４－４．Setting DRIVE CURRENT SELECT switch
(1) Set the switch No. to the setting specified in the table "10-4. Applicable Motors."
●Relationship between the DRIVE I.SEL switch No. and DRIVE CURRENT.
DRIVE I.SEL
No.
A high setting value may cause burn on the
skin due to overheating of the motor.
Do not select a high value beyond the
required.
DRIVE CURRENT is set up with the DRIVE I.SEL switch.
A/phase
０ 0.150
１ 0.163
２ 0.175
３ 0.188
４ 0.200
５ 0.213
６ 0.225
７ 0.238
８ 0.250
９ 0.263
Ａ 0.275
Ｂ 0.288
Ｃ 0.300
Ｄ 0.325
Ｅ 0.350
(Factory setting）
Ｆ 0.375
CAUTION
