Summary of Contents for Delta A09733
-
Page 2: Safety Guidelines - Definitions
• Heat will expand fuel in the tank which could result in spillage and possible fire explosion. • Operating the pressure washer in an ex- plosive environment could result in a fire. A09733 which, if not avoided, may result in minor or moderate injury. - Page 3 HAZARD HOW TO PREVENT IT • Never operate pressure washer in an area containing dry brush or weeds. • Always keep pressure washer a minimum of four feet away from surfaces (such as houses, automobiles, or live plants) that could be damaged from muffler exhaust heat.
- Page 4 HAZARD HOW TO PREVENT IT • If pressure washer is equipped with a fuel shut-off valve, turn the valve to the off position before transporting to avoid fuel leaks. If pressure washer is not equipped with a fuel shut-off valve, drain the fuel from tank before transporting.
- Page 5 RISK OF UNSAFE OPERATION WHAT CAN HAPPEN • Unsafe operation of your pressure washer could lead to serious injury or death to you or others. • If proper starting procedure is not followed, engine can kickback causing serious hand and arm injury.
-
Page 6: Carton Contents
Surface Cleaning Guide ASSEMBLY INSTRUCTIONS To Assemble Quick Connect Grommets: Squeeze grommet and place into hole, fitting groove to rim. Push grommet into place. Repeat steps until all grommets are assembled. A09733 CARTON CONTENTS Operation Nozzle Manual Chemical Cleaning Hose Engine Registration... - Page 7 NOTE: The high pressure pump was filled with oil at the factory. The oil in the high pressure pump was designed to last the life of the pump. If there is a problem with the pump contact an Authorized Service Center. 7- ENG A09733...
-
Page 8: Basic Elements Of Apressure Washer
Spray Wand instructions in this section. Chemical Hose (not shown): Feeds cleaning agents into the pump to mix with the water. See How To Apply Chemicals/Cleaning Solvents instructions in this section. A09733 High Pressure Hose "Water Vroom" surface cleaning guide: Allows the operator to maintain a consistent distance when cleaning most any flat surface. -
Page 9: Pressure Washer Operating Features
finished using your pressure washer, return the pressure reg- ulator to its original position by turning it clockwise. DO NOT try to turn pressure regulator knob past the built-in stop or damage to pump will result. 9- ENG A09733... - Page 10 DO NOT use hot water, use cold water only. NEVER turn water supply off while pressure washer engine is running or damage to pump will result. DO NOT stop spraying water for more than two minutes at a time. Pump operates in bypass mode when spray gun trigger is not pressed.
- Page 11 Pumps damaged due to chemicals will not be covered under warranty. NOTE: Chemicals and soaps will not siphon when spray wand is in the high pressure setting. 11- ENG Barb Fitting A09733...
-
Page 12: Shutting Down
Solvents instructions in this section. Turn water source on. NOTE: Failure to do so could cause damage to the pump. A09733 Start engine. See Engine Owners Manual for correct procedure. NOTE: When engine rope is pulled, pressure starts building in the gun. If the engine... -
Page 13: Maintenance
To ensure efficient operation and longer life of your pressure washer, a routine maintenance schedule should be prepared and followed. If the pressure washer is used in unusual conditions, such as high- temperatures or dusty conditions, more frequent maintenance checks will be required. -
Page 14: Inlet Filter
Clean filter by flushing it with water on both sides. Re-insert filter into water inlet of pump. NOTE: Cone side faces out. NOTE: Do not operate pressure washer without filter properly installed. A09733 14- ENG... -
Page 15: Pressure Washer
Store in gun holder. Store chemical hose so it is protected from damage. If space is needed, remove handles and replace as shown. 15- ENG A09733... -
Page 16: Troubleshooting Guide
Nozzle obstructed. Water filter screen clogged. Air in hose. Choke lever in the “Choke” position. Move choke to the “No Choke” High pressure hose is too long. A09733 CAUSE Add Fuel. Squeeze gun trigger to relieve pressure. Move choke to the “Choke”... - Page 17 Drain and fill with correct amount and type of oil. Clean vent plug; blow air through it to remove any blockage. If prob- lem persists, replace plug. See Nozzle Cleaning paragraph in the Maintenance section for the correct procedure. 17- ENG CORRECTION A09733...
-
Page 18: Warranty
• Use reasonable care in the operation and maintenance of the product as described in the Owners Manual(s). • Deliver or ship the product to the nearest Delta Authorized Warranty Service Center. Freight costs, if any, must be paid by the purchaser.
