Delta FORCE-GT DRF-V960W3GBA Series Technical Data Sheet

TECHNICAL DATASHEET
Force-GT DIN Rail Power Supply
960 W 3 Phase / DRF-V960W3GBA
General Description
The Force-GT Series DIN rail industrial power supply features high power density and high efficiency. The Series offers overcurrent
protection in constant current mode, making it suitable for charging applications. Conformal coating is applied on the PCBAs to protect
against dust and pollutants often found in harsh industrial environments. The Series' electromagnetic radiated and conducted emissions
are compliant with heavy industrial Class B Emission standard and Immunity standard, and complies with environmental protection
standards RoHS Directive.
Model Information
Force-GT DIN Rail Power Supply
Model Number
DRF-24V960W3GBA
DRF-48V960W3GBA
Model Numbering
F –
DR
DIN Rail Product Series
F – Force
All parameters are specified at 25°C ambient and AC input 3x unless otherwise indicated.
1
www.DeltaPSU.com (November 2024, Rev. 05)
Input Voltage Range
3 x 320-575 Vac (3-Phase) or
2 x 340-575 Vac (2-Phase)
V 960W
Output Voltage Output Power Three Phase
24 – 24 V
48 – 48 V
Highlights & Features
Universal AC input voltage range
•
• Built-in constant current circuit for charging applications
Full load operating temperature up to 55°C
•
• Cold start at -40°C
Ultra-Slim design
•
• Reduced no-load power consumption
Built-in DC OK relay and LED indicator
•
• Conformal coating on PCBAs to protect against common dust
and pollutants
Safety Standards
CB Certified for worldwide use
Model Number:
Unit Weight:
Dimensions (H x W x D):
Rated Output Voltage
24 Vdc
48 Vdc
3 G
G – General Type B – Screw Terminal Delta Standard
DRF-V960W3GBA
2.26 kg (4.98 lb)
124 x 110 x 128.7 mm
(4.88 x 4.33 x 5.07 inch)
Rated Output Current
40.0 A
20.0 A
B A
