Operating and Installation
Instructions Display Unit
KERN KXS/KXG-TM
Version 2.2
2017-12
GB
KERN & Sohn GmbH
Ziegelei 1
D-72336 Balingen
E-Mail:
info@kern-sohn.com
KXS/KXG-TM-BA_IA-e-1722
Phone: +49-[0]7433- 9933-0
Fax: +49-[0]7433-9933-149
Internet:
www.kern-sohn.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KXS-TM and is the answer not in the manual?

Questions and answers

Related Manuals for KERN KXS-TM

Summary of Contents for KERN KXS-TM

  • Page 1 KERN & Sohn GmbH Ziegelei 1 Phone: +49-[0]7433- 9933-0 D-72336 Balingen Fax: +49-[0]7433-9933-149 E-Mail: info@kern-sohn.com Internet: www.kern-sohn.com Operating and Installation Instructions Display Unit KERN KXS/KXG-TM Version 2.2 2017-12 KXS/KXG-TM-BA_IA-e-1722...

  • Page 2: Table Of Contents

    Display unit Contents Technical data ....................5 Appliance overview ................... 6 Keyboard overview ....................7 2.1.1 Models KXS-TM: ........................ 7 2.1.2 Models KXG-TM: ....................... 8 Overview of display ....................10 Basic Information (General) ................12 Proper use ........................12 Improper Use ......................12 Warranty ........................12...
  • Page 3 Applications: ....................21 Parts counting ......................21 Totalization .......................23 Menu ......................... 27 Indicator settings (menu block "01 FnC") ..........28 10.1 Backlighting of the display (function "FnC 01") ............31 10.2 Automatic power cut "Auto power off (function „FnC 02“) ..........32 10.3 Weighing with tolerance range (function "FnC 03 „) ..........33 10.4 Resetting to factory settings (function "FnC 04 „) ............37...
  • Page 4 Service menu ....................80 19.1 Configure weighing system / menu block ..........82 19.1.1 Unverified weighing systems (function „CSP 01”) ............83 19.1.2 Verified balancing systems (function "CSP 02“) ............87 19.1.3 Set the buffeting point (function „CSP 03“) ..............91 19.2 Linearization/ menu block ..............93...

  • Page 5: Technical Data

    1 Technical data KERN KXS-TM KXG-TM Display 6-digit Single (Max.) 10,000 e Solution verifiable Dual (Max.) 5,000 e Resolution non-verifiable 30,000 d Verification class Weighing ranges Max. 2 Weighing Units g, kg Divisions 1,2,5,…10, n Display LCD 55 mm digits with back lighting DMS weighing cells Max.

  • Page 6: Appliance Overview

    2 Appliance overview Wireless Status of rechargeable battery Wall bracket Locking screw Display Keyboard Electric Supply RS 232 / RS485 (Factory option) Connection to the load cell KXS/KXG-TM-BA_IA-e-1722...

  • Page 7: Keyboard Overview

    2.1 Keyboard overview 2.1.1 Models KXS-TM: Button Description Function 1. Turn on/off ON/OFF button • Functional button (allocation see chap. 10.1 FNC-03) F-key • Gross weight  switch over to net weight BG/ NET key • Weighing unit UNIT-key • Taring •...

  • Page 8: Models Kxg-Tm

    2.1.1.1 Navigation keys and their function in the menu • Increase flashing digit  • Scroll forward in menu • Decrease flashing digit  • Scroll backwards in menu • Digit selection to the right  • Take over selected setting Digit selection to the left ...
  • Page 9 • Gross weight  switch over to net weight BG/ NET key • Weighing unit UNIT-key • Taring • Confirm entry TARE button • Zeroing ZERO key • Functional button (allocation see chap. 10.1 FNC-02) M+/ PRINT key 2.1.2.1 Navigation keys and their function in the menu •...

  • Page 10: Overview Of Display

    2.2 Overview of display HI / OK / LO Indicators for weighing with tolerance range Current selected unit of weight „kilograms“ Current selected unit of weight „pound“ Indicator for counting Zero indicator The displayed weighing value is a net weighing value Status of rechargeable battery KXS/KXG-TM-BA_IA-e-1722...
  • Page 11 Non verified weighing systems: Indicator [] next to symbol displays: that the weight value is stable  that the displayed weighing value is a gross weight value  GROSS that the balance is set to unit counting mode   PRE- that a PRE-TARE value is stored TARE...

