Operating / Programming Manual & Warranty Document
PBX Model: 308B
We extend a warm welcome to you on becoming a part of the CCL Epabx family.
Our service support Engineers shall be working hard through our channel partners to ensure your satisfaction
with the product and after sales services.
We welcome your feedback / query at info@cclepabx.com
Contents
.
.
CLI Recieving Mode (DTMF / FSK)
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 308B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CCL 308B

Summary of Contents for CCL 308B

  • Page 1: Table Of Contents

    Operating / Programming Manual & Warranty Document PBX Model: 308B We extend a warm welcome to you on becoming a part of the CCL Epabx family. Our service support Engineers shall be working hard through our channel partners to ensure your satisfaction with the product and after sales services.

  • Page 2: Introduction

    Technical Specifications Warranty claim details NOTE- CCL Epabx reserves the right to alter equipment specifications and description contained herein and makes no commitment to update or keep current the information herein. All information herein is subject to change at any time without notice.

  • Page 3: Terminologies Used

    Front Panel Indications Following is the descriptions of the LED indicators of the front panel of the PBX: LED Name Description POWER Blinking means PBX is working on Mains AC or Battery. Connections The PBX has the following connectors on its side panel: Connectors Description LINE 1...

  • Page 4: Auto Attendant Settings

    Dial #*0000 + 10 J # where J= Junction Number 1, 2 or 3 To set Junction in Direct Ring mode: Dial #*0000 + 11 J# Message Recording/ Listening: To Record Auto Attendant Message: Dial #*0000 + 12 M # Recording starts after a confirmation beep.

  • Page 5: Barge-In

    Where, N= Last digit of the Extension Number. TT= 01 to 99. Time in minutes after which the Junction call is to be disconnected. Note: In default there is no restriction. : This auto call disconnection is not applicable on incoming Junction calls. To cancel this feature: Dial 6 N 00 # Barge-In...

  • Page 6: Cli - Digits Addition

    CLI – Digits addition Some CLI Telephones cannot display less than 4 digit numbers. In that case if the PBX extension numbers are less than 4 digits then additional dummy Zeros need to be added by the PBX. Procedure: To Enable, Dial #0000 + 180 1 # To Disable, Dial #0000 + 180 0 # Note- If CLI digit addition is enable then if extension is of 2 digits then 2 dummy zeros are added before extension number and if the extension number is of 3 digits then a zero is added before the extension number.

  • Page 7: Do Not Disturb (Dnd)

    Do Not Disturb (DND) In DND mode, no one can call the DND extension PROCEDURE: Dial # 83 To cancel DND, simply lift Handset. Default: Normal Mode Door Phone 1 Door Phone can be connected to the PBX. Open the back cover of the Door Phone and connect 2 wires on the Terminal block. These 2 wires are to be connected to any of the Extension port (from 601 to 605) of the PBX.

  • Page 8: Hot Line To Junction

    Hot Line to Junction Some or all extensions can be programmed to get Junction Line on lifting the Handset. To dial internal numbers, dial  on lifting the Handset. You will get internal dial tone of the PBX. To program an extension to get a free Junction line on lifting handset, Dial #0000 + 20 N# Where, N= last digit of Extension numbers that is to be programmed for Direct Junction Access.
  • Page 9 Default: All extensions are allowed to access Junction Line in both Day and Night mode. Junction Dialing Controls Junction dialing facility can be controlled Extension wise as below: Dial #0000 + 40 N L # where, N= Last digit of Extension number. L = 0 - The Extension can dial only the numbers starting with digits defined in “Allowed Table”...

  • Page 10: Memory Dialing

    M = 0 for Day mode/ 1 for Night Mode = The last digit of Original extension numbers (1-8) where ring is required. (Not the flexible number) When all assigned extensions are busy When the extensions assigned for the Junction incoming call are busy, The assigned extension when busy, will hear a waiting call beep after every 5 seconds.

  • Page 11: Troubleshooting

    Default: Disabled Note- If memory dialing is disabled then it will check the Junction dialing control for extension. To dial a number from memory- Dial 7CC Operator Extension Setting In default Extension number 602 is defined as Operator and this extension can be changed if desired by the user. To change the Operator Extension, Dial #0000 + 15N# Where, NN = Last digit of Extension which is to be made the Operator.
  • Page 12 CCL Epabx. was not notified by consumer of the alleged defect or malfunction of the product during the limited warranty period. c) The product was used with or connected to equipment not fit for use with CCL Epabx. system or used in other than its intended use.
