Anzzi COLLINES SP-AZ079 Installation & Operation Manual page 14

CARE AND MAINTENANCE
IMPORTANT:
It is not recommended that the user disassemble the thermostatic cartridge by himself,
and it is recommended to ask professional personnel for treatment.
1
Remove the plug.
4
Remove the Escutcheon.
7
Unplug the thermostatic cartridge.
2
Loosen the screw with the
hexagon wrench.
5
Remove thermostatic restrictor
with the plier.
Note: We suggest recording
the position of thermostatic
restrictor by camera.
8
10'
Soak the thermostatic cartridge in vinegar for 10 minutes
Rinse the cartridge with clean flowing water.
3
Remove the thermostatic handle.
Note: The rod of cartridge can only
be rotated when the handle is right in
place. Don't rotate the rod of cartridge
during and after removing the handle.
6
Remove the bonnet nut.
pg. 14
