It is imperative that you read these Operating Instructions prior to installing
50133345; State: 04.12 Rights to technical changes reserved!
Operating Instructions
with storage tank
Water Purification System
and operating this system!
Art. no.: 50132372 (UV/UF)
Art. no.: 50132374 (UV)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Thermo Scientific MicroPure 50132367
Summary of Contents for Thermo Scientific MicroPure 50132367
- Page 1 Operating Instructions Thermo Scientific Barnstead MicroPure with storage tank Water Purification System Art. no.: 50132367 (Standard) Art. no.: 50132372 (UV/UF) Art. no.: 50132369 (UF) Art. no.: 50132374 (UV) Serial number: ........ It is imperative that you read these Operating Instructions prior to installing and operating this system! 50133345;...
-
Page 2: Ec Declaration Of Conformity
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system EC-Declaration of Conformity in accordance with the EEC machine directive 2006/42/EC, appendix II A We hereby certify that the following described machine in its conception and form put by us into... -
Page 3: Preface
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system Preface Dear Sir or Madam In deciding to purchase an ultrapure water system from the MicroPure with storage tank se- ries, you have selected a high-quality product. Thank you for the confidence you have placed in us. -
Page 4: Table Of Contents
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system 1. Contents Preface ......................3 1. Contents ....................4 2. Explanatory notes on the operating instructions ........6 3. Transport and packaging ................ 7 3.1 Examination on receipt ....................... 7 ... - Page 5 Thermo Scientific Barnstead MicroPure with tank Ultrapure water system 12.2.1 Setting the limiting temperature for the system: ............31 12.2.2 Setting the rinsing time: ................... 32 12.2.3 Changing the disinfection time: ................32 12.2.4 Setting the interval time for the pump: ..............32 ...
-
Page 6: Explanatory Notes On The Operating Instructions
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system 2. Explanatory notes on the operating instructions EU Mark of Conformity CSA - admission Important operating and/or maintenance instructions! Read the oper- ating instructions with due care . Risk of electric shock! Electrical work on the system is only to be car- ried out by qualified personnel. -
Page 7: Transport And Packaging
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system 3. Transport and packaging Ultrapure water systems are carefully controlled and packed prior to dispatch, but damage could still possibly occur during transport. 3.1 Examination on receipt Check the completeness of the goods received against the delivery note. -
Page 8: Parts Supplied
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system 4. Parts supplied MicroPure ultrapure water systems with a performance up to 1,5 l/min are available in the fol- lowing versions: 50132367 MicroPure with tank (Standard system) 50132369 MicroPure UF with tank... -
Page 9: Safety Precautions
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system 5. Safety precautions Observe these safety precautions for your own safety! Each system of the MicroPure with tank series is a modern ultrapure through out water system, exclusively designed for the purification of tap water of drinking water quality. - Page 10 Thermo Scientific Barnstead MicroPure with tank Ultrapure water system The maximum operating temperature of the system is 40°C. If neither a floor drain is not is available, then proceed as follows during longer system standstills (e.g. long holidays): ...
-
Page 11: Intended Purpose
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system 6. Intended purpose Decisive for the development of the novel MicroPure with tank ultrapure water systems were the continually increasing requirements that ultrapure water quality must fulfill, the ever stricter de- mands resulting from technological advances, and the need for user-friendly systems and com- plete solutions. -
Page 12: Technical Specifications
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system 7. Technical specifications Demands on the feedwater Source Potable tap water pretreated by reverse osmosis, ion exchange or distillation. Feedwater resistance > 0.20 MΩxcm Free chlorine max. 0.05 ppm TOC Value max. - Page 13 Thermo Scientific Barnstead MicroPure with tank Ultrapure water system Electrical connections / external switched mode power supply Input voltage AC 100 – 240 V, 50 – 60 Hz, 5 – 3.8 A Output voltage DC 24 V, 3.8 A System connection...