  • Page 12: Basic Information (General)

    The display unit may only be operated in accordance with the described default settings. Other areas of use must be released by KERN in writing. 3.3 Warranty Warranty claims shall be voided in case •...

  • Page 13: Monitoring Of Test Resources

    In KERN’s accredited DKD calibration laboratory test weights and display units may be calibrated (return to the national standard) fast and at moderate cost.

  • Page 14: Unpacking And Placing

    6 Unpacking and placing 6.1 Installation Site, Location of Use The display units are designed in a way that reliable weighing results are achieved in common conditions of use. Precise and fast work is achieved by selecting the right place for your display unit and your weighing plate.

  • Page 15: Transport Securing

    6.4 Transport Securing Remove the transportation safety device at the four marked positions: Transport Securing Placing Mount the display unit in a way that facilitates operation and where it is easy to see. In order to raise the display, the display device can be mounted on an optional stand.

  • Page 16: Adjustment

    6.8 Adjustment As the acceleration value due to gravity is not the same at every location on earth, each display unit with connected weighing plate must be coordinated - in compliance with the underlying physical weighing principle - to the existing acceleration due to gravity at its place of location (only if the weighing system has not already been adjusted to the location in the factory).
  • Page 17 Sealing: KXS/KXG-TM-BA_IA-e-1722...

  • Page 18: Basic Operation

    7 Basic Operation 7.1 Start-up  Press on/ off key, the equipment completes a self check. As soon as the weight display appears, the instrument will be ready to weigh. 7.2 Switching Off  Press the on/ off key approx. 3 seconds, the display will turn off. 7.3 Zeroing Resetting to zero corrects the influence of light soiling on the weighing plate.

  • Page 19: Switch-Over Weighing Unit

    7.5 Switch-over weighing unit  Press the UNIT-key The weight gauge changes between „kg“and "g". 7.6 Weighing with tare After taring no numeric input of a tare weight can follow. After the numeric input of a tare weight, the system can only be tared if „tare weight >...

  • Page 20: Numerical Input Of Tare (Pre-Tare)

    7.6.3 Numerical input of tare (PRE-TARE) The known dead weight of a weighing container can be tared off by entering its weight as pre-tare deduction in order to ensure the net weight of the goods to be weighed in subsequent weighings is always displayed. ...

  • Page 21: Applications

    8 Applications: 8.1 Parts counting Before the balance can count parts, it must know the average part weight (i.e. reference). Proceed by putting on a certain number of the parts to be counted. The balance determines the total weight and divides it by the number of parts, the so- called reference quantity.
  • Page 22 Switch between number of items and weight With the UNIT key you can switch between number of items and weight: By switching the scale off and then on again the scale starts in the unit counting mode. The current reference weight remains stored until the reference is set again or the power supply is interrupted.

  • Page 23: Totalization

    F_M 11 (M+ accumulating mode 2): Total = sum of net weight of each weight Total = Sum of gross weight of each weight reading reading Printout example (KERN YKB-01N) Printout example (KERN YKB-01N) 1. Weighing 1. Weighing 2. Weighing 2.
  • Page 24 Add up:  Place weighing good A, e.g. 5 kg. Wait for stability, then press M + / PRINT key. . The weight is added to the accumulative memory and printed if an optional printer is connected. The number of weighings, followed by the total weight will be indicated. The indicator  above M+ shows.
  • Page 25  Place goods to be weighed, e.g. 7 kg. Wait for stability then press the M+/PRINT, it calculates. The weight value is added to the accumulative memory and given out when connecting an optional printer. Number of weighings, followed by the total weight will be displayed for 2 sec.
  • Page 26 Display and output sum „Total“:  When the scale is unloaded (zero indicator) press the M+/PRINT key, the number of weight readings followed by the total weight are indicated for 2 seconds. Press M+/PRINT to print out this display. Delete accumulative memory: 1.

  • Page 27: Menu

    9 Menu The menu consists of the following blocks: Settings of the display device External adjustment Settings of the interface Exit menu / back to weighing mode. Access to menu:  In the weighing mode press the BG/NET and ZERO key simultaneously, "01 FnC" is indicated.

