- Page 1 Seeker-30 AI-TIR 50mm Thermal Sensor EO/ IR AI Recognition & Tracking Gimbal Camera User Manual...
-
Page 2: Disclaimer And Warning
Disclaimer and Warning Congratulations on purchasing your new product. Please read this entire document carefully. Failure to read or follow instructions and warnings in this document may result in damage to your product. Disassemble the gimbal camera by user is not permitted, as which may cause the camera does not work normally. -
Page 3: Product Introduction
1. Product Introduction 1.1 Introduction Seeker-30 AI-TIR is a 3-axis triple-sensor AI gimbal camera for long range inspection and surveillance. It’s powered by 30x optical zoom SONY RGB camera, 50mm 640*512 12 μm IR thermal sensor. -
Page 4: Standard Version
1.2 In the Box A. Standard Version USB to TTL Cable Gimbal Camera X 1 pc x1pc Copper Cylinder M3 Screw x 4 pcs x 8 pcs Power Cable x 1 pc B. Quich-detach Version Gimbal Camera USB to TTL Cable X 1 pc x1pc Copper Cylinder... -
Page 5: Installation Instruction
2.Installation Instruction 2.1 Overview [11] [12] [13] Control Box Back Side (Standard Version) [10] [14] [11] [13] [12] Quick-detach module Control Box (quick-detach Version) - Page 6 [1] Upper damping board [9] FHD zoom camera [2] Damping ball [10] Infrared thermal camera [3] Lower damping board [11] 3S-6S power interface [4] Roll axis motor [12] Micro HDMI interface [5] TF card slot [13] Ethernet interface [6] Pitch axis motor [14] Quick-detach unlock [7] Control box button...
-
Page 7: Front Side
The input voltage cannot be higher than 6S. The pin insertion interface cannot be connected with power supply. The yellow jumper cap cannot be removed 2.2.2 Control Box Printing (Quick-detach Version) HDMI Front Side Left Side Right Side... - Page 8 2.3 Device Dimensions (Standard Version) Unit: mm...
- Page 9 2.3 Device Dimensions (Quick-detach Version) Unit: mm Control Box...
- Page 10 2.4 Install Mounting Part (1) Find out the arrow on the gimbal which indicating the yaw heading of the payload (i.e. the lens direction when the camera power on), and synchronize with the direction specified by the UAV. (2) Fix one end of the copper cylinder on the screw hole of lower damping board, and use M3 screw to fasten it.
- Page 11 2.5 Quick-detach Release Instruction × 1. Make sure the two white stripes indicated in above picture are aligned with each other. (If the stripes are not aligned to each other, please pinch the connector part and turn it to left manually)
- Page 12 2. Align the white dot (unlock icon) to the red triangle (below unlock button), push the gimbal into the quick-detach module completely and then rotate the gimbal camera anticlock- wise. 3. When you hear "click" sound (when red dot is aligned to the red triangle) means the gimbal camera and quick-detach module has been locked.
-
Page 13: Install Tf Card
2.6 Install TF Card TF (Micro SD card): Install the TF card to the card slot (Re. 2.1 Overview). Support max 128GB. Request Class 10 (10m/s) transmission speed or higher and FAT32 or exFAT format. Make sure device is power off when inserting the TF card, hot plugging is not supported. -
Page 14: Signal Control
3. Signal Control 3.1 PWM Control Control the gimbal camera functions by the multiplex pulse width modulation signal outputted by PWM channel of the remote control receiver. The camera needs up to 6 control channels of PWM (to expand tracking function use up to 7 PWM channels). You can choose needed functions according to actual usage to reduce the required number of PWM channels. - Page 15 3.1.2 PWM Control Operation Instruction 1) Pitch (PWM Pitch channel in to control Pitch. Joystick, rotary knob or 3-gear switch on remote control are optional. 3-gear switch as example.) Position 1 Position 2 Position 3 Low Gear Middle Gear High Gear Pitch Up Pitch Stop Pitch Down...
- Page 16 Position 1: Low speed mode, control pitch / yaw with this mode at lowest speed Position 2: Middle speed mode, control pitch / yaw with this mode at middle speed Position 3: High speed mode, control pitch / yaw with this mode at highest speed (If it is controlled by rotary knob, the speed will change according to switch position) Function of continuous switching: 1) Operate 1 time continuously and quickly, from position 2 - 3, to Home position.
