Owner's Manual
6541-CP
This Owner's Manual provides assembly, install and
user guidance. It applies to all Pacifica Floor sold by
Ranger Design. For a list of compatible models, visit our
website at rangerdesign.com.
Contents
Warnings ....................2
Parts Included ............3
Tools Required (Not
Included) ....................4
Pre-assembly .............5
Assembly ...................6
Installation ..................7
This Owner's Manual must remain in vehicle at all times.
6541-CP
as shown
Scan the QR code for the
latest Installation Guide.
For more information,
visit rangerdesign.com.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6541-CP and is the answer not in the manual?

Questions and answers

Summary of Contents for Ranger design 6541-CP

  • Page 1: Table Of Contents

    Owner’s Manual 6541-CP This Owner’s Manual provides assembly, install and user guidance. It applies to all Pacifica Floor sold by Ranger Design. For a list of compatible models, visit our website at rangerdesign.com. Contents Warnings ....2 Parts Included ....3 6541-CP...
  • Page 2: Warnings

    FR: Si vous avez besoin de ces instructions en français, s'il vous plait contacter notre service à la clientèle. +1-800-565-5321 ES: Si necesita estas instrucciones en español, comuníquese con el Servicio de atención al cliente de Ranger Design. +1-800-565-5321 Page 2 | 6541-CP Installation Guide | REV. B...
  • Page 3: Parts Included

    P/N 65-500 Rear Support Bracket – Qty. 1 P/N 65-503 Mid Jigsaw Bracket – Qty. 1 P/N 65-504 Front Support – Qty. 1 P/N 65-505 For technical support, contact us at 1-800-565-5321 6541-CP Installation Guide | REV. B | Page 3...
  • Page 4: Included)

    Tools Required (Not Included) Cordless Drill ƒ Tape Measure ƒ ƒ Marker 7/16" Drill Bit w/ Drill Collar ƒ 15mm Socket ƒ 3/16 Allen ƒ T20Torx ƒ Page 4 | 6541-CP Installation Guide | REV. B For technical support, contact us at 1-800-565-5321...
  • Page 5: Pre-Assembly

    STEP 1 Prepare installation by installing the snap-in nuts to the jigsaw support and the rear support bracket. HARDWARE Snap-in Nut 5/16"-18 Qty: 8 Snap in nut Snap in nut For technical support, contact us at 1-800-565-5321 6541-CP Installation Guide | REV. B | Page 5...
  • Page 6 Pre-assembly STEP 2 Install floor sill extrusion to front panel floor. TOOLS ƒ Rubber Mallet Page 6 | 6541-CP Installation Guide | REV. B For technical support, contact us at 1-800-565-5321...
  • Page 7: Assembly

    Serrated Nut 5/16"-18 Qty: 6 NOTE: ƒ Ensure that when installing the jigsaw bracket the indicator slot is facing the front of the van. FRONT REAR For technical support, contact us at 1-800-565-5321 6541-CP Installation Guide | REV. B | Page 7...
  • Page 8: Installation

    ƒ Impact Driver ƒ 15mm Socket HARDWARE Square Flat Washer 0.438"OD × 1.000" Qty: 3 Square Washer Re-use OEM Bolts Torque to 12 ft-lbs. Page 8 | 6541-CP Installation Guide | REV. B For technical support, contact us at 1-800-565-5321...
  • Page 9 Use botton head screw to install the floor. TOOLS ƒ 3/16 Allen Bit ƒ Impact Driver HARDWARE Button Head Screw Botton Head Screw 5/16"x 1 Qty: 6 Torque to 12 ft-lbs. For technical support, contact us at 1-800-565-5321 6541-CP Installation Guide | REV. B | Page 9...
  • Page 10 Install floor to mid puzzle joint and mid floor bracket using ranger provided hardware. HARDWARE Botton Head Screw 5/16"x 1 Qty: 8 Torque to Botton Head Screw 12 ft-lbs. Page 10 | 6541-CP Installation Guide | REV. B For technical support, contact us at 1-800-565-5321...
  • Page 11 ƒ Impact Driver HARDWARE Black oxide bolts Qty: 4 Tapping Inserts 5/16-18 Qty: 4 Botton Head Hex Screw Wood Insert Torque to 12 ft-lbs. For technical support, contact us at 1-800-565-5321 6541-CP Installation Guide | REV. B | Page 11...
  • Page 12 STEP 8 Install panel plug and torx screw. TOOLS ƒ T20 Torx Bit ƒ Impact Driver Torx Screw Locking Panel Plug Torque to 12 ft-lbs. Page 12 | 6541-CP Installation Guide | REV. B For technical support, contact us at 1-800-565-5321...
  • Page 13 For any feedback or suggestions you may have, please contact cs@rangerdesign.com. Copyright © 2024 All rights reserved. This manual or any portion thereof may not be reproduced or used in any manner whatsoever without the express written permission of Ranger Design, Inc.
