Stainless Steel
Self-Contained Hopper Spreaders
Table of Contents
Warranty Information .................................................. 1
General Information ................................................. 1-2
Safety Precautions ..................................................... 2
Installation Instructions ............................................ 2-4
Chute Installation ........................................................ 4
Spreader and Chute Operation ...............................5-6
Spreader Maintenance ............................................... 6
Optional Equipment .................................................... 7
Repair Parts & Drawings ........................................8-12
SPREADER WARRANTY INFORMATION
This warranty replaces all previous warranties and no employee of
this company is authorized to extend additional warranties, or agree-
ments, or implications not explicitly covered herein. Buyers Products
Company warrants all parts of the product to be free from defects in
material and workmanship for a period of one (1) year, excluding the
gasoline engine, from the date of installation. Parts must be properly
installed and used under normal conditions. Normal wear is excluded.
Any part which has been altered, including modifications, misuse, acci-
dent, or lack of maintenance will not be considered under this warranty.
The sole responsibility of Buyers Products Company under this war-
ranty is limited to repairing or replacing any part(s) which are returned,
prepaid, 30 days after such defect is discovered, and returned part(s)
are found to be defective by Buyers Products Company. Authorization
from Buyers Products Company must be obtained before returning
any part. The following information must accompany defective parts
returned to Buyers Products Company: RMA#, spreader model, serial
number, date installed, and distributor from whom purchased. Buyers
Products Company shall not be liable for damage arising out of failure
of any unit to operate properly, or failure, or delay in work, or for any
consequential damages. No charges for transportation or labor per-
formed on any part will be allowed under this warranty. The gasoline
engine is solely warranted through engine's manufacturer. All engine
related warranty claims are to be processed through the engine's man-
ufacturer. This information is explained in the engine owner's manual.
Spreader Models and Specifications
HOPPER
MODEL #
POWER
LENGTH
1400455SS
Gas
96"
1400460SS
Gas
108"
1400465SS
Gas
120"
1400475SS
Gas
96"
1400500SS
Gas
108"
1400550SS
Gas
120"
Installation Manual
OVERALL
OVERALL
EMPTY
LENGTH
WIDTH
WEIGHT
CAPACITY
115.9"
58"
1,395 lbs.
2.5 yds.
127.9"
58"
1,460 lbs.
2.75 yds.
138.9"
58"
1,526 lbs.
3.0 yds.
116"
70"
1,470 lbs.
3.5 yds.
128"
70"
1,500 lbs.
4.0 yds.
140"
70"
1,560 lbs.
4.5 yds.
Phone (440) 974-8888 • Fax (440) 974-0165
Toll-Free Fax 800-841-8003 • buyersproducts.com
General Information
1. Recommended Vehicle Requirements:
This spreader is to be used on trucks with dump
bodies or flat bed trucks with a Gross Vehicle Weight
Rated chassis of 15,000 lbs. or greater.
Do not overload vehicle beyond the vehicle's Gross
Vehicle Weight Rating (GVWR) or Gross Axle Weight
Ratings (GAWR). Check the vehicle's load rating cer-
tification sticker for maximum vehicle capacity.
2. Average Material Weights:
MATERIAL
#1 Rock Salt
#2 Rock Salt
Coarse Sand - Dry
Coarse Sand - Wet
Note: To calculate the total spreader weight
(including ice control material); add the empty
spreader weight plus the ice control material and
spreader accessories.
1
9049 Tyler Blvd. • Mentor, Ohio 44060
CAUTION
WEIGHT (POUNDS PER CUBIC YARD)
950
1,215
2,565
3,240