  • Page 28: Indicator Settings (Menu Block "01 Fnc")

    10 Indicator settings (menu block "01 FnC") Access to menu:  In the weighing mode press BG/ NET and ZERO key simultaneously "01 FnC" is indicated, see chapter 9. Keys and their function in the menu: • Increase flashing digit ...
  • Page 29 Exit menu / back to weighing mode:  Leave the example function "FnC 01"  Select with the navigation keys "FNC 00” and confirm with TARE key. KXS/KXG-TM-BA_IA-e-1722...
  • Page 30 Overview: Exit menu FnC 00 Display background illumination FnC 01 Automatic power switch-off FnC 02 Weighing with tolerance range / set limit values FnC 03 Reset to default setting FnC 04 Automatic zero tracking / stability and response settings FnC 05 Data-Hold function FnC 06 Automatic reference optimization with counting of items...

  • Page 31: Backlighting Of The Display (Function "Fnc 01")

    10.1 Backlighting of the display (function "FnC 01")  Call up function "FnC 01", see chapter 10 „Navigation in the menu“.  Press the TARE-key , the current setting for the back lighting of the display is indicated.  Select desired settings with TARE or UNIT key. Display background illumination off bl off Starting from a weight >...

  • Page 32: Automatic Power Cut "Auto Power Off (Function „Fnc 02")

    10.2 Automatic power cut "Auto power off (function „FnC 02“)  Call up function "FnC 02", see chapter 10 "Navigation in the menu”.  Press the TARE-key, current setting appears.  Select desired settings with TARE or UNIT key. Function switched off A off0 A off1 The indicator is switched off automatically within the adjusted time,...

  • Page 33: Weighing With Tolerance Range (Function "Fnc 03 „)

    10.3 Weighing with tolerance range (function "FnC 03 „) You can set an upper or lower tolerance limit when weighing with tolerance range and thus ensure that the weighed load remains exactly within the set tolerance limits. Tolerance checks such as dosing, portioning and sorting the display above or below the tolerance levels with a visual and acoustic signal (depending on the setting in the menu).
  • Page 34 Settings:  Call up function "FnC 03", see chapter 10 "Navigation in the menu“.  Press the TARE key, the current settings of the upper tolerance is indicated.  With the navigation keys (see chapter XX) enter the desired value e.g. 3 kg. ...
  • Page 35  Press the TARE key until the display for the settings of the audio signal appears. The current setting will be displayed.  With the navigation keys (see chapter 2.1.1) select the desired setting. Settings of audio signal: Selectable mode Description 1 = Audio signal switched on (a) ⇒...
  • Page 36 Weighing with tolerance range:  Tare when using a weighing container.  Put on goods to be weighed, tolerance control is started. The indicators show whether the load is within the two set tolerance limits. Load below specified Load within specified Load exceeds specified tolerance tolerance...

  • Page 37: Resetting To Factory Settings (Function "Fnc 04 „)

    10.4 Resetting to factory settings (function "FnC 04 „) The following functions are reset to factory setting with "FnC 04 „. 1. External adjustment weight 2. Settings for weighing with tolerance range 3. Filter settings 4. Settings of number of items ...

  • Page 38: Automatic Zero-Adjusting/ Stability And Response Settings (Function "Fnc 05")

    10.5 Automatic zero-adjusting/ stability and response settings (function "FnC 05“) This function is only available for unverified weighing systems (CFn 02 = 0), for verified weighing systems see chapter 19.5.1.  Call up function "FnC 05", see chapter 10 "Navigation in the menu“. ...
  • Page 39 FiL 0 The higher the value, the more priority is given to stability.  You can select 0-9. Factory setting "0". FiL 9  Confirm with the TARE key, the current response level is displayed. The higher the value, the more priority is given to response. 3 db 0 You can select 0-9.

  • Page 40: Data Hold Functions (Function "Fnc 06")

    10.6 Data Hold functions (function "FnC 06“) With verified balancing systems (Cfn 02 = 1) the setting „hold = 0“ cannot be altered with the function „FnC 06“ (changes are possible with function "CFn 05" see chapter 19.5.4.).  Call up function "FnC 06", see chapter 10 "Navigation in the menu“. ...

