Summary of Contents for Proline TCG4
- Page 1 PROline Model TCG4 BUILT-IN GAS HOB INSTRUCTION BOOK...
- Page 2 Operating and Installation Instructions...
- Page 3 Index Introduction Technical data and specifications ..3 Important notes and precautions for use Installation ..... . 3-6 Dear User, Ventilation.
- Page 4 Technical data Installation GAS BURNERS CHARACTERISTICS Burner Injector Consumption low flow-rate nominal flow-rate (kW) (kW) auxiliary 95 l/h 0,45 1,00 semi-rapid 157 l/h 0,60 1,65 mbar rapid 276 l/h 0,95 2,90 G30/G31 auxiliary 73 g/h 0,45 1,00 28-30 mbar semi-rapid 120 g/h 0,60 1,65...
- Page 5 Installation 4'x7'x7'6" high). If it is installed in a room of vol- is essential to install a heat baffle between the ume between 6m3 and 9m3 an air vent of effec- bottom of the hob and the underlying unit. tive areas 65m2 is required. If it is installed in a •...
- Page 6 Installation Natural Gas is 20 mbar (8 inch W.G.). down. The hob may be equipped with type A taps, with by-pass inside (accessed by inserting Installation to LP Gas a small screwdriver into the rod) or type B taps, This appliance must only be connected to LPG with by-pass on the outside on the right (ac- after an LPG conversion kit has been fitted (see cessed directly).
- Page 7 Installation For the user Important HOW TO USE THE HOB The wires in the mains lead on this appliance are coloured in accordance with the following code: VENTILATION Green and Yellow - Earth All gas cooking appliances produce heat and Blue –...
- Page 8 5425425. INFORMATION AND SERVICE For any information you require about the product contact the Proline helpline on 0113 2793520 If you require a service call contact your nearest Comet Service Centre on 0870 5425425. The manufacturer declines all responsability for injury or damage deriving from poor installation or incorrect use of the hob.
- Page 9 Figure A = AUXILIARY SR = SEMIRAPID R = RAPID...
- Page 10 Figure...
- Page 12 ED. 06/03/2003 334995...
