４－７．Setting ROTATE MODE SELECT switch
(1) Turn power [OFF].
(2) Set the switch to the setting specified in the table "10-4. Applicable Motors."
R4
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
ON
ON
ON
ON
ON
ON
ON
ON
Erroneous setting may cause breakage of
the machine or injury due to unexpected
rotation of motor.
Ensure correct setting.
ROTATE MODE is set up with the RM SEL switch.
Set this switch with power OFF.
RM SEL switch
R3
R2
R1
OFF
OFF
OFF
OFF
OFF
ON
OFF
ON
OFF
OFF
ON
ON
ON
OFF
OFF
ON
OFF
ON
ON
ON
OFF
ON
ON
ON
OFF
OFF
OFF
OFF
OFF
ON
OFF
ON
OFF
OFF
ON
ON
ON
OFF
OFF
ON
OFF
ON
ON
ON
OFF
ON
ON
ON
-21-
CAUTION
(Factory setting)
Sub adjustment(Not available)
GDB-5KS20
Instructions Manual
