Buyers 14708F460211 Installation Manual

Stainless Steel Hopper Spreaders,
Chain Feed
Contents
Stainless Steel Self-Contained Hopper Spreaders ............ 1
Recommended Vehicle Requirements: .............................. 1
Average Material Weights ................................................... 1
Safety Precautions ............................................................. 1
Safety Symbols .................................................................. 2
Installation Instructions ...................................................... 3
Control Box and Vehicle Wiring Harness Installation ......... 3
Spinner/Chute Assembly Operation ................................... 4
Installation Instructions - Hydraulic Models ....................... 5
Spreader Operation - Hydraulic Models ............................ 5
Spreader Maintenance ....................................................... 6
SPREADER WARRANTY INFORMATION
This warranty replaces all previous warranties and no employee of this
company is authorized to extend additional warranties, or agreements, or
implications not explicitly covered herein.
Buyers Products Company warrants all parts of the product to be free from
defects in material and workmanship for a period of one (1) year. Parts must
be properly installed and used under normal conditions. Normal wear is
excluded.
Any part which has been altered, including modifications, misuse, accident,
or lack of maintenance will not be considered under this warranty.
The sole responsibility of Buyers Products Company under this warranty is
limited to repairing or replacing any part(s) which are returned, prepaid, 30
days after such defect is discovered, and returned part(s) are found to be
defective by Buyers Products Company.
Authorization from Buyers Products Company must be obtained before
returning any part. The following information must accompany defective
parts returned to Buyers Products Company: RMA#, spreader model, serial
number, date installed, and distributor from whom purchased.
Buyers Products Company shall not be liable for damage arising out of failure
of any unit to operate properly, or failure, or delay in work, or for any conse-
quential damages. No charges for transportation or labor performed on any
part will be allowed under this warranty.
Spreader Models and Specifications
HOPPER
MODEL # POWER LENGTH
14708F460211 Electric 96
14708F462211 Hydraulic 96
14708F380211 Electric 96
14708F382211 Hydraulic 96
14709F460211 Electric 108
14709F462211 Hydraulic 108
14709F380211
Electric 108
14709F382211
Hydraulic 108
14709F520211
Electric 108
14709F522211
Hydraulic 108
14710F460211
Electric 120
14710F462211
Hydraulic 120
14710F380211 Electric 120
14710F382211 Hydraulic 120
14710F520211 Electric 120
14710F522211 Hydraulic 120
Installation Manual
OVERALL OVERALL EMPTY CAPACITY
LENGTH WIDTH WEIGHT (YDS.)
109 70 1636 3.00
109 70 1636 3.00
109 58 1426 2.50
109 58 1426 2.50
121 70 1803 4.00
121 70 1803 4.00
121 58 1572 2.75
121 58 1572 2.75
121 70 1910 5.00
121 70 1910 5.00
133 70 1913 4.50
133 70 1913 4.50
133 58 1668 3.00
133 58 1668 3.00
133 70 2028 5.50
133 70 2028 5.50
General Information

Recommended Vehicle Requirements:

This spreader is to be used on trucks with dump bodies or
flatbed trucks with a Gross Vehicle Weight Rated chassis
of 15,000 lbs. or greater.
Do not overload vehicle beyond the vehicle's Gross
Vehicle Weight Rating (GVWR) or Gross Axle Weight
Ratings (GAWR). Check the vehicle's load rating certi-
fication sticker for maximum vehicle capacity.

Average Material Weights:

MATERIAL WEIGHT (pounds per cubic yard)
• Rock Salt - 2,160 lbs per cubic yard
• Sand weight, course dry - 2,565 lbs per cubic yard
• Sand weight, course wet - 3,240 lbs per cubic yard
Note: To calculate the total Gross Spreader Weight
(including ice control material), add the empty spreader
weight plus the ice control material and spreader
accessories.

Safety Precautions

This symbol points out important safety instructions which,
if not followed, could endanger the personal safety and/or
property of yourself and others. Read and follow all instructions
in this manual before attempting to install or operate this
spreader. Failure to comply with these instructions may result in
personal injury. When you see this symbol. HEED ITS WARNING!
1
www.buyersproducts.com
Phone (440) 974-8888
Fax 800-841-8003
CAUTION