-
Page 14: How Micropure Systems Function
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system 8. How MicroPure systems function MicroPure with tank, UF, UV/UF, UV Tap water that has been subjected to pre-treatment (by reverse osmosis, ion exchange or distil- lation) flows from the storage tank into the ultrapure water system, where the electrical conduc- tivity is monitored. -
Page 15: Flow Chart, Micropure Uf With Tank
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system 8.2 Flow chart, MicroPure UF with tank A-B1 Storage tank A-F1 Filter cartridge A-F2 Sterile filter A-F3 Ultrafiltration module A-F4 Sterile venting filter A-P1 Circulation pump QIA 300 Feedwater conductivity QIA 301... -
Page 16: Flow Chart, Micropure Uv/Uf With Tank
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system 8.3 Flow chart, MicroPure UV/UF with tank A-B1 Storage tank A-F1 Filter cartridge A-F2 Sterile filter A-F3 Ultrafiltration module A-F4 Sterile venting filter A-P1 Circulation pump A-UV1 UV-photooxidation QIA 300 Feedwater conductivity... -
Page 17: Flow Chart, Micropure Uv With Tank
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system 8.4 Flow chart, MicroPure UV with tank A-B1 Storage tank A-F1 Filter cartridge A-F2 Sterile filter A-F4 Sterile venting filter A-P1 Circulation pump A-UV1 UV-photooxidation QIA 300 Feedwater conductivity QIA 301... -
Page 18: Installation Of The System
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system 9. Installation of the system 9.1 The installation area Take the following criteria into consideration when selecting the installation area: Feedwater pressure, not below 0.1 bar, not above 6 bar. -
Page 19: Installation
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system 9.2 Installation 1) Connection power supply 4-pin, 24V DC 2) Rinse water connector Hose, 8 mm o.d. 3) Tank overflow connector Hose, 8 mm o.d 4) Sterile filter 5) Filter cartridge... - Page 20 Thermo Scientific Barnstead MicroPure with tank Ultrapure water system Open the water tap so that feedwater is supplied and check that all connections are leak-free. Replace the cartridge cover, ensuring that the catch on the right side of the cover locks...
-
Page 21: Mounting The Power Pack (Voltage Supply)
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system 9.3 Mounting the power pack (voltage supply) Whenever possible, mount the power pack on the wall to the left or right of the ultrapure water system where it is freely accessible. -
Page 22: Putting The System Into Operation
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system 10. Putting the system into operation Allow the system to warm up to, or to cool down to, room temperature before starting it up for the first time. Check that all hose connections have been made as specified in the "Setting up the system"... -
Page 23: Operating Elements
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system 11. Operating elements Intervall – ppb 18.2 MΩxcm 18.5°C UV/TC Switches the system on or off Switches "Nonstop" operation on or, in the menu, increases a value on display Confirms the value shown in a menu... -
Page 24: System Control
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system 12. System control General information A press on the ON/OFF-key causes the system to run in the Interval operating mode (see Inter- val mode). Interval operation then starts up automatically every 0.5 hours and runs for the set length of time to ensure the high ultra pure water quality. -
Page 25: Menu
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system 12.1 Menu 12.1.1 Feedwater conductivity After a single press on the menu-key, the feedwater conductivity can be read and the lim- iting value of the feedwater conductivity can be set. The fault message that flashes in the fourth line of the display when the feedwater limiting value is exceeded is "Limit value... -
Page 26: Uv-Lamp Operating Time And Intensity
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system 12.1.3. UV-Lamp operating time and intensity: Not active in this version. The display shows: UV-time 0000 h UV-intensity 12.1.4. Filter cartridge operating time counter: The operating time counter for the filter cartridge can be set in this menu by a fourth press on the menu-key and the entry of a valid serial number for the filter cartridge. -
Page 27: Disinfection
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system During rinsing, the display shows: Rinse 30 sec. 12.1.6. Disinfection A sixth press on the menu-key gives you the possibility of carrying out disinfection. The command “Disinfection cartridge. Install one” is shown when this menu-prompt is con- firmed with Enter. -
Page 28: Display Of Fault Storage
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system After disinfection, the display shows: filterset Press enter 12.1.7 Display of fault storage: A seventh press on the menu-key calls the fault storage. Confirmation with Enter allows you to look through the faults in the fault storage. -
Page 29: Data Print Out
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system 12.1.8 Data print out Not active in this version. The display shows: Print out? Press enter 0000 12.1.9 Unlocking the system An nine press on the menu-key in this menu brings you to the “Code” menu. To prevent... - Page 30 Thermo Scientific Barnstead MicroPure with tank Ultrapure water system Assignment Table for code numbers which unlock the system Printer Code no. Person output 0001 0002 0003 0004 0005 0006 0007 0008 0009...
