Buyers SaltDogg 1470601SSH Installation Instructions Manual

1470601SSH - 8 ft. Stainless Steel Hydraulic
Drive Auger Sreader
2.0 Cubic Yards

Table of Contents

General Information ....................................................................1
Safety Precautions ...................................................................1-2
Installation Instructions ........................................................... 1-3
Spreader Operation ....................................................................4
Spreader Maintenance ............................................................ 4-5
Repair Parts & Drawings ..........................................................5-7
Warranty Information ..................................................................8
General Information
Overall Length: 111.75 inches
Overall Width: 48 inches
Overall Height: 32.25 inches
Empty Weight: 740 lbs.
Capacity Struck: 2.0 cu. yd.
Vehicle Requirements
Trucks with minimum GVWR 13,000 lbs. (8 ft. bed), 150 AMP or
higher alternator is recommended.
Average Material Weights
This spreader is restricted to the use of dry, free-flowing salt,
sand, and sand/salt mix. Do not run other materials through the
spreader.
Materials to use
Fine Salt-Dry
Coarse Salt-Dry
Sand/Salt up to 50/50 Mix-Dry
Note: To calculate the total spreader weight (including ice
control material), add the empty spreader weight plus the ice
control material and spreader accessories.
CAUTION
Do not overload vehicle beyond the vehicle's GVWR or GAWR.
Check vehicle's load rating certification sticker for maximum
vehicle capacity.
WARNING
Improper installation and operation could cause personal
injury, and/or property damage. Observe the following Safety
Precautions before, during and after operating this spreader. By
following these precautions and common sense, possible injury
to persons and potential damage to this machine may be avoided.
Installation Instructions
Weight (pounds per cubic yard)
2,250
1,431
2,700
Phone (440) 974-8888 • Fax (800) 841-8003
This spreader was built to be operated according to the
safe operation practices in this manual. As with any type of
power equipment, carelessness or error on the part of the
operator can result in serious injury. This spreader is capable
of amputating hands and feet and throwing objects. Failure to
observe the following safety instructions may result in serious
injury or death.
Improper installation and operation could cause personal
injury, and/or property damage. Observe the following Safety
Precautions before, during and after operating this spreader.
By following these precautions and common sense, possible
injury to persons and potential damage to this spreader may be
avoided.
Safety Precautions
1. Read the entire Installation Instructions before operating this
spreader.
2. Read and understand all safety decals on the spreader
before operating.
3. Check to make sure all safety guards are securely mounted
into place before operating this spreader.
4. Verify that all personnel are clear of the spreader spray area
before starting or operating this spreader.
5. Do not over-load your vehicle beyond payload limits. If there
are any questions, contact the vehicle manufacturer.
6. Do not adjust, clean, lubricate or unclog material jambs
without first turning off the spreader.
7. Do not climb on or in the spreader during operation. Do not
ride on the spreader while the vehicle is in motion.
8. Make sure the spreader is securely fastened to the vehicle in
accordance with this manual.
9. Do not operate a spreader that is in need of maintenance or
repairs.
10. Do not operate the spreader while ill, tired, or under the
influence of alcohol or drugs.
1
9049 Tyler Blvd. • Mentor, Ohio 44060
www.buyersproducts.com
DANGER
WARNING
-continued inside
