MINI LED
(Programmable)
The MINI series LED remote uses RF 2.4GHz wireless transmission technology and the control distance (under no interference)
can be up to 30 meters.
Connect to a P5 controller with 5 channel outputs which supports DIM/CT/RGB/RGBW/RGBCW light. One remote can control a
large amount of controllers within the effective range to achieve different functions, such as turning lights on/off, adjusting
brightness, CT, static RGB color and effects of dynamic modes. Using the remote, you're able to program and modify 9 built-in
dynamic modes, turn on/off the power off memory mode, and set the fade time between 1s and 9s for controllers. These features
meet user needs for different lighting applications.
Technical parameters
Model
M9
Color
White
Wireless protocol
RF2.4GHz
Working voltage
3Vdc
(Button
battery
CR2032×1)
Standby current
<1uA
Distance of remote
30M
(Under no interference)
-30°C~55°C
Working temp.
Weight
40g±10g
Dimensions
104×58×9mm (
Remote ,
) 108×63×14mm (
Remote
Remote + Holder
)
1
Dimensions
9mm
58mm
104mm
Remote
Product installation
：
Two ways to fix the remote holder
1.Fix the remote holder in the wall with two screws.
2.Fix the remote holder in the wall with a 3M adhesive.
MINILEDRemote
14mm
63mm
78mm
108mm
Remote holder
Note: Please pull out the battery tab before first use
2
