- Page 1 INSTALLATION GUIDE 5045 C For virtual Install Guide, scan the QR code or visit: https://rangerdesign.com/products/lockable-van- cab-storage-box-18x12x16/...
- Page 2 QUICK START GUIDE Phase 1 - Assembly 1.1 Setup............................... 3 Phase 2 - Installation 2.1 Regular Install..........................4 SAFETY INSTRUCTIONS WARNING •Before the installation, carefully read the supplied installation guide to avoid possible injuries and dam- ages resulting from incorrect installation. Always keep the installation guide in an accessible location at all times for reference during installation.
- Page 3 PHASE 1 – ASSEMBLY 1.1 SETUP 1.1.1 Unpack components; compare with the bill of materials. bILL oF MaTERIaL Item No. Description Qty. 5045 96-5007 nstall astener For technical support, contact us at 1-800-565-5321 5040 Installation Guide | REV. D1 | Page 3...
- Page 4 PHASE 2 – INSTALL 2.1 NO 5041 INSTALL 2.1.1 Place and screw your 5045 cab box on a flat surface. TOOLS q Cordless Impact q 3/8" Driver Bit HARDWARE USED 4× #92-100 Screw #14 × 3/4" “You have successfully installed your Cab Box Thank you for doing business with us.”...
