Safety Precautions
At least two people are required to safely mount the system in the rack.
All servers and systems in the rack should be planned with the same air ow
direction.
All FRU components must have the same air ow direction. A mismatch in the air ow
will a ect the heat dissipation.
The part of the system to which you choose to attach the rails will determine the
system's adjustable side. The system's part to which the brackets are attached will
be adjacent to the cabinet.
The FRU side is extractable. Mounting the rack brackets inverted to the FRU side will
allow you to slide the FRUs, in and out.
System Package Contents
1 x System
1 x Rail kit for 23.6-31.5" [600-BOOmm) racks
2 x Power cables - Type C13 -C14
1 x Harness: RS232 2M cable - RJ-45 to 089
1 x RJ to RJ Cable
Quantity
X1
X2
X1
SN2201 1U Ethernet Switch Systems Quick Installation Guide
Item
2
