Melec GDB-5KS20 Instruction Manual page 28

〔Motor output Connector〕
Leads of the motor
MOTOR
Leads of the motor
MOTOR
●The color indications for the motor crimping J3 represent color of the leads of
the motor.
●Use a cable of 5m or less for the motor cable.
<wiring> <Crimping>
2
(0.3mm or more，5m Max)
Violet/Blue
Red/Gray
Black/Yellow
White/Orange
Green/Brown
<wiring> <Crimping>
(0.3mm 2 or more，5m Max)
Black
Green
Orange
Red
Blue
-28-
Instructions Manual
<Connection>
<Insertion> Housing
Contact
for J3
1
2
3
4
5
<Connection>
<Insertion> Housing
Contact
for J3
1
2
3
4
5
GDB-5KS20
DRIVER
J3
VIO
1 BLK
BLU
RED
2 GRN
GRY
BLK
3 ORN
YLW
WHT
4 RED
ORN
GRN
5 BLU
BRN
DRIVER
J3
VIO
1 BLK
BLU
RED
2 GRN
GRY
BLK
3 ORN
YLW
WHT
4 RED
ORN
GRN
5 BLU
BRN
