  • Page 1 ™ DECT digital monitor...

  • Page 3: Table Of Contents

    Contents 02………………………… Welcome 03………………………… Important Safety Instructions 06………………………… Parts Checklist 07………………………… Quick Reference Guide 09………………………… Preparing Your Baby Monitor - Default Settings - Power - Positioning and Operating Range 13………………………… Baby Monitor Features - Turning the Units On/Off - Adjusting Speaker Volume - Adjusting Microphone Sensitivity - Sound Level Indicators &...

  • Page 4: Welcome

    Welcome Crystal Sounds DECT Thank you for purchasing the VTech ® Digital Monitor. VTech is dedicated to producing reliable ® telecommunications, baby gear and toy products that give parents the reassurance they need. This VTech baby monitor provides support by ®...

  • Page 5: Important Safety Instructions

    SAVE THESE INSTRUCTIONS Important Safety Instructions When using your equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: 1. Do not use this product near water, for example, near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
  • Page 6 10. Children should be supervised to ensure that they do not play with the appliance. 11. Use only the specified type of battery. Warranty is voided if other batteries are used. Please contact VTech for a replacement ® battery pack. Contact information can be found on the last page of these instructions.

  • Page 7: Technical Specifications

    9. Batteries should not be exposed to excessive heat such as bright sunshine or fire. Electromagnetic Fields (EMF) This VTech baby monitor appliance complies with all standards ® regarding electromagnetic fields (EMF). If handled properly and according to the instructions in this user manual, the appliance is safe to use based on scientific evidence available today.

  • Page 8: Parts Checklist

    Parts Checklist Included in this package: • User’s manual • Baby unit • Parent unit Model: 1022 Model: 1022C • Two adaptors 6V DC 300mA 6V DC 500mA (for parent unit only) (for baby unit only) • Ni-MH Rechargeable batteries 2 x AAA (AM-4/LR03), 1.2V, 750mAh...

  • Page 9: Quick Reference Guide

    Quick Reference Guide Baby Unit 1. On/off button 10. Adaptor 2. PAGE button 11. Large appliance plug 3. Power-on light 12. Socket for large appliance plug 4. Battery light 13. Speaker 5. Volume (+) button 14. Battery compartment 6. Volume (-) button 15.
  • Page 10 Parent Unit 1. On/off button 10. Socket for small appliance plug 2. Secure link indicator 11. Small appliance plug 3. Battery light 12. Rechargeable batteries 4. Speaker compartment 5. Sound level indicators 13. Battery compartment 6. Volume(+) button cover 7. Volume(-) button 14.

  • Page 11: Preparing Your Baby Monitor

    Preparing Your Baby Monitor Default Settings The first time you turn on the parent and baby units, they are operating with default settings. Adjustments can be made. Please see corresponding sections in this manual for instructions. Speaker volume setting (baby and parent unit)..page 14 Default: level 3 (out of 5 levels) Sensitivity setting (parent unit)..page 14 Default: level 3 (out of 5 levels)
  • Page 12 Battery operation 1. The baby unit runs on 4 pcs 1.5V AA (AM-3/LR6) batteries (not included). Please use alkaline batteries for best performance. 2. Do NOT use rechargeable batteries, as the baby unit does not have a charging function. 3. Place 4 pcs 1.5V AA (AM-3/LR6) batteries into the baby unit’s battery compartment, noting the + and - configuration.

  • Page 13: Positioning And Operating Range

    Note: • When you charge the parent unit for the first time or after a long period of non-use, turn it off and let it charge continuously for at least 10 hours. • Charging normally takes 12-14 hours, but it takes longer when the parent unit is on while charging.
  • Page 14 Technical Specifications: Loss of Material Dry Materials Range Thickness Wood, plaster, cardboard, glass < 12 inches 0-10% (without metal, wires or lead) Brick, plywood < 12 inches 5-35% < 12 inches Reinforced concrete 30-100% < 1/2 inch Metal grills or bars 90-100% <...