  • Page 41: Animal Weighing Function

     Confirm with the TARE key, the display returns back to the menu.  Return to weighing mode function, see chap. 10. 10.6.1 Animal weighing function With this function jerky balancing goods can be weighed, e.g. living animals. The scale calculates an average value by the number of adjusted weighings and displays this until the scale is cleared (display <...
  • Page 42  Press the TARE key repeatedly until the current setting "number of weight readings" is indicated. Number of weight readings, which are consulted for the average value  calculation, you can select 1, 2, 4, 8, 16, 32, 64. Factory setting "8“...
  • Page 43 From now on the scale is in animal weighing mode. Animal weighing: When the animal weighing function is activated horizontal segments appear at the zero display.  Place goods to be weighed on the balance. The scale calculates the average value by the number of adjusted weight readings.
  • Page 44 Return to weighing mode:  In the weighing mode press the BG/NET and ZERO key simultaneously, "01 FnC" is indicated. Press the TARE key, „FNC 00” is indicated.  Select „FnC 00“ with the navigation keys and confirm with the TARE key. „hold 4“ is indicated.
  • Page 45 KXS/KXG-TM-BA_IA-e-1722...

  • Page 46: Automatic Reference Optimisation With The Unit Count (Function „Fnc 07")

    10.7 Automatic reference optimisation with the unit count (function „FnC 07“)  Call up function „FnC 07“, see chapter 10 "Navigation in the menu“.  Press the TARE-key, current setting appears.  Select desired settings with TARE or UNIT key. No reference optimisation AvErG 0 Reference optimisation is activated.

  • Page 47: Automatic Storage Of Zero Point (Function "Fnc 10")

    10.8 Automatic storage of zero point (function "FnC 10“) This function is only available for unverified weighing systems (CFn 02 = 0).  Call up function "FnC 10", see chapter 10 "Navigation in the menu“.  Press the TARE-key, current setting appears. ...

  • Page 48: Function Of The F-Key (Function „Fnc 12")

    10.9 Function of the F-key (function „FnC 12“)  Call up function "FnC 12", see chapter 10 "Navigation in the menu“.  Press the TARE-key, current setting appears.  Select desired settings with TARE or UNIT key. 3 different functions can be assigned to the F-key: The accumulative memory is cleared when the F-key is pressed.

  • Page 49: Auto Zero

    10.10 Auto Zero This function is used to tare small variations in weight automatically. In the event that small quantities are removed or added to the material to be weighed, incorrect weighing results can be displayed due to the “stability compensation“.

  • Page 50: External Adjustment "Unverified Weighing Systems

    Prepare the required adjustment weight. The weight to be used depends on the capacity of the scale. Carry out adjustment as near as possible to the scale’s maximum weight. Info about test weights can be found on the Internet at: http://www.kern-sohn.com. • Observe stable environmental conditions. Stabilisation requires a certain warm-up time.
  • Page 51  Ensure that there are no objects on the weighing pan. Press the TARE key. The weight value of the required adjustment weight will be displayed.  Carefully place the adjusting weight into the centre of the balancing plate and press the TARE key.
  • Page 52 Return to weighing mode: KXS/KXG-TM-BA_IA-e-1722...

  • Page 53: Settings Rs 232 (Menu Block "03 Rs1")

    12 Settings RS 232 (menu block "03 rS1”) Access to menu:  In the weighing mode press the BG/NET and ZERO key simultaneously, "01 FnC" is indicated. Select "03 rS1" with the navigation keys. Call up the navigation in the menu/ function: Press TARE key Select the function with navigation keys...
  • Page 54 Keys and their function in the menu: see chap. 10 Exit menu / back to weighing mode:  For example to leave function "rS1 01"  Select "rS1 00" with the navigation keys and confirm with the TARE key. KXS/KXG-TM-BA_IA-e-1722...
  • Page 55 Overview: Exit menu rS1 00 Baud rate rS1 01 Parity rS1 02 Output format rS1 03 Output mode rS1 04 Continuous output rate rS1 05 Automatic data output with zero display. rS1 06 Not documented (Factory setting “0”) rS1 07 Set output stable/instable weighing values rS1 08 6 /7 -digit data format...

  • Page 56: Baud Rate (Function "Rs1 01")

    12.1 Baud rate (function "rS1 01“)  Call up function "rS1 01", see chapter 12.  Press the TARE-key, current setting appears.  Select desired settings with TARE or UNIT key. b600 You can select 600/1200/2400/4800/9600 (bit/ second)  b19200 ...

