postfach 40 52
72332 Balingen
Display devices
Tel. 0049 –[0]7433-9933-0
Fax. 0049 –[0]7433-9933-149
e-mail: info@kern-sohn.com
Web: www.kern-sohn.com
KMB/KMS/KMT-TM-BA-e-0720
ME-Nr. 22017065

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KMB Series and is the answer not in the manual?

Questions and answers

Summary of Contents for KERN KMB Series

  • Page 1 KERN & Sohn GmbH Ziegelei 1 Tel. 0049 –[0]7433-9933-0 D-72336 Balingen-Frommern Fax. 0049 –[0]7433-9933-149 Postfach 40 52 e-mail: info@kern-sohn.com 72332 Balingen Web: www.kern-sohn.com Installation information Display devices KERN KMB/KMS/KMT-TM Version 2.0 01/2007 KMB/KMS/KMT-TM-BA-e-0720 ME-Nr. 22017065...
  • Page 2: Table Of Contents

    Contents Important information ...........................2 Product range ..............................2 Documentation ..............................2 Safety and environment ..........................2 Attaching weighing platforms ........................3 Instructions on weighing cells .........................3 2.1.1 Cells with or without SENSE lines ........................3 2.1.2 Attaching weighing platforms with several weighing cells ..................3 Preparing the connecting cable for the weighing platform ..................3 Attaching the weighing platform to the terminal ....................4 Configuring the terminal ..........................5 Calling up the menu and entering the password ....................5...
  • Page 3: Important Information

    Chapter 1: Important information Important information Please read this installation information carefully and observe all instructions! Please contact the Sales Office if there are items which are missing or have been wrongly delivered, or if you encounter any other problems with the terminal. These instructions are intended for those who have a basic but adequate knowledge of the design of weighing systems.
  • Page 4: Attaching Weighing Platforms

    Chapter 2: Attaching weighing platforms Attaching weighing platforms All analog weighing platforms can be attached to the terminals if they are conform to the required specifications (see chapter 5). Two different weighing platforms can be attached if the terminal also has an OptionPac with an analog option. Compact two-scale systems can therefore be constructed using just one terminal.
  • Page 5: Attaching The Weighing Platform To The Terminal

    Chapter 2: Attaching weighing platforms Attaching the weighing platform to the terminal Before assembling, the terminal must first be disconnected from the power supply! Undo the gland nut of the heavy gauge cable gland and remove this together with the black crimping ferrule and the two washers. Undo the rear cover plate of the terminal (6 Torx T20 screws) and fold down carefully (cable connections!).
  • Page 6: Configuring The Terminal

    Chapter 3: Configuring the terminal Configuring the terminal The configuration data of the weighing system must be known before the terminal can be configured (see chapter 5). The IND4.. terminal has a service level for entering configuration data as well as for calibrating and linearization of the weighing system. This level is protected by a password.
  • Page 7: Summary Of Menu Blocks Of The Service Level

    Chapter 3: Configuring the terminal Summary of menu blocks of the service level The complete menu is available including those menu blocks to which operators and supervisors have access. The following summary shows only those menu blocks of the service level in the menu “SCALE”. The rest of the menu is described in the operating instructions.
  • Page 8: Admissibility For Certification (Scale -> Metrology)

    Chapter 3: Configuring the terminal Admissibility for certification ( SCALE –> Metrology ) Display Remarks Setting the admissibility for certification: MEtROLO Scale not certifiable. NO APPr ▼ Scale certifiable to OIML. OIML Caution: When a scale is declared certifiable, then certain settings are no longer available.
  • Page 9: Entering The Configuration Data (Scale -> Scale Build)

    Chapter 3: Configuring the terminal Entering the configuration data ( SCALE –> Scale Build ) Display Remarks Entering configuration data SCAL.bLd Defining the type of scale ––> chapter 3.8.1 SCAL.tYP Specifying the basic units ––> chapter 3.8.2 bAS.UNIt Specifying the capacity of the weighing system ––>...
  • Page 10: Setting The Scale Capacity (Scale -> Scale Build -> Scale Capacity)

    Chapter 3: Configuring the terminal Setting the scale capacity ( SCALE –> Scale Build –> Scale Capacity ) 3.8.3 Display Remarks Entering the scale capacity (in the preset basic unit). SCL.CAP For KMT-TM terminals, the capacity can be entered via the numeric keyboard. For 000015.0 kg KMB-TM / KMS-TM terminals, press the key.
  • Page 11: Linearization With Calibration (Scale -> Lin-Cal)

