Buyers SaltDogg 1470601SSE Installation Instructions Manual

1470601SSE - 8 ft. Stainless Steel Electric
Drive Auger Sreader
2.0 Cubic Yards
Table of Contents
General Information ....................................................................1
Safety Precautions ......................................................................1
Installation Instructions ........................................................... 1-3
Spreader Operation ....................................................................4
Spreader Maintenance ............................................................ 4-5
Repair Parts & Drawings ..........................................................5-7
Warranty Information ..................................................................8
General Information
Overall Length: 111.75 inches
Overall Width: 48 inches
Overall Height: 32.25 inches
Empty Weight: 995 lbs.
Capacity Struck: 2.0 cu. yd.
Vehicle Requirements
Trucks with minimum GVWR 13,000 lbs. (8 ft. bed), 150 AMP or
higher alternator is recommended.
Average Material Weights
This spreader is restricted to the use of dry, free-flowing salt,
sand, and sand/salt mix. Do not run other materials through the
spreader.
Materials to use
Fine Salt-Dry
Coarse Salt-Dry
Sand/Salt up to 50/50 Mix-Dry
Note: To calculate the total spreader weight (including ice
control material), add the empty spreader weight plus the ice
control material and spreader accessories.
CAUTION
Do not overload vehicle beyond the vehicle's GVWR or GAWR.
Check vehicle's load rating certification sticker for maximum
vehicle capacity.
WARNING
Improper installation and operation could cause personal
injury, and/or property damage. Observe the following Safety
Precautions before, during and after operating this spreader. By
following these precautions and common sense, possible injury
to persons and potential damage to this machine may be avoided.
Installation Instructions
Weight (pounds per cubic yard)
2,250
1,431
2,700
Phone (440) 974-8888 • Fax (800) 841-8003
Safety Precautions
1. Read the entire Installation Instructions before operating this
spreader.
2. Read and understand all safety decals on the spreader
before operating.
3. Check to make sure all safety guards are securely mounted
into place before operating this spreader.
4. Verify that all personnel are clear of the spreader spray area
before starting or operating this spreader.
5. Do not over-load your vehicle beyond payload limits. If there
are any questions, contact the vehicle manufacturer.
6. Do not adjust, clean, lubricate or unclog material jambs
without first turning off the spreader.
7. Do not climb on or in the spreader during operation. Do not
ride on the spreader while the vehicle is in motion.
8. Make sure the spreader is securely fastened to the vehicle in
accordance with this manual.
9. Do not operate a spreader that is in need of maintenance or
repairs.
10. Do not operate the spreader while ill, tired, or under the
influence of alcohol or drugs.
11. Batteries normally produce explosive gases which can
cause personal injury. Always disconnect the battery before
removing or replacing electrical components.
12. Do not leave unused material in hopper. Material can
freeze or solidify, causing spreader to not work properly, and/or
damage the unit. Empty and clean after each use.
Installation Instructions
1. Mounting the Spreader onto the Vehicle
A. Remove the tailgate from the vehicle (if equipped) as well as
any other object which will interfere with the spreader.
B. Remove chute, hardware kit from inside spreader. If spreader
has been used make sure there is no material left in the hopper.
C. Lift spreader using all tie downs (Fig. 1), or elevate the
spreader off the vehicle with lumber. Place lumber under the
side gussets of the spreader. This will help with removal of
excess material that accumulates under the spreader.
1
9049 Tyler Blvd. • Mentor, Ohio 44060
www.buyersproducts.com
—continued inside