  • Page 57: Parity (Function "Rs1 02")

    12.2 Parity (function "rS1 02“)  Call up function "rS1 01", see chapter 12.  Press the TARE-key, current setting appears.  Select desired settings with TARE or UNIT key. No parity, 8 bits, 1 stop bit P n81 Even parity 7 bits, 1 stop bit P E71 Odd parity, 7 bits, 1 stop bit P o71...

  • Page 58: Output Format (Function "Rs1 03")

    12.3 Output format (function "rS1 03“)  Call up function "rS1 01", see chapter 12.  Press the TARE-key, current setting appears.  Select desired settings with TARE or UNIT key. Display value with status F_M 00 Sample printout: Factory settings ST, G + 1.000 kg Gross weight with status...
  • Page 59 Hi /Lo/ OK status + display value without status F_M 06 sample printout: 001+ 2.000 Lo (001) 010+ 3.000 OK (010) 100+ 4.000 Hi (100) Hi /Lo/ OK status + gross weight without status F_M 07 Hi/ Lo/ Ok status + net weight without status F_M 08 Tare weight F_M 09...

  • Page 60: Output Format (Function „Rs1 04")

    12.4 Output format (function „rS1 04“)  Call up function "rS1 04", see chapter 12.  Press the TARE-key, current setting appears.  Select desired settings with TARE or UNIT key. Data output via remote control commands Comand Continuous output Stream Automatic issue of first stable weighing value Auto...

  • Page 61: Continuous Output Rate (Function „Rs1 05")

    12.5 Continuous output rate (function „rS1 05“)  Call up function "rS1 05", see chapter 12.  Press the TARE-key, current setting appears.  Select desired settings with TARE or UNIT key. rPS 1 Data transmission rate 1, 2, 4, 8, 16 times/ second ...

  • Page 62: Automatic Data Output With Zero Display (Function "Rs1 06")

    12.6 Automatic data output with zero display (function "rS1 06“)  Call up function "rS1 06", see chapter 12.  Press the TARE-key, current setting appears.  Select desired settings with TARE or UNIT key. Range, below which appliance has to go before the scale prints, -b 00 you can select 0 - 99 division steps.

  • Page 63: Condition For Data Output (Function "Rs1 08")

    12.7 Condition for data output (function "rS1 08”)  Call up function "rS1 08", see chapter 12.  Press the TARE-key, current setting appears.  Select desired settings with TARE or UNIT key. Output only with stable weight values Stb-P (no output with unstable weight values and "OL „) Factory setting Output only for stable weight values (including „OL“)

  • Page 64: 6/ 7-Digit Data Format (Function "Rs1 09")

    12.8 6/ 7-digit data format (function "rS1 09”)  Call up function "rS1 09", see chapter 12.  Press the TARE-key, current setting appears.  Select desired settings with TARE or UNIT key. S iII 6 Digits Factory setting 7 Digits SEvEn ...

  • Page 65: Set The Date/ Time (Function "Rs1 10")

    12.9 Set the date/ time (function "rS1 10“)  Call up function "rS1 09", see chapter 12.  Press the TARE-key, current setting appears.  Set the date with TARE or UNIT key.  Press the TARE key repeatedly until the last digit flashes, the display for the time setting appears.
  • Page 66  Set the date format (function "rS1 11“)  Call up function "rS1 11", see chapter 12.  Press the TARE-key, current setting appears.  Select desired settings with TARE or UNIT key. Year/ month/ day y_m_d Day/Month/Year d _m_j ...
  • Page 67  RS 485 ID input (function "rS1 12“)  Call up function "rS1 12", see chapter 12.  Press the TARE-key, current setting appears.  Select desired settings with TARE or UNIT key. ID input, you can select 0 - 99 Id 00 With the input „ID 00“...

  • Page 68: Instruction Mode

    13 Instruction mode RS 485:  During input „Id 00“(function RS1 12, see chapter 12.12) the instruction format is the same as with RS232.  During input "ID 01-99“ "@ID „must be placed in front of the remote control command, so that the respective scale reacts to the instruction; e. g. to set the scale to zero with ID 99 the instruction must be sent to "@99MZ“...
  • Page 69 Hi /Lo/ OK status + display value without status Example: Hi/ Lo/ OK status Sample display Lo (001) 001+ 2.000 OK (010) 010+ 3.000 Hi (100) 100+ 4.000 Hi/Lo/ OK status + gross weight without status (example see "RJ"). Rear one/ Lo/ OK status + net weight without status (example see "RJ"). Show tolerance limit RS...

