- Page 1 Push Button Pendants 80 Series Installation, Operation & Maintenance Manual XA-960400.5-US - 02.17.25 80 SERIES PUSH BUTTON PENDANTS MANUAL...
- Page 2 Buyer’s name - provided that Seller shall have the right to elect to defend any such suit or action for the account of Buyer. The foregoing shall be the exclusive remedies of the Buyer and all persons and entitles claiming through the Buyer. 80 SERIES PUSH BUTTON PENDANTS MANUAL...
-
Page 3: Conductix-Wampfler Field Service
Ask us for a quote on expert system installations,inspections, preventative maintenance, and repairs/retrofits. As the world’s largest single source manufacturer of mobile electrification products, Conductix-Wampfler has the unique ability to offer a degree of service not found anywhere else. Conductix-Wampfler’s team of highly qualified service technicians and engineers have years of experience servicing our complete line of products. -
Page 4: Table Of Contents
4.0 Disassembly of the Enclosure 4.1 Mounting Switches 4.2 Mounting Mushroom Head and Selector, Switches 4.3 Cable Installation 4.4 Button Legends 4.5 Vertical Legends 4.6 Reassembly of the Enclosure SECTION 5 - SWITCH SCHEMATICS 14-15 80 SERIES PUSH BUTTON PENDANTS MANUAL... -
Page 5: Section 1 - Safety
1.2.4 All products are subject to technical modifications in the context of improvement of function and further development. 80 SERIES PUSH BUTTON PENDANTS MANUAL... -
Page 6: Personnel Requirements-Qualifications
Keep unauthorized personnel away from the working area. In case of doubt, address the person and direct them away from the working area. Stop working, as long as unauthorized persons are in the working area. 80 SERIES PUSH BUTTON PENDANTS MANUAL... -
Page 7: Personnel Requirements-Training
Breathing mask (FFP-3 - according to country-specific requirements): For protection against materials, particles, and organisms. In this case, for protection against the dust produced by the abrasion of carbon brushes and the PVC insulation of the conductor rail. 80 SERIES PUSH BUTTON PENDANTS MANUAL... -
Page 8: Section 2 - Product Disposal
All other components are to be disposed of in accordance with their material composition. Take care with items identified as Substances of Concern. 2.0.3 Local authorities or special disposal companies can provide information about environmentally appropriate disposal. 80 SERIES PUSH BUTTON PENDANTS MANUAL... -
Page 9: Section 3 - Specifications
3.2.3 Outdoor Use Warning 3.2.3.1 While the 80 Series Pendant is designed for NEMA 4X rated environments and certified for indoor use only by UL, Conductix- Wampfler permits outdoor use under specific conditions. Proper shielding and storage (e.g., protective case and cover) are essential to protect the pendant from weather extremes such as UV light, ice, or snow. -
Page 10: Section 4 - Installation
Tighten switch screws securely. (Depending on switch, there will be either two or four screws.) Torque to 20 in-lbs. Clear Switch Cover Button Legend (Sticky Side Up) Switch Boot Enclosure Switch Switch Screws Figure: 4.2 80 SERIES PUSH BUTTON PENDANTS MANUAL... -
Page 11: Mounting Mushroom Head And Selector, Switches
Firmly fasten tightening ring to secure frame. Align the notches for the tightening ring with the screw holes in the enclosure. The switch has tabs that fit into the cut-outs on the frame. Misalignment will prevent the switch from seating properly. Mushroom Switch or Selector Switch Tightening Ring Figure: 4.3 80 SERIES PUSH BUTTON PENDANTS MANUAL... -
Page 12: Cable Installation
Wire lengths must be a minimum of 6” long according to NEC code. Route wires along the inside of the housing. Never leave wire on top of switch due to interference with back cover installation. 80 SERIES PUSH BUTTON PENDANTS MANUAL... -
Page 13: Button Legends
4.6.2 Ensure that the enclosure seal gasket is in place in the slot of the enclosure cover. 4.6.3 Remove all wire waste and debris from inside the enclosure case. 4.6.4 Install the enclosure cover and tighten enclosure screws. 80 SERIES PUSH BUTTON PENDANTS MANUAL... -
Page 14: Section 5 - Switch Schematics
34314D - (2K) 34298 34314 - (5K) 34314C - (10K) 34296 34304 Blind rubber gasket with metal plate 34298 - same as 34297 but with delayed opening of contacts 7&8 “Break-Before- Make” contact arrangement 34323 80 SERIES PUSH BUTTON PENDANTS MANUAL... - Page 15 Toggle, 1NC, 1NO 37127 Toggle, 1NO, 1NC 34314B Variable position resistor (1K) 34314D Variable position resistor (2K) 34314 Variable position resistor (5K) 34314C Variable position resistor (10K) 34304 Blind rubber gasket with metal plate 80 SERIES PUSH BUTTON PENDANTS MANUAL...
- Page 16 To provide you with energy and data transmission systems that will keep your operations up and running 24/7/365. To contact your nearest sales office, please refer to: www.conductix.contact 80 SERIES PUSH BUTTON PENDANTS MANUAL XA-960400.5-US - 02.17.25...