- Page 17 5) Focus (PWM Focus channel is to control PIP, IR color palette switch, 3-gear switch as example.) Position 1 Position 2 Position 3 Low Gear Middle High Gear PIP switch Gear IR color palette switch Switch from Position 2 to 1: Picture in Picture. EO+IR , IR+EO, EO only, IR only. Switch from Position 2 to 3: IR color switching: white hot, black hot, pseudo color 6) Pic/Rec (PWM Pic/Rec channel in to control take picture and record.
- Page 18 7) Multi: tracking control Position 1 Position 2 Position 3 Low Gear Middle Gear High Gear Switch from Position 2 to 1: (Reserved) Switch from Position 2 to 3: Exit the tracking, display the cross cursor. Adjust the cross cursor to lock target object and start tracking Switch from Position 3 to 2: Cancel tracking...
- Page 19 USB to TTL Cable Control Box Connection Diagram Quick-detach Version Diagram of USB to TTL Cable: Connect the camera to the upper computer by USB to TTL cable (Adopt connection method of TX to RX, RX to TX, GNG to GND at Dupont ends of the provided USB to TTL cable, connect to the specified TTL of the gimbal, and the USB end of the cable connect to computer).
-
Page 20: S.bus Control
3.3 S.BUS Control Control the gimbal camera functions by one combining signals. Connect the external S.Bus to S.Bus port on the control box, and the external S.bus signal GND connect to the GND interface of the control box. Wiring Diagram (Take Futaba remote control for example): 5V OUTPUT Receiver Remote Control... - Page 21 S.Bus control mode: default S.Bus signal channel 7-13 to control gimbal camera functions (the function of channel is consistent with the corresponding channel in PWM function description) Channel 7: Yaw Control Channel 8: Pitch Control Channel 9: Mode Control Channel 10: Zoom Control Channel 11: Focus Control Channel 12: Pic/Rec Control Channel 13: Multi Backup...
-
Page 22: Specification
RJ45 Remote Control Standard version ethernet wiring diagram ETHERNET Quick-detach version ethernet wiring diagram 4.Specification Hardware Parameter Working voltage Input voltage 4S ~ 6S(16V~24V ) Output voltage 5V (connect with PWM) Dynamic current 850~1800mA @ 16V Working environment temp. -20℃ ~ +60℃ Output micro HDMI(1080P 30/60fps) / IP (RTSP/UDP 1080p/720p 30fps) - Page 23 Photo storage format JPG(1920*1080) Video storage format MP4 (1080P 30fps) Card reading online HTTP read pictures Control method PWM / TTL / S.BUS / TCP(IP output)/UDP(IP output version) Geotagging Support, display time and GPS coordinate in picture exif Gimbal Spec Mechanical Range Pitch/Tilt: -55°～125°, Roll: ±40°,...
- Page 24 Sync system Internal S/N ratio more than 50dB Min illumination Color 0.01lux@F1.6 Exposure control Auto, Manual, Priority mode(shutter priority & iris priority), Bright, EV compensation, Slow AE Gain Auto/Manual 0dB to 50.0dB(0 to 28 steps + 2 setep/ total 15 steps) Max.Gain Limit 10.7 dB to 50.0dB (6 to 28 steps + 2 step/ total 12 steps)"...
- Page 25 521 meters Recognize Distance (Man: 1.8x0.5m) 260 meters Verified Distance (Man: 1.8x0.5m) 6389 meters Detective Distance (Car: 4.2x1.8m) 1597 meters Recognize Distance (Car: 4.2x1.8m) 799 meters Verified Distance (Car: 4.2x1.8m) Working mode Uncooled VOx long wave (8μm~14μm) thermal imager Detector pixel 640*512 Pixel pitch 12μm...
-
Page 26: Packing Information
Tracking speed ±48 pixel/frame Object memory time 100 frames EO Camera AI Performance Targets type Car and human ≥ 10 targets Simultaneous detection quantity Min contrast ratio Min target size 5×5 pixel Car detection rate ≥85% False alarm rate ≤10% Packing Information N.W. - Page 27 2. Does Seeker-30 AI-TIR support taking photos during recording?A: 3. How to set the video storage format of Seeker-30 AI-TIR? A: When the IP output resolution is set to 1280*720, the storage resolution is 1920*1080; Storage resolution is 1920*1080 when the IP output resolution is set to 1920*1080;...
