Owner's Manual
3020-CP
This Owner's Manual provides assembly, install and
user guidance. It applies to all 3020-CP sold by Ranger
Design. For a list of compatible models, visit our
website at rangerdesign.com.
Contents
Warnings ....................2
Parts Included ............3
Included) ....................4
Assembly ...................5
Installation ..................9
This Owner's Manual must remain in vehicle at all times.
3020-CP
as shown
Scan the QR code for the
latest Installation Guide.
For more information,
visit rangerdesign.com.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 3020-CP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ranger design 3020-CP

Summary of Contents for Ranger design 3020-CP

  • Page 1: Table Of Contents

    Owner’s Manual 3020-CP This Owner’s Manual provides assembly, install and user guidance. It applies to all 3020-CP sold by Ranger Design. For a list of compatible models, visit our website at rangerdesign.com. Contents Warnings ....2 Parts Included ....3 Tools Required (Not Included) ....4...

  • Page 2: Warnings

    FR: Si vous avez besoin de ces instructions en français, s'il vous plait contacter notre service à la clientèle. +1-800-565-5321 ES: Si necesita estas instrucciones en español, comuníquese con el Servicio de atención al cliente de Ranger Design. +1-800-565-5321 Page 2 | 3020-CP Installation Guide | REV. B...

  • Page 3: Parts Included

    PS Wing Panel – Qty. 1 P/N 31-0012 Bottom Panel – Qty. 1 P/N 31-0010 Floor Bracket – Qty. 1 P/N 31-001 Edge Trim – Qty. 2 P/N 31-003 For technical support, contact us at 1-800-565-5321 3020-CP Installation Guide | REV. B | Page 3...

  • Page 4: Tools Required (Not Included)

    7/16" Wrench 8mm Socket ƒ ƒ ƒ Tape Measure 1/2" Socket 10mm Socket ƒ ƒ ƒ Marker 1/2" Wrench 11mm Socket ƒ ƒ ƒ Page 4 | 3020-CP Installation Guide | REV. B For technical support, contact us at 1-800-565-5321...

  • Page 5: Assembly

    Assembly STEP 1 Pre-assemble top and bottom panels with the mounting track and wing panels before installing inside the van. For technical support, contact us at 1-800-565-5321 3020-CP Installation Guide | REV. B | Page 5...
  • Page 6 Carriage Bolt Serrated Nut HARDWARE Carriage Bolt 5/16"-20 × 5/8" Qty: 14 Carriage Bolt Serrated Nut Serrated Nut 5/16"-20 Qty: 14 Torque to 12 ft-lbs. Page 6 | 3020-CP Installation Guide | REV. B For technical support, contact us at 1-800-565-5321...
  • Page 7 Serrated Nut 5/16"-20 Qty: 4 HARDWARE Carriage Bolt 5/16"-20 × 1/2" Qty: 8 Serrated Nut 5/16"-20 Qty: 8 Carriage Bolt Serrated Nut Torque to 12 ft-lbs. For technical support, contact us at 1-800-565-5321 3020-CP Installation Guide | REV. B | Page 7...
  • Page 8 Assembly STEP 4 Insert the partition edge trim. Page 8 | 3020-CP Installation Guide | REV. B For technical support, contact us at 1-800-565-5321...

  • Page 9: Installation

    TOOLS ƒ 11mm Socket ƒ Impact Driver HARDWARE Serrated Lock Nut M5 x 0.8mm Qty: 6 Torque to Serrated Nut 12 ft-lbs. Nylon Spacer For technical support, contact us at 1-800-565-5321 3020-CP Installation Guide | REV. B | Page 9...
  • Page 10 ƒ Impact Driver Carriage Bolt Serrated Nut HARDWARE Torque to Carriage Bolt 5/16"-18 × 1/2" Qty: 8 12 ft-lbs. Serrated Nut 5/16"-18 Qty: 8 Page 10 | 3020-CP Installation Guide | REV. B For technical support, contact us at 1-800-565-5321...
  • Page 11 ƒ Impact Driver HARDWARE Hex Head Bolt 5/16"-20 × 1/2" Qty: 8 Flat Washer 5/16"-20 Qty: 8 Hex Bolt Flat Washer Torque to 12 ft-lbs. For technical support, contact us at 1-800-565-5321 3020-CP Installation Guide | REV. B | Page 11...
  • Page 12 STEP 8 Install partition handle holder into the van together with the OEM grab handles. a. Remove OEM grab handles. b. Install partition brackets together with OEM grab handles. Page 12 | 3020-CP Installation Guide | REV. B For technical support, contact us at 1-800-565-5321...
  • Page 13 ƒ Impact Driver HARDWARE Torque to Carriage Bolt 12 ft-lbs. Carriage Bolt 5/16"-20 × 1/2" Qty: 6 Serrated Nut Serrated Nut 5/16"-20 Qty: 6 For technical support, contact us at 1-800-565-5321 3020-CP Installation Guide | REV. B | Page 13...
  • Page 14 For any feedback or suggestions you may have, please contact cs@rangerdesign.com. Copyright © 2024 All rights reserved. This manual or any portion thereof may not be reproduced or used in any manner whatsoever without the express written permission of Ranger Design, Inc.