  • Page 70: Data Output Format

    14 Data output format 14.1 7-digit data format (first decimal place not included) Weight value with status Gross Tare Plus OL Minus OL Unstable Weight value without status G / N G / N G / N Plus OL Minus OL Hi /Lo/ OK status + display value without status: Byte0 Byte1 Byte2 +/- Byte0: HI 30H / 31H...

  • Page 71: Bluetooth (Factory Option)

    15 Bluetooth (Factory option) Click in the task border with activated Bluetooth.  Click on „Add device“.  KXS/KXG-TM-BA_IA-e-1722...
  • Page 72  Click on "Enter pairing code of the device"   Enter code 1111 KXS/KXG-TM-BA_IA-e-1722...
  • Page 73  Click on „Next“  Click on „Close“ KXS/KXG-TM-BA_IA-e-1722...
  • Page 74  Display Bluetooth network appliance  Double click KXS/KXG-TM-BA_IA-e-1722...

  • Page 75: Servicing, Maintenance, Disposal

     Do not use metal brushes or cleaning sponges of steel wool, as this causes superficial corrosion. 16.2 Servicing, maintenance  The appliance may only be opened by trained service technicians who are authorized by KERN.  Ensure that the balance is regularly calibrated, see chap. Monitoring of test resources. 16.3 Disposal ...

  • Page 76: Instant Help

    17 Instant help In case of an error in the program process, briefly turn off the display unit and disconnect from power supply. The weighing process must then be restarted from the beginning. Help: Fault Possible cause The displayed weight does •...

  • Page 77: Installation Display Appliance/ Load Cell

    18 Installation display appliance/ load cell Installation / configuration of the weighing system must be carried out by a well acquainted specialist with the workings of weighing balances. 18.1 Weighing system design The display unit is suitable for connection to any analogue platform in compliance with the required specifications.

  • Page 78: Attach The Load Cell

    18.2 Attach the load cell  Disconnect the display unit from the power supply.  Attach the load cell cables according to the following illustration. 4-wire load cells: When using 4-wire load cells SEN + and SEN - must not be connected. 6-wire load cells: KXS/KXG-TM-BA_IA-e-1722...

  • Page 79: Attach Rs232

    18.3 Attach RS232 KXS/KXG-TM-BA_IA-e-1722...

  • Page 80: Service Menu

    19 Service menu Verified weighing systems: • In verified weighing systems the access to the service menu is locked. , the sealing must be destroyed (see chapter 6.9) In order to unlock the access and the housing opened. On the plate move the adjusting switch SWA1 to position „ADJ”.
  • Page 81 The service menu consists of the following blocks: Configure the weighing system, see chapter 19.1 Adjustment of verified weighing systems, see chapter 19.3 For linearisation see chapter 19.2 Appliance settings of verified weighing systems, see chapter 19.5 Alter the gravitation zone, see chapter 19.4 Navigation: KXS/KXG-TM-BA_IA-e-1722...

  • Page 82: Configure Weighing System / Menu Block

    19.1 Configure weighing system / menu block  Call up the menu block , see chapter 19. Call up the navigation in the menu/ function: Press TARE key Select function using navigation keys, (CSP 00  CSP 03) Back to menu: Select function "CSP 00"...

  • Page 83: Unverified Weighing Systems (Function „Csp 01")

    19.1.1 Unverified weighing systems (function „CSP 01”) Menu setting „unverified” CFN 02 = 0, see chapters. 19.5.2.  Call up function "CSP 01", see chapter 19.1 "Navigation in the menu“.  Press the TARE key, the current set capacity / resolution is displayed for 2 seconds (display sample Max 15 kg / d 0.01 kg), followed by the display of "u00000"...
  • Page 84  Use the navigation buttons to select desired settings Example 020002: Standard weighing unit "kg“ (a), second weighing unit "lb“ (b), number of weighing units "2“  Confirm with TARE key, the display "C00000“ appears on the input capacity (max). Example 015000 15.000kg ⇒...
  • Page 85 Settings: Description Readability (d), select from 1, 2, or 5 steps (m) ⇒ Number of decimal places, select from 0 ~ 5 (n) ⇒ Examples: Adjustment 15.000 kg 1500.0 g 6.000 lb (o) ⇒ 0 , 1 ⇒ Single-range balance ⇒...
  • Page 86 Example 132000: Readability 1 step 1 ⇒ 3 decimal places 3 ⇒ 2 ⇒ Divide into maximum of two sections 0 ⇒ Multi-interval balance ultiplication factor Division m 0 ⇒  Press the TARE key, the newly set capacity / resolution is displayed for 2 seconds (display sample maximum 15 kg / d 0.001 kg).

