User Manual of 10KG

10KG Winch for Drone

User Manual

Need help?

Do you have a question about the Eayload Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Foxtech Eayload Series

Page 1 User Manual of 10KG 10KG Winch for Drone User Manual...
Page 2 User Manual of 10KG Content I. Disclaimer ..................................2 II. Precautions ................................3 III. Product Overview ..............................4 I> Basic Introduction ............................4 II> System composition ............................5 III>Function Introduction ............................. 6 IV. Control method ................................7 I> Independent remote control ..........................7 II>...
Page 3 User Manual of 10KG Dear Users, Thank you for your trust in choosing this products. We always believes that professionalism creates quality and insists on customer first. Continuous investment in product research and development, the pursuit of precision, and efficient and excellent service allow us to continue to innovate and launch products that satisfy customers.
Page 4 User Manual of 10KG I. Disclaimer This statement applies to all licensees who use the 10KG UAV airborne winch (hereinafter referred to as "this product"), including users who purchase this product, authorized dealers, distributors, and developers. Before using this product, please read this statement carefully and make sure that you fully understand and accept all the contents of this statement.
Page 5 User Manual of 10KG II. Precautions When using for the first time, please strictly follow the operation manual. If there are any operating problems, please contact our professional personnel for guidance. Our company is not responsible for product damage or personal risk caused by failure to follow the manual. 1.
Page 6 User Manual of 10KG III. Product Overview I> Basic Introduction 10KG is a multi-platform drone unmanned aerial winch system with a self-weight of 1.1Kg and a maximum load of 10Kg, which has a high load-to-weight ratio. It is suitable for a variety of application scenarios such as emergency drone delivery, cargo transportation, and express (take-out) delivery.
Page 7 User Manual of 10KG II> System composition 1.10KG UAV payload winch components The 10KG UAV payload winch consists of a winch body, a counterweight ring, a hook release, a rope, and a quick-release installation kit (a mechanical mechanism for connecting to the UAV platform).
Page 8 User Manual of 10KG State Yellow light flashing slowly Heavy load Red light flashing slowly Overload FIG 3-2-1 Sheet of Indicator light status 2. Hook release device 10KG is equipped with two types of unhooking devices: a Smart Auto Release device and a mechanical Release device.
Page 9 User Manual of 10KG (2) Automatic line arrangement: the reel supports automatic line arrangement. (3) Automatic unhooking: the unhooking device can automatically unhook when the cargo touches the ground. (4) Electric control casting: the electric control unhooking device supports one-button casting. (5) Ground Stop with Auto Unhook: the rope release automatically stops when the cargo touches the bottom.
Page 10 User Manual of 10KG FIG 4-1-1 Remote control button function Sheet (default version) Key Operation Corresponding functions Lifting up (retracting the rope) Push the left joystick up Lower the load (release the rope) Pull the left joystick down...
Page 11 User Manual of 10KG Fuse blown Pull the right joystick left and down Trigger for 2 seconds, keep triggering until the fuse blows Smart Auto Release control/casting Right button switch Trigger on/off with one press One-click drop (one-touch cargo release) Top position of the left three-stage switch One-click rise...
Page 12 User Manual of 10KG manufacturer provides a debugging remote controller based on SBUS communication, which can be used by customers to debug the equipment functions on the ground. Command Channel Trigger condition (μs) Channel 1 1600-2200 Down Channel 1 800-1400 Stop Channel 1 1400-1600...
Page 13 User Manual of 10KG If the user needs to control through the communication protocol, please contact the manufacturer to lead out the wiring before delivery, and obtain the "10KG Communication Protocol.xlsx" from the manufacturer for development and configuration. According to the communication protocol of the winch, development and control are carried out on the host computer of the ground station, and one-to-one communication with the manufacturer is required.
Page 14 User Manual of 10KG V. Product installation and connection I> Quick-release mounting hardware installation Remove the upper part of the quick-release mount and install the quick-release bracket directly under the drone, as close to the center of gravity of the flight platform as possible, making sure that the quick-release bracket is firmly connected to the drone platform.
Page 15 User Manual of 10KG III> The installation of the winch body on the aircraft platform Place the flying platform on a flat surface, push the top connector of the 10KG winch body into the quick-release mounting piece, and check to ensure that the winch body and the flying platform are firmly installed.
Page 16 User Manual of 10KG 2.Communication line connection Plug the SBUS communication cable into the winch SBUS control interface. FIG 5-4-2 The SBUS cable into the winch SBUS 3.Reset the unhooker Check and ensure that there is no cable entanglement in the limiter spring and unhooker to prevent the upper limit from failing when the rope is collected, causing damage to the equipment.
Page 17 User Manual of 10KG VI. Perform pre-flight cargo inspections After confirming and being familiar with the winch control, before flying, be sure to check whether the connection between the winch equipment and the flight platform is secure. At the same time, evaluate the flight environment and potential safety risks to ensure the smooth and safe flight process.
Page 18 User Manual of 10KG VII. Payload winch system cargo mounting and inspection The 10KG UAV payload winch system can realize the air transportation task of cargo within 10Kg. Before the cargo is transported, it is necessary to weigh the cargo to ensure that it is within the safe lifting weight range.The 10KG is equipped with two types of hook release devices, a mechanical release device device and an smart auto release device (optional).
Page 19 User Manual of 10KG 2. The method for the landing gear a little lower The remote controller executes the cable lowering command, and at the same time manually applies traction to the cable, lowers the cable to a certain length (about 5m), and then pulls out the unhooking device safety pin.
Page 20 User Manual of 10KG 2. Mount after takeoff i>Mounting at the departure point After the flying platform takes off to the set height, lower the rope to the ground. Hang the cargo into the mechanical release device, insert the safety pin, and the flying platform rises until the cable is straightened.
Page 21 User Manual of 10KG FIG 7-2-1 lower the rope to the ground FIG 7-2-2 open the hook FIG 7-2-3 hang the cargo onto it FIG 7-2-4 Closed hanging hook FIG 7-2-5 drone lift the cargo FIG 7-2-6 winch rises to the limiter III>Indicator light check After winch lifts the cargo, observe the indicator light: when the rope is rising or falling, it is blue, indicating that the equipment is working normally;...
Page 22 User Manual of 10KG VIII. Payload winch system cargo unloading I>Mechanical Release device 1. Safety pin locked The flying platform flies to the top of the unloading location and hovers. The one-click lowering command is operated, and the rope is automatically lowered until it stops at the bottom. The user removes the safety pin, takes out the cargo, and operates the one-button ascending command to retract the winch.
Page 23 User Manual of 10KG FIG 8-1-5 unload the cargo（mechanical release without the safety pin） II>Smart Auto Release device 1. Smart one-click release The flying platform flies to the top of the unloading site and hovers, and the intelligent one-click lowering command is activated. The cable is lowered until it touches the bottom and stops automatically, and the Smart Auto Release device is unhooked synchronously to complete the unloading.
Page 24 User Manual of 10KG IX. Maintenance The 10KG drone payload winch system is a drone mounting product with high safety requirements. The terms and precautions in the user manual must be strictly followed when using the equipment. Routine inspections should be carried out before testing, and regular inspections and maintenance should be performed to reduce risks and failures, effectively improve product reliability, and ensure product service life.
Page 25 User Manual of 10KG II>Regular inspection and maintenance It is recommended that users refer to the following standards and conduct regular inspections and maintenance to maintain the equipment in optimal condition and reduce safety hazards. Periodic Inspection and Maintenance Checklist Each 100h/3 three Check Items...