  • Page 15: Baby Monitor Features

    Baby Monitor Features Turning the Units On/Off Baby unit 1. Press and hold the on/off button for about 2 seconds to turn on the unit. 2. The ON light on the baby unit will briefly light 3. Press and hold the on/off button for about 2 seconds to turn off the unit.

  • Page 16: Adjusting Speaker Volume

    Adjusting Speaker Volume 1. Press the volume control buttons (+,-) on the parent unit until the desired speaker volume for the parent unit has been reached. There are 5 volume levels. 2. The sound level indicators show the volume level during adjustment: - OOOOO = Parent unit volume is off - OOOOO = Minimum volume...

  • Page 17: Paging The Parent Unit

    indicators light up on the parent unit. 1. As long as the baby unit does not detect a sound, the sound level indicators on the parent unit will not be lit. 2. When the baby unit picks up a sound, one or more sound level indicators light up on the parent unit.

  • Page 18: Out Of Range Alert

    Lullabies 1. Brahms Lullaby (with singing voice) 2. Rock-A-Bye, Baby - Traditional 3. Fais Do Do - French Traditional 4. Au Clair de la Lune - French Traditional 5. Berceuse - Chopin 6. Twinkle, Twinkle - Traditional 7. La Berceuse - Brahms 8.

  • Page 19: Troubleshooting

    Troubleshooting Problem Possible causes Solutions Secure link No power from Recharge parent unit parent unit. by connecting it to a indicator on power supply. parent unit does not light up when No power from Replace with new the on/off button baby unit.
  • Page 20 Problem Possible causes Solutions Parent unit Parent unit has lost Reduce the distance beeps. connection with between the units, baby unit. but not closer than 3 feet. Turn on the baby unit. Rechargeable Recharge the parent unit by connecting it batteries in parent to the power supply.
  • Page 21 Problem Possible causes Solutions Parent unit reacts Baby unit microphone Use the parent unit too slowly to sensitivity level is too to increase the baby sounds from the low. unit’s microphone baby unit. sensitivity level. Parent unit reacts Baby unit picks up Move baby unit too quickly to sounds other than...
  • Page 22 Problem Possible causes Solutions Parent unit Baby unit Use the parent unit to decrease operating microphone the baby unit’s time is shorter sensitivity level is too microphone than specified high and consumes sensitivity level. operating time power quickly. of at least 24 Baby unit volume Decrease the baby hours...

  • Page 23: Frequently Asked Questions

    Frequently Asked Questions 1. The technical specifications show an operating range of 1000 feet. Why does my monitor lose connection at a much shorter distance? The 1000-feet specified operating range is only valid outdoors in open air. Inside a home, the number and type of walls and ceilings between the baby and parent units limit the operating range.

  • Page 24: Appendix

    Appendix Cleaning and Maintenance Do not immerse the parent unit or the baby unit in water and do not clean them under the tap. Do not use cleaning spray or liquid cleaners. 1. Unplug the baby and parent units if they are connected to a power source.

  • Page 25: Environmental Notices

    • Adaptor Only replace the adaptor of the parent unit with an adaptor of the same type. Contact Consumer Services at 1-800-521-2010 in the US or 1-877-352-8697 in Canada for replacement parts. Environmental Notices 1. This baby monitor is designed and manufactured with high quality materials and components that can be recycled and reused.

  • Page 26: Rf Radiation Exposure Statement

    4. Consult the dealer or an experienced radio/TV technician for help. Caution: changes or modifications to this equipment not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 27: Assistance

    If a problem persists, please call our Consumer Services Department at 1-800-521-2010 in the U.S. or 1-877-352-8697 in Canada, and a service representative will be happy to help you. For information on this product’s warranty, please call VTech ® 1-800-521-2010 in the U.S. or 1-877-352-8697 in Canada.
  • Page 28 1022/1022C © 2009 VTech Printed in China 91-102200-001...