  • Page 87: Verified Balancing Systems (Function "Csp 02")

    19.1.2 Verified balancing systems (function "CSP 02“) For menu settings "verified" CFN 02 = 1, see chapter. 19.5.2.  Call up function "CSP 02", see chapter 19.1 "Navigation in the menu“.  Press the TARE key, the current set capacity / resolution is displayed for 2 seconds (display sample Max 15 kg / d 0.01 kg), followed by the display of "unit"...
  • Page 88  Use the navigation buttons to select desired settings Example unit 20: Number of balancing units "2“ (a), standard weighing unit „kg“(b),  Confirm with TARE key, the current standard weighing unit is indicated for 2 seconds (e.g. „kg“) followed by the display „000001“...
  • Page 89 Example 015000 15.000kg ⇒  Confirm with the TARE key, the display "000003" appears for the input of "resolution (d), decimal places and type of scale". Settings: Description Readability (d), select from 1, 2, or 5 steps (o) ⇒ Number of decimal places, select from 0 ~ 5 (p) ⇒...
  • Page 90 Example 530010: Readability of 5 steps 5 ⇒ 3 decimal places d = 0.005 3 ⇒ Standard weighing unit „kg“ 0 ⇒ Single-range balance 0 ⇒ Sequence of the weighing units 1 ⇒ 0 ⇒ Multi-interval balance  Press the TARE key, the newly set capacity / resolution is displayed for 2 seconds (display sample maximum 15 kg / d 0.005kg).

  • Page 91: Set The Buffeting Point (Function „Csp 03")

    19.1.3 Set the buffeting point (function „CSP 03“) With the functions „CSP 01” and „CSP 02” the weighing range, by default, can be divided into:  Single-range balance  Divide into maximum of two sections (subranges ½ max)  Divide into maximum of three sections (subranges 1/6 and 2/3 max) Call up function „CSP 03”...
  • Page 92  Confirm with the TARE key, the current set second buffeting point (only during allocation into 3 sections) is indicated.  Use the navigation keys to select the desired settings  Confirm with the TARE key, the display returns back to the menu. ...

  • Page 93: Linearization/ Menu Block

    19.2 Linearization/ menu block Linearity shows the greatest deviation of a weight display on the scale to the value of the respective test weight according to plus and minus over the entire weighing range. If linearity deviation is discovered during a monitoring of test resources, you can improve this by means of linearization.
  • Page 94 6. When „L3 1“ is displayed, place the third adjustment weight carefully in the centre of the weighing plate. Enter the desired factor, by which the following adjusting weight is to increase, with the navigation keys. Press the TARE key. 7.
  • Page 95 Setting "factor” All weight values are equal The following weight value is twice as high as the first. The following weight value is three times higher than the first ….5 times… ….6 times… ….7 times… ….8 times… ….9 times… ….10 times… ….11 times…...
  • Page 96 Example 4: 5-point linearization/ 30 kg (5kg, 5kg, 10 kg, 10kg) Display Button Explication 03 CLn TARE Linearization function TARE zero point TARE First adjustment weight (5 kg) TARE Second adjustment weight (5kg), factor 1, i.e., the same size as the first TARE Third adjustment weight (10 kg);...

  • Page 97: Adjustment Of "Verified Weighing Systems / Menu Block

    Prepare the required adjustment weight. The weight to be used depends on the capacity of the scale. Carry out adjustment as near as possible to the scale’s maximum weight. Info about test weights can be found on the Internet at: http://www.kern-sohn.com. • Observe stable environmental conditions. Stabilisation requires a certain warm-up time.
  • Page 98 Perform external adjustment / function "CAL 01":  Call up function "CAL 01”  Press the TARE button, the currently set adjustment weight is displayed. The last digit flashes. To change the adjustment weight select the digit to be changed with BG/ NET key, the active digit flashes.
  • Page 99  Carefully place the adjusting weight into the centre of the balancing plate and press the TARE key. After successful adjustment, an acoustic signal sounds.  Remove the adjustment weight. Press any key, the scale will return to the menu.. ...

