Anzzi COLLINES SP-AZ079 Installation & Operation Manual

Shower panel
Hide thumbs

Advertisement

Quick Links

Download this manual
DON'T WAIT!
REGISTER NOW!
Register your product within 90 days to ensure your product is
recognized as an
coverage.
Register online at
PG. 2.
purchase and is
https://anzzi.com/pages/register
ANZZI COLLINES SHOWER PANEL
INSTALLATION & OPERATION MANUAL
for warranty
ITEM: SP-AZ079
or scan the QR code at
V1.0
08/01/2024

Advertisement

loading
Need help?

Need help?

Do you have a question about the COLLINES SP-AZ079 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Anzzi COLLINES SP-AZ079

Summary of Contents for Anzzi COLLINES SP-AZ079

  • Page 1 ITEM: SP-AZ079 ANZZI COLLINES SHOWER PANEL INSTALLATION & OPERATION MANUAL V1.0 08/01/2024 DON’T WAIT! REGISTER NOW! Register your product within 90 days to ensure your product is recognized as an purchase and is for warranty coverage. Register online at or scan the QR code at https://anzzi.com/pages/register...
  • Page 2 IMPORTANT: Warranty will not be recognized unless product is registered. https://anzzi.com/pages/register Register online at or Scan the QR code below. Registering online is fast, secure, and ensures we receive your information. USE YOUR PHONE CAMERA FILL IN A QUICK CLICK SUBMIT AND...
  • Page 3 PARTS LIST IAPMO IGC 154 ASME A112.18.1/ CSA B125.1 A. Shower Head Part Description Part Description [01] Shower Head [12A] Washer B. Body Jets [02] Shower Panel [12B] Spring Washer [03] Diverter Cartridge [12C] Butterfly Nut C. Diverter [04] Escutcheon [13] Hand Shower [05]...
  • Page 4 1. Prior to installation, please make sure your package is intact. Look over the product and contact your dealer or ANZZI if you find damaged sections. 2. In order to install this shower panel, simple understanding of plumbing techniques will be necessary.
  • Page 5 Mounting the Brackets of the Shower Panel -It is recommended that the shower panel be mounted at a height that will make the unit accessible to people with varying heights. Establish the precise height and position of the unit on the wall.
  • Page 6 PRODUCT SIZE CHART 19.69" [500 mm] 1.77" [45 mm] 7.87" [200 mm] pg. 6...
  • Page 7 STEP 1 Fig 1.2 [01] [12A] [12B] [12C] [02] Fig 1.3 shank outlet hose Fig 1.1 1-1 Install Shower Head [01] from the top of Shower Panel [02] as Fig 1.2 shows. 1-2 Slide Washers [12A] and Spring Washers [12B] to the screws of Shower Head [01] from the back of Shower Panel [02] and secure it with Butterfly Nuts [12C].
  • Page 8 STEP 2 screw hole marking of Bracket [10B] 37.8" lower back line 2 bracket screw hole marking line 2 of Bracket [10B] " 4 . 4 " - align 2 . 2 line 1 [10B] Fig 2.1 Fig 2.2 Fig 2.3 2-1 Position the shower panel on the wall according to figure A on page 5.
  • Page 9 STEP 3 1/4" [10A] Fig 3.1 Fig 3.2 [10B] [10C] Fig 3.3 IMPORTANT Before drilling any holes for the shower panel brackets, be sure there are no hidden cables or pipelines aligned with the desired drilling position. 3-1 Drill 1/4" holes at the marked positions. (Fig 3.1) 3-2 Install the Anchors [10A] .
  • Page 10 STEP 4 connector [02] [13] [14C] [15A] [11] [14A] [15A] [14B] connector 1 [15B] connector 2 Fig 4.1 Fig 4.2 Install the Shower Holder [14C] through the hole from the right of Shower Panel [02]. Make sure the shower hose connector faces downward. (Fig 4.1) Slide the Washer [14B] to the Shower Holder [14C] from the inside of Shower Panel [02] and secure it by tightening the Nut [14A].
  • Page 11 STEP 5 IMPORTANT: Before connecting the inlet hoses and water supplies, turn on cold and hot water supplies and flush water lines for one minute. This flushes away any debris that could cause damage to internal parts. pg. 11...
  • Page 12 STEP 6 [16] [17] Fig 6.1 Fig 6.2 Fig 6.3 Install Washers [16] and Elbow Fittings [17] to the outlet. Adjust the direction of the Elbow Fittings [17] and tighten them. DO NOT OVER TIGHTEN! (Fig 6.1) Connect the Hoses labeled with "Hot" or "Cold" to the Elbow Fittings [17], then tighten the nuts of the hoses.
  • Page 13 CARE AND MAINTENANCE × The water flow is normal The water flow becomes smaller Remove the hot and cold Clean the filter screen. Install the filter and connect water pipes and take out the hot and cold water pipes. the filter screen. Note: If the water flow becomes smaller, please clean the filter screen at the inlet hoses.
  • Page 14 CARE AND MAINTENANCE IMPORTANT: It is not recommended that the user disassemble the thermostatic cartridge by himself, and it is recommended to ask professional personnel for treatment. Remove the plug. Loosen the screw with the Remove the thermostatic handle. hexagon wrench. Note: The rod of cartridge can only be rotated when the handle is right in place.
  • Page 15 CARE AND MAINTENANCE The white dot must be aligned with 104 degrees Fahrenheit and face up. Put the cartridge back into Secure the cartridge with Install the thermostatic the faucet. bonnet nut again. restrictor back again. Note: Beware the side hole of the cartridge is pointing downside and aligning with the side hole of body.
  • Page 16 Wipe all surfaces clean and rinse completely with water immediately after applying cleaner. Rinse and dry any overspray that lands on nearby surfaces. DO NOT ALLOW THE CLEANER TO SOAK. Following these simple procedures will ensure your ANZZI product remains as lustrous and stunning ®...
