Melec GDB-5KS20 Instruction Manual page 43

１０－４．Applicable Motors
(1) GDB-5KS20 can drive a 5-phase stepping motor with 0.35A/phase.
① Examples of applicable motors
SANYO DENKI Co., Ltd.
□28mm SH5281-3241
ORIENTAL MOTOR Co., Ltd.
□28mm PK523PA(B)
PK525PA(B)
Factory Setting
( ) : Both axes
● Please contact us if you want to use the motor other than the above to our office.
Setting
Current
DRIVE I.SEL
(A/phase)
switch No.
0.35 E
Setting
Current
DRIVE I.SEL
(A/phase)
switch No.
0.35 E
0.35 E
E
-43-
Setting Setting RM SEL
MOTOR SEL
switch
switch
4 3
OFF OFF OFF
Setting Setting RM SEL
MOTOR SEL
switch
switch
4 3
OFF OFF OFF OFF
OFF OFF OFF
OFF OFF OFF OFF OFF
GDB-5KS20
Instructions Manual
Torque Data
Fig. No.
2 1
OFF ON Fig.1
Torque Data
Fig. No.
2 1
ON Fig.2
ON Fig.3
－