  • Page 100: Amend The Local Gravitation Zone/ Menu Block

    19.4 Amend the local gravitation zone/ menu block  Call up function , see chapter 19. Press TARE key The current setting will be displayed. Using the navigation buttons, enter the local gravitational zone. Confirm with the TARE key, the display returns back to the menu.

  • Page 101: Appliance Settings/ Menu Block

    19.5 Appliance settings/ menu block Call up the navigation in the menu/ function:  Call up function , see chapter 19. Press TARE key Using the navigation keys, select function, (CFn 00  CFn 07) Back to menu: Select function "CFn 00"...

  • Page 102: Parameter „Adjustment To Site Conditions" (Function „Cfn 01")

    19.5.1 Parameter „adjustment to site conditions“ (function „CFn 01”) In the case of change to the settings in CFn 01 the settings in FNC 05 are automatically overwritten, see chapter 10.5.  Call up function „CFn 01“, see chapter 19.5. ...

  • Page 103: Kxs/Kxg-Tm-Ba_Ia-E

    FiL 0 The higher the value, the more priority is given to stability.  You can select 0 - 9. Factory setting "0". FiL 9  Confirm with the TARE key, the current response level is displayed. The higher the value, the more priority is given to response. 3 db 0 You can select 0-9.
  • Page 104  Confirm with the TARE key, the display returns back to the menu.  With the navigation keys (see chapter 2.1.1) Select "CFn 00".  Confirm with TARE key.  To exit the menu, move the adjustment switch into the „LOCK“...

  • Page 105: Configuration „Verified/ Unverified" (Function „Cfn 02")

    19.5.2 Configuration „verified/ unverified“ (function „CFn 02“)  Call up function „CFn 02“, see chapter 19.  Press the TARE-key, current setting appears.  With the navigation keys (see chapter 2.1.1) select the desired setting. 0 ⇒ Non verified models 1 ⇒...

  • Page 106: Resetting To Zero When Switched On (Function "Cfn 04")

    19.5.3 Resetting to zero when switched on (function "CFn 04“)  Call up function „CFn 04“, see chapter 19.  Press the TARE-key, current setting appears.  With the navigation keys (see chapter 2.1.1) select the desired setting. Zero setting when switching on within ±...

  • Page 107: Amend The Data Hold Function Of Verified Weighing System (Function „Cfn 05")

    19.5.4 Amend the DATA Hold function of verified weighing system (function „CFn 05“)  Call up function „CFn 05“, see chapter 19.  Press the TARE-key, current setting appears.  Select desired settings with TARE or UNIT key. Function switched off (factory setting) hold 0 Peak value function hold 1...
  • Page 108  Confirm with the TARE key, the display returns back to the menu.  With the navigation keys (see chapter 2.1.1) Select "CFn 00".  Confirm with TARE key.  To exit the menu, move the adjustment switch into the „LOCK“...

  • Page 109: Auto Zero (Verified Weighing Systems)/ Function "Cfn

    19.5.5 Auto zero (verified weighing systems)/ function "CFn 06“  Call up function „CFn 05“, see chapter 19.  Press the TARE-key, current setting appears.  Select desired settings with TARE or UNIT key. Function switched off When the balance is cleared the zero point is corrected automatically. ...

  • Page 110: Parts Counting On / Off „Cfn 07

    19.5.6 Parts counting on / off „CFn 07“  Call up function „CFn 07“, see chapter 19.  Press the TARE-key, current setting appears. (PCS off / PCS on).  Select desired settings with TARE or UNIT key. Parts counting disabled PCS off Parts counting enabled PCS on...

  • Page 111: Declaration Of Conformity

    20 Declaration of Conformity To view the current EC/EU Declaration of Conformity go to: www.kern-sohn.com/ce The scope of delivery for verified weighing balances (= conformity- rated weighing balances) includes a Declaration of Conformity. KXS/KXG-TM-BA_IA-e-1722...

This manual is also suitable for:

Kxg-tm

Table of Contents
