Summary of Contents for Ltech WiFi-101-RGBW
- Page 1 Product Features 16.7 million kinds of colors to choose Lights changing with the music Intelligent lighting timing set Limitless long-range control DIY Scene Model RGBW...
-
Page 2: Product Parameters
Product Parameters Product Structure Product Name : WiFi LED Controller Model : WiFi-101-RGBW DC Power supply socket (φ5.5mm x φ2.5mm) Input Voltage : 12 ~ 24Vdc Out Control： RGBW LED Lights 12~24Vdc power input Setting key 3A x 4CH Max 12A... -
Page 3: Product Installation
Load power below 75W, 5. Please ensure that adequate sized cable is use this round adapter WiFi-101-RGBW used from the controller to the LED lights to socket for connection. carry the current. Please also ensure that the cable is secured tightly in the connector. -
Page 4: Operating Schematic
Operating Schematic Operating Instruction... -
Page 5: Operating Guidance
Turn on APP, enter "My Device" interface, Operating Guidance click" "icon. Open WLAN via mobile phone, connect to the wireless router. Scan QR Code to download the APP via mobile phone. iOS / Android After installation, the strip flashes within 30s when powered on and then the controller is ready to the configuration status accordingly. - Page 6 Enter the interface "To select a device", Once successfully connect to the device choose "Color light" and follow the that will immediately open intelligent prompts to connect. life and realize long-distance control via mobile phone.