    Chapter 3: Configuring the terminal 3.10 Linearization with calibration ( SCALE –> Lin-Cal ) Display Remarks Linearizing the scale system with simultaneous calibration. LIN - CAL Calibration is carried out purely theoretically to compensate for shifts in the full load when linearizing. The loads applied are checked (±5%) and thus a basic calibration must first be carried out (chapter 3.11).
  • Page 12: Basic Calibration (Scale -> Cal)

    Chapter 3: Configuring the terminal 3.11 Basic calibration ( SCALE –> Cal ) Display Remarks The basic calibration corresponds to the calibration function for the user (however, the user cannot set the preload). Apply the preload and confirm with the key.
  • Page 13: Setting The Zero Capturing Range (Scale -> Zero -> Zero Capture)

    Chapter 3: Configuring the terminal 3.13.1 Setting the zero capturing range ( SCALE –> Zero –> Zero Capture ) Display Remarks Setting the zero capturing range (when switching on and via the key). Z - CAPt Zero capturing range –2% to +18% - 2 18 Zero capturing range –2% to +2% (mainly for certifiable scales) ▼...
  • Page 14: Table Of Geo Values

    Chapter 4: Table of Geo values Table of Geo values Height above sea level in meters 1300 1625 1950 2275 2600 2925 3250 Northern or southern 1300 1625 1950 2275 2600 2925 3250 3575 geographical latitude Height above sea level in feet in degrees and minutes 1060 2130...
  • Page 15: Setting Up A Weighing System And Technical Data

    Chapter 5: Setting up a weighing system and technical data Setting up a weighing system and technical data Before setting up a weighing system with the terminal, its basic data must first be determined. These data are to be entered into the service level of the menu (chapter 3).
  • Page 16 Chapter 5: Setting up a weighing system and technical data How do I set up my scale? Application: Scale parameters: – simple weighing – > KMB-TM – heaviest weight? – simple counting – > KMS-TM – weight of pan holder? –...
  • Page 17: Measuring Ranges Of The Terminal

    Chapter 5: Setting up a weighing system and technical data Measuring ranges of the terminal When setting up a weighing system, consider the measuring ranges of the terminal according to the summary given below. a: Total preload applied to weighing Total capacity of weighing cell(s) cell when calibrating (upper part of platform, weighing pan, roller track,...
  • Page 18: Technical Data

    Chapter 5: Setting up a weighing system and technical data Technical data Only those specifications needed for using this installation information are shown below. The other technical data are given in the operating instructions. Data for the terminal Resolution 300 000 points for non-certifiable applications 7 000 points for certifiable applications Weighing ranges Up to 3 weighing ranges defined in the menu, incl.
  • Page 19: Event And Error Messages

    Chapter 6: Event and error messages Event and error messages Overload: Reduce the load on the scale or reduce the preload. gjjjjh Underload: Place the weighing pan on the scale and ensure it can move freely. eiiiif iiiiii Result not stable: Always appears when not stable (when zeroing, taring, etc.). If the scale still does not become stable after a long time, check the environmental conditions.
  • Page 20 KERN & Sohn GmbH D-72322 Balingen-Frommern Tel: 0049-[0]7433- 9933-0 Postfach 4052 Fax: 0049-[0]7433-9933-149 E-Mail: info@kern-sohn.de Internet: www.kern-sohn.de Konformitätserklärungen Declaration of conformity for apparatus with CE mark Konformitätserklärung für Geräte mit CE-Zeichen Déclaration de conformité pour appareils portant la marque CE Declaración de conformidad para aparatos con marca CE...
  • Page 21 Scale Series: BTEP Mark applied EU Directive Standards Approval/ Test- certificate N° 73/23/EEC EN60950-1 93/68/EEC Low Voltage 89/336/EEC EN61326-1 Kl.B 93/68/EEC EN61000-3-2 92/31/EEC EN61000-3-3 90/384/EEC EN45501 T7092 1) 93/68/EEC TC7091 1) [year] 1) [code] M Non automatic weighing instruments 1) applies only to certified balances gilt nur für geeichte Waagen valable uniquement pour les balances vérifiées...
  • Page 22 Bij weegschalen met een analoge weegbruggenaansluiting moet aanvullend de nauwkeurigheid overeenkomstig EN45501- 3.5.3.3 getest worden. Deze controle is niet nodig als de terminal het serienummer van de weegbrug heeft. Date: 03.01.2007 Signature: Gottl. KERN & Sohn GmbH Management Gottl. KERN & Sohn GmbH, Ziegelei 1, D-72336 Balingen, Tel. +49-[0]7433/9933-0,Fax +49-[0]7433/9933-149...
  • Page 23 Notice Certified balances and balances used for legal applications have the EU type approval. The year of the initial verification is shown next to the CE mark. Such balances are verified in the factory and carry the „M“ mark on the actual balance and the packaging. The year of initial verification is shown next to the CE mark.
