- Page 1 Dock Bundle Quick Installation Guide クイック設置ガイド 빠른 설치 가이드 Schnellinstallationsanleitung Guía de instalación rápida Guide d’installation rapide Guida rapida all’installazione Beknopte installatiehandleiding Guia de instalação rápida Guia de Instalação Rápida Краткое руководство v1.0...
-
Page 2: Read Before Use
UPS power supply. The dock weighs 105 kg and occupies less than 1 m , which supports quick installation and configuration. With the M30 Series Dock Version aircraft, DJI FlightHub 2 can be used to perform automated operations remotely. - Page 3 Unpacking and Inspecting the Dock Manually Opening the Dock Cover • DO NOT apply force or place heavy objects on the electrical cabinet door after opening. • DO NOT apply force on the side of the dock covers in order to avoid any damage when opening or closing.
- Page 4 Dock Installation Confirming the Installation Orientation Make sure to consider the below factors before installing the dock: • If there is frequently ocurring strong wind in one direction at the installation site, make sure to avoid the wind speed gauge module being located downwind, so as to prevent the aircraft from taking off and landing too close to the wind speed gauge module in a windy environment.
- Page 5 2. Carefully lift the dock at the parts indicated in gray marked with arrows in the diagram. Move the dock to the installation location, align the four mounting base bracket holes with the expansion bolts, and then put it down slowly. It is recommended that at least four people carry it. 3.
- Page 6 Connecting the Dock The electrical connection is to connect the external cables to the electrical cabinet for dock grounding, power supply and Ethernet connection. 1. After opening the door of the electrical cabinet, use a 3 mm hex key to loosen the four screws and remove the electrical cabinet plate.
- Page 7 1. Lead the pre-embedded power cable through the cable hole at the bottom of the electrical cabinet and reserve the proper length for connection. 2. Use the diagonal cutting pliers to remove about 70 mm of the cable insulation layer and then use the wire strippers to remove about 8 mm of the wire insulation layer.
- Page 8 Powering on the Dock Before Powering On Checklist Checklist Description Earth Wire The two ends of the earth wire are properly connected, and the screws are securely tightened. Power Cable The protective earth wire, neutral wire, and live wire are securely connected and the wire sequence is correct.
-
Page 9: Preparing The Aircraft
Getting the Device Binding Code 1. Use a computer to visit https://fh.dji.com, and log in to DJI FlightHub 2 using a DJI account. Click to create an organization, fill in the organization information, and click the created organization name to enter the organization page. - Page 10 1. Use the USB-C cable included to connect the USB-C port of the remote controller to the USB-A port of the dock electrical cabinet. 2. Power on the remote controller, run DJI Pilot 2, and follow the prompts to complete the activation and configuration for the dock and the aircraft.
-
Page 11: Automatic Operation Test
To ensure that the dock and aircraft are properly functioning, make sure to create a flight route and plan a flight task in DJI FlightHub 2, and then launch the flight task to allow the dock to perform the automatic operation test after completing the dock configuration in the app. - Page 12 The rain gauge surface is clear of dirt or foreign objects. Check the rain gauge data displayed in DJI FlightHub 2 by gently tapping the top of the rain gauge. The sealant completely covers the holes and seals the cables completely.
- Page 13 Appendix Status Indicators The status indicators on the dock covers are used to display the current dock working status. Normal States Blinks white The dock is working normally and the aircraft is ready to take off. Blinks blue The dock and the aircraft are linking, and the buzzer emits a short beep. Blinks green The aircraft has taken off from the dock and is performing a flight task.
