DON'T WAIT!
REGISTER NOW!
Register your product within 90 days to ensure your product is
recognized as an
coverage.
Register online at
PG. 2.
purchase and is
https://anzzi.com/pages/register
ANZZI BEVERLY SHOWER PANEL
INSTALLATION & OPERATION MANUAL
for warranty
V1.2-This version supersedes all previous versions as of 01/30/2025
ITEM: SP-AZ080**
or scan the QR code at
V1.2
01/30/2025
Advertisement
Table of Contents
Related Manuals for Anzzi BEVERLY SP-AZ080 Series
Summary of Contents for Anzzi BEVERLY SP-AZ080 Series
- Page 1 ITEM: SP-AZ080** ANZZI BEVERLY SHOWER PANEL INSTALLATION & OPERATION MANUAL V1.2 01/30/2025 DON’T WAIT! REGISTER NOW! Register your product within 90 days to ensure your product is recognized as an purchase and is for warranty coverage. Register online at or scan the QR code at https://anzzi.com/pages/register...
- Page 2 IMPORTANT: Warranty will not be recognized unless product is registered. https://anzzi.com/pages/register Register online at or Scan the QR code below. Registering online is fast, secure, and ensures we receive your information. USE YOUR PHONE CAMERA FILL IN A QUICK CLICK SUBMIT AND...
-
Page 3: Parts List
PARTS LIST IAPMO IGC 154 ASME A112.18.1/ CSA B125.1 Part Description Description Part [01] Shower Panel [07C] Screw [02A] [08] Washer [02B] Washer [09A] Base [02C] Shower Arm [09B] [03A] Gasket [10] Nipple A. Shower Head [03B] Shower Head [11] Hand Shower [04] Diverter Cartridge... -
Page 4: Tools And Material
PRODUCT SIZE CHART 20.23"[514mm] 2.75"[70mm] 5.91"[150mm] TOOLS AND MATERIAL Screwdriver Channel Locks oggles Rubber Mallet Tape Measure 1/4" Adjustable Wrench Teflon tape Allen key Pencil Electric drill pg. 4... -
Page 5: Before You Start
1. Prior to installation, please make sure your package is intact. Look over the product and contact your dealer or ANZZI if you find damaged sections. 2. In order to install this shower panel, simple understanding of plumbing techniques will be necessary. - Page 6 Before starting, measure the distance between the showerhead and valve. If the distance is between 26" - 38", a standard, centered installation is possible. Refer to Figure A and follow the steps on page 8 for Standard Installation. If the distance is outside this range, an Offset Installation is required. Refer to Figure B and follow the corresponding steps on page 9.
- Page 7 STEP 1 [08] connector [02B] [01] [02A] [02C] [03A] outlet [03B] Fig 1 Remove the Nut [02A] and Washer [02B] from the Shower Arm [02C] and slide the Shower Arm [02C] into the Shower Panel [01] from the front. From the back of the Shower Panel [01], slide the Washer [02B] on to the Shower Arm [02C] and secure it with Nut [02A].
- Page 8 STEP 2A - Outlet behind the Shower Panel (outlet falls between the outlet connector of shower arm and closest back bracket) 3"-15" connector of shower arm screw hole marking of Bracket [07B] 19.3" back bracket lower back line 2 bracket line 2 screw hole marking of Bracket [07B]...
- Page 9 STEP 2B - Outlet beside the Shower Panel optimal distance 8.4" - 14.4" outlet shower valve screw hole marking of Bracket [07B] back bracket 19.3" optimal distance lower back 8.4" - 14.4" bracket line 2 line 2 screw hole marking of Bracket [07B] align line 1...
- Page 10 STEP 3 1/4" [07A] Fig 3.1 Fig 3.2 [07B] [07C] Fig 3.3 IMPORTANT Before drilling any holes for the shower panel brackets, be sure there are no hidden cables or pipelines aligned with the desired drilling position. 3-1 Drill 1/4" holes at the marked positions. (Fig 3.1) 3-2 Install the Anchors [07A].
- Page 11 STEP 4 connector [01] [11] [12C] [13A] [08] [12A] [13A] [12B] connector 1 [13B] connector 2 Fig 4.1 Fig 4.2 Install the Hand Shower Holder [12C] through the hole on the right of Shower Panel [01]. Make sure the shower hose connector faces downward. (Fig 4.1) Slide the Washer [12B] onto the Hand Shower Holder [12C] from the inside of Shower Panel [01] and secure it by tightening the Nut [12A].
- Page 12 STEP 5 Base [09A] is for outlet positioned outside the shower panel installation only. outlet [09A] [10] hex nut Fig 5.1 Fig 5.2 Turn off the faucet. Remove the existing shower head and shower arm assembly. (Fig 5.1) Slide the Base [09A] on to the outlet.
- Page 13 STEP 6A - Outlet behind the Shower Panel hose Fig 6A.1 Fig 6A.2 Fig 6A.3 6A-1 Connect the hose to the Nipple [10] and tighten it to secure. (Fig 6A.1) 6A-2 Test all water functions by turning on the faucet before hanging the shower panel. Retighten if necessary, but do not overtighten.
- Page 14 STEP 6B - Outlet beside the Shower Panel [09B] [14] Fig 6B.1 Fig 6B.2 Fig 6B.3 6B-1 Slide the shower panel down until it rests on the mounting brackets. Slightly pull down the shower panel to secure. (Fig 6B.1) 6B-2 Use the Extended Hose [14] to connect the Nipple [10] and the hose of the shower panel.
-
Page 15: Care And Maintenance
Wipe all surfaces clean and rinse completely with water immediately after applying cleaner. Rinse and dry any overspray that lands on nearby surfaces. DO NOT ALLOW THE CLEANER TO SOAK. Following these simple procedures will ensure your ANZZI product remains as lustrous and stunning ®...
