- Page 1 LEGEND WARBIRD SERIES USER MANUAL 76111 v.01.2025...
-
Page 2: Safety Precautions
This product is not intended for use by children without direct adult supervision. Do not attempt to disassemble, use with incompatible components or augment product in any way without the approval of VolantexRC Co., Ltd.. This manual contains instructions for safety, operation and maintenance. It is essential to read and follow all the instructions and warnings in the manual, prior to assembly, setup or use, in order to operate correctly and avoid damage or serious injury. -
Page 3: Box Contents
- By handling, charging or using the included battery, you shall assume all risks associated with Li-Po/Li-Ion/Ni-Mh battery. - If at any time the battery begins to balloon or swell, discontinue use immediately. If charging or discharging, you should discontinue and disconnect. Continue to use, charge or discharge a battery that is ballooning or swelling can result in - Always store the battery at room temperature in a dry area for best results. -
Page 4: Charging Instruction
Charging Instruction 1. Unplug the battery from your plane. 2. Carefully plug the charger into the USB port on your computer or USB adapter. 3. Connect battery into the charger. 4. The charging process takes about 3 hours. For safety reasons, never charge the battery for longer than 4 hours. - Page 5 Center Control Surfaces NOTE: Keep the X-PILOT switch off (manual mode) before you operate the steps below. See more information in "X-PILOT switch" section. With the transmitter turned on and the battery conected to the ESC(and installed in the battery compartment), it is now possible to check the center of all control surfaces. Observe the rudder to ensure it is properly centered as shown above.
- Page 6 Push Rod Push Rod Arc-shaped Arc-shaped Section Section If the elevator is angled off to the upper or If the aileron is angled off to the upper or lower position, adjust the push rod by its lower position, adjust the push rod by its arc-shaped section slightly, making sure arc-shaped section slightly, making sure the elevator is properly centered.
- Page 7 Binding Instruction 1.Keep the transmitter switched OFF, throttle joystick at buttom position. NOTE : Keep X-PILOT switch at Middle or Beginner position. NOTE : Keep the plane still in a calm environment for calculating the X-PILOT. 2.Connect the battery to the plane, then turn on the transmitter within 5 seconds. CAUTION: Do NOT operate around people or property, otherwise it may cause serious damage! Arm the Throttle...
- Page 8 Channels Reactions Checking Swing The Transmitter X-PILOT Reaction Reaction Plane Operaton Place your plane in a neutral position, follow below steps to check the channels reactions. Move the sticks(except the throttle stick) to see if all servo surfaces react correctly as shown in the left diagram(left throttle for example).
- Page 9 One-key Takeoff The airplane comes with one-key take off function, which enable the plane to take off automatically and hover in the air, until any operation on transmitter to exit. Follow below steps to use this function. 1. Turn the X-PILOT switch to beginner / intermediate mode. 2.
- Page 10 Find My Aircraft When the aircraft is missing but with power on, press and Find My Aircraft hold the find my aircraft button for 3 seconds until there is Button a beeping sound, it means the find my aircraft is activiated. The aircraft will keep 4 beepings in a series to indicate its location.
- Page 11 Screws Screws 2. Follow below steps to replace the receiver. a. Loosen the screws of servo horns, take the servo horns off. b. Unplug the motor cable and the mainwing servo cable. You may need to record the direction of cable plugs. c.
-
Page 12: Flight Checklist
Flight Checklist NOTE: This checklist is NOT intended to replace the content included in this instruction manual. Althought it can be used as a quick start guide, we strongly suggest that read all though the manual completely before proceeding. - Ensure the throttle control stick is at bottom position before connecting the battery. - Unplug the battery.
