White Rodgers 36J22 Installation Instructions Manual

Operator: Save these instructions for future use!
FAILURE TO READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY
BEFORE INSTALLING OR OPERATING THIS CONTROL COULD CAUSE
PERSONAL INJURY AND/OR PROPERTY DAMAGE.
The 36J22/24/54/55 combination gas valves are de-
signed for direct spark ignition (DSI) and hot surface
ignition (HSI) system applications. These valves
are equipped with redundant and main solenoid
valves that control gas flow to the main burners, a
pressure regulator and a two-position on/off switch
for regulation and electrical shut-off of the solenoid
valves. The 36J24 and 36J55 are also equipped
with a slow-opening pressure regulator for softer
lighting characteristics. When the second solenoid
on 2-stage valves is energized the valve operates
at the second stage (high) outlet pressure setting.
Model Coil
Number Voltage
36J22 24V
36J24 24V
36J54 24V
36J55 24V
Pressure Regulator Adjustment Range (in W.C.)
Gas Single
Low
Type Stage
Natural 2.5 – 5.0 1.0 – 4.0 2.0 – 5.0
LP 7.0 – 12.0 4.0 – 10.0 6.0 – 12.0
CONTENTS
Description ........................................................ 1
Specifications .................................................... 1
Precautions ....................................................... 2
Installation
System Wiring ...................................... 3
Adjustment
Pressure Regulator Adjustment ............ 6
Lighting Instructions ..........................................
Contents French
................................................ 9
Contents Spanish
............................................ 17
36J22, 36J24, 36J54 and 36J55
DSI and HSI Single and Two Stage
INSTALLATION INSTRUCTIONS
Opening
Stages
Characteristics
1 Fast
1 Slow
2 Fast
2 Slow
Two Stage
Min. Diff.
High
Low to High
1
2
8
www.white-rodgers.com
www.emersonclimate.com
Combination Gas Valves
36J Single Stage
Fig. 1
Intermittent Pilot
HSI
Proven Pilot
No Yes
No Yes
No Yes
No Yes
SPECIFICATIONS
PIPE SIZES/CAPACITIES
Capacity (BTU/hr) at
1" pressure drop across valve
Pipe Sizes
Available
AGA Std. Nat. Gas
(inches)
(1,000 BTU/cu. ft.)
1 /2" x 1 /2" NPT
140,000
Type of Gas: Natural gas
LP gas (use conversion kit)
Ambient Temperature: -40° to 175°F
Pressure Rating: 14" W.C. (½ PSI) max.
Voltage: 24 VAC
Frequency: 50/60 Hz
Current: Single Stage – 0.28A
Two-Stage – 0.43A
Mounting Positions: Multipoise – Control may
be mounted in any position
DESCRIPTION
36J Two-Stage
Standing
DSI
Pilot
Yes No
Yes No
Yes No
Yes No
LP Gas
(2,500 BTU/cu. ft.)
226,800
PART NO. 37-7338A
1224