-
Page 31: Oem Menu
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system 12.2 OEM Menu: Basic settings and limiting values can be changed in this menu. To make changes in the OEM menu, system control must previously be unlocked. Calling the OEM menu: Simultaneous pressing of the Interval-key and the Nonstop-key calls the OEM menu. -
Page 32: Setting The Rinsing Time
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system 12.2.2 Setting the rinsing time: Basic setting: 30 sec. Setting range: 10 - 60 sec. The display shows: OEM-Menu Rinse time 30 sec. 12.2.3 Changing the disinfection time: Basic setting: 30 min. -
Page 33: Setting The Interval Rinse Time
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system 12.2.5 Setting the interval rinse time: Basic setting: 0.5 sec. Setting range: 0.1 - 2 sec. The display shows: OEM-Menu Rinse interval 0.5 sec. 12.2.6 Setting the real-time clock: Basic setting:... -
Page 34: Selecting The Language
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system 12.2.8 Selecting the language: Basic setting: English Setting range: English, French, German The display shows: OEM-Menu Language English 12.2.9 Switching units: Basic setting: Resistance MΩxcm Setting range: Resistance MΩxcm, Specific electrical resistance MΩxcm... -
Page 35: Maintenance
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system 13. Maintenance Regular maintenance of your system ensures that the value of it is maintained. We recommend that you close a service contract with a service company which has been expressly authorized. -
Page 36: Maintenance Intervals
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system 13.1 Maintenance intervals Consumable materials are to be replaced at the intervals given in the following Table or when there is drop in performance: Material Flow chart no. Article no. Interval* Pretreatment cartridge 09.2001... -
Page 37: Replacing The Filter Cartridge
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system 13.2 Replacing the filter cartridge The filter cartridge must be replaced when the limiting value that you have set for the ultrapure water is exceeded, or after the system has been subject to disinfection. -
Page 38: Disinfection
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system 13.3 Disinfection Your system should be cleaned and disinfected at least once per year to kill any bacteria that are possibly in the tank. We recommend that you carry out cleaning and disinfection shortly prior to the time that the filter cartridge must be replaced. -
Page 39: Waste Disposal
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system 14. Waste disposal When the packaging is no longer needed, it can be disposed of as household waste. Systems are in conformity with EEC Guideline 2002/95/EC The system is not to be thrown away as household waste but must be properly disposed of. It can be returned to the manufacturer for safe disposal according to EEC Guideline 2002/96/EC. -
Page 40: Trouble Shooting
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system 15. Trouble shooting Fault Cause Remedy The system does not start - No supply of power - Provide power Dispensing not possible - Feedwater tap is closed - Open the feedwater tap... - Page 41 Thermo Scientific Barnstead MicroPure with tank Ultrapure water system Fault message: - Filter cartridge exhausted - Replace with new filter - Limiting value set too low cartridge (art.-no.: 09.2005) "Lim. va.pure w." - System has a UF-module - Check and suit the limiting...
- Page 42 Thermo Scientific Barnstead MicroPure with tank Ultrapure water system The address to contact when your system requires service: Overview of Thermo Scientific International Sales Organization Postal address USA: Thermo Scientific 275 Aiken Road Asheville, NC 28804 Enquiries from USA/Canada Sales:...
- Page 43 Thermo Scientific Barnstead MicroPure with tank Ultrapure water system Belgium Sales: +32 53 73 4241 Service: +32 53 73 4241 Finland/Nordic/Baltic countries Sales: +358 9 329 100 Service: +358 9 329 100 France Sales: +33 2 2803 2180 Service: +33 825 800 119...
-
Page 44: Replacement Parts And Consumables
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system 16. Replacement parts and consumables Rückansicht ohne Tank Backside without tank... - Page 45 Thermo Scientific Barnstead MicroPure with tank Ultrapure water system Pos. R+I Nr. Designation Article no. A-F1 Filter cartridge 09.1006 A-F2 Sterile filter 09.1003 A-F3 Ultrafiltration module 50133981 A-F4 Sterile venting filter 22.0091 A-P1 Circulation pump 19.0050* A-UV1 Replacement UV-lamp 22.0039 UV-Booster 22.0086...
-
Page 46: Accessories
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system 17. Accessories Bezeichnung Artikel - Nr. Desinfection cartridge 09.1102 Disinfection agent, MICRO-Chlor (pack of 12 cans, Europe only) 09.2202 Cleaning Solution, 1 syringe (US-market only) CMX25 Wall mount 09.2212... -
Page 47: Terminal Assignment
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system 18. Terminal assignment... - Page 48 Thermo Scientific Barnstead MicroPure with tank Ultrapure water system...
-
Page 49: Maintenance Record
Thermo Scientific Barnstead MicroPure with tank Ultrapure water system 19. Maintenance record (Please keep this carefully updated, as correct keeping of this maintenance record is a condition of the guarantee) Address of customer: Location: Type of system: Serial-no.: Year made:... - Page 50 Thermo Scientific Barnstead MicroPure with tank Ultrapure water system Contact Information Thermo Scientific North America: USA/Canada +1 866 984 3766 (866-9-THERMO) Europe: Austria +43 1 801 40 0, Belgium +32 53 73 42 41, France +33 2 2803 2180, Germany national toll free 08001-536 376,...
