- Page 1 Installation Instructions and User Guide Gallery Rapid Boiling 3-in-1 ScaleFilter Sink Mixer Chrome Models Covered: GLL RAPSNK3 SF C Please keep this booklet for future reference. Installer, when you have read these instructions please ensure you leave them with the user.
-
Page 2: Table Of Contents
Contents Thank you for choosing Bristan, the UK’s leading tap and shower expert. We have designed this product to be easy to install and use. It has also been assessed to all of the relevant British Standards, and conforms to UKCA and CE Regulations. -
Page 3: Important Safety Information
• Please read these instructions thoroughly and retain for future use. • All products manufactured and supplied by Bristan are safe provided they are installed, used correctly and receive regular maintenance in accordance with these instructions. • If you are in any doubt about your ability to... - Page 4 Important Safety Information • The filter supplied must be replaced every six months for protection of your Boiling Water Tank. Failure to do so will invalidate your guarantee. • To protect against electric shock, do not place the cord, plugs or Boiling Water Tank near or in water/ other liquids.
-
Page 5: Specification
Commercial Prior to Installation Pack Contents All products manufactured and supplied by Bristan are safe to use provided they are installed, operated correctly and receive regular maintenance in accordance with these instructions. This product has been designed to comply with the Water Supply (Water Fittings) Regulations 1999 and current bylaws. -
Page 6: Installation Requirements
Installation Requirements Positioning the Boiling Water Tank Place the tank in a suitable, well ventilated location that will not fall below 0°C. Ensure that the tank is installed vertically on Also ensure that the a level surface with adequate space around the Filter is in an easily tank. -
Page 7: Connection Diagram
Installation Requirements IMPORTANT Connection Diagram The PRV, filter and isolation valves, are required for optimum performance and maintenance of your product IMPORTANT Ensure water Household quality has been tested and the Pipework Isolation Valves filter head is set (not supplied) correctly before installation (pg9). -
Page 8: Installation
Installation Attach the connecting pipes as shown. See the Connection Diagram for guidance. Tighten the hose clip to secure in place. Plain Boiling Water Flexible Tail Pipe & Hose Cold Flexible Tail Flexible Tail Feed the pipes through the sink hole and place the tap body. -
Page 9: Filter Commissioning
Installation IMPORTANT Do not tamper IMPORTANT with the PRV as Ensure the plastic this will affect the shroud covers performance of the silicon hose your tap. connector. This is a safety feature to prevent accidental scalding. Cold Screw the hose Connect the domestic adaptor on to the hot and cold water... - Page 10 Installation Using the result of the water test carried out in Step 7, push and turn the pre-fitted blue key to the required filter setting. The key must then be removed from the filter head and kept for future adjustment. Push the supplied pipework reducers into the filter head.
-
Page 11: Prime The Filter/Tank
Installation Connect the filter outlet to the blue boiling water tank connector. Attach the filter sump to the filter head. Prime the Filter/Tank Place a jug under the spout and expel all air from the system. Check connections for any leaks. Run off at least 20 litres of water from the Boiling Water Touch Control handle, resting the system every... -
Page 12: Operation
Operation Light-up Status Arc: Flashing = Warming Up Current Temperature ºC Setting Setting Heating Actual Water Actual ºC Temperature Confirm Temperature Setting Change Temperature Setting: Choose from 75°C, 85°C, 90°C, On/Off 95°C, 96°C, 97°C and 98°C Start-Up/Change Temperature Press the Change ºC Setting... -
Page 13: General Cleaning
Operation Optimum Temperatures Temperature Suitable For 75°C Green Tea Instant Coffee/ 85°C Oolong Tea Oolong Tea/ 90°C Brewing Coffee 95°C Brewing Coffee 96°C 97°C Black Tea/Herbal Tea 98°C Operation - Boiling Water Cold Boiling Setting ºC Water Actual ºC Set up the Boiling Water Tank temperature (see pg10). -
Page 14: Maintenance
Maintenance Cleaning Outlet Using a Return suitable the aerator solution, scrub ensuring and wash the washer the aerator IMPORTANT is in place. Isolate the until fully Screw on water supply de-scaled. Unscrew the the casing. before starting! Rinse aerator casing and hold the thoroughly. -
Page 15: Changing The Filter
Maintenance Changing the Filter IMPORTANT Your filter cartridge must be replaced every six months to ensure adequate performance and maintain the guarantee. Isolate the water supply and draw off Switch off the Boiling Water Tank. all remaining water. Turn on the water supply. Follow the Prime Filter/Tank section to re-prime the filter. -
Page 16: Maintenance Schedule
We have included this maintenance schedule in order to help keep track of when to replace your filter; which can be ordered using RAP SCALE FILT on the Bristan website. Please ensure your plumber fills in the date of installation. Date Installed/Replaced... -
Page 17: Troubleshooting
Troubleshooting Symptom Cause Remedy Boiling Water Tank is empty at first Follow the Preparation for Use section. switch-on. ‘99’ flashing in the ‘Set Temperature’ display. Boiling Water Tank isn’t holding water. Check connections for any leaks/blockages. Contact Customer Services. E3 Error Code in the No Water in Tank after first use ‘Set Temperature’... -
Page 18: Notes
Notes Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors. - Page 19 Notes Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
- Page 20 Email: enquire@bristan.com A Masco Company At Bristan, we want to make things as easy as possible for our customers. That’s why we offer solid guarantees on all our products, effective from the date of purchase, to give you peace of mind.
