  • Page 1 User guide Tywell Thermostat or smart thermostat Bioclimatic manager...
  • Page 2 User instructions Tywell www.deltadore.com The Tywell has different use cases depending on the installation. Identify your use case (1, 2, 3 or 4) from the information displayed on its home screen, then refer to the relevant paragraph in this manual.

  • Page 3: Table Of Contents

    Function of the Tywell Control ........

  • Page 4: Description

    1. Description 1.1 Tywell Control environment Tywell Control, combined with a thermal receiver, controls the heating and air conditioning (depending on the installation) of a zone in the home. The smart version is linked to a Tydom smart home hub.

  • Page 5: Function Of The Tywell Control

    2. Function of the Tywell Control 2.1 Selecting the operating mode Choose the operating mode for your installation: Off / Heating / Air conditioning Tywell Control displays the menus available for your installation. Tywell Control Heating Heating Temperatures Air conditionning Air conditionning : Measuring the humidity level in the air.

  • Page 6: Setting The Temperatures Of The Zone

    2.3 Setting the temperatures of the zone Set the desired temperatures for the different operating periods. These temperatures will be automatically applied when the installation changes mode: Heating when present / Heating at night / Heating when absent (short-term) 2. AM, PM and wknd Temperatures Heating while present Week...

  • Page 7: System Settings

    2.4 System settings Download the user instructions Scan the QR Code to access the information page dedicated to Tywell. Tywell Control Se ings User manual Scan this code to download User manual the user manual. Control with a smartphone Mode...

  • Page 8: Heating Control

    3. Heating control 3.1 Heating: changing the current set-point temperature You can change the current set-point temperature at any time. Press the + or - button: Current setpoint temperature New set-point temperature Adjust the temperature Adjust the temperature Setpoint Cancel Confirm Cancel Confirm...

  • Page 9: Standby Screen

    4. Standby screen The standby screen is activated automatically when no buttons are pressed: - after 1 minute 30 secs from the home screen, - after 6 minutes from the settings screens. In standby mode, only the room temperature will be displayed. Press any key to exit standby mode: Display in standby Receipt of data...

  • Page 10: Troubleshooting

    ❸ Place Tywell Control back on its base. Click 3 x 1,5V - AAA LR03 Tywell Control is powered by 3 x 1.5V - AAA LR03 batteries Do not use rechargeable or lithium batteries. 6.2 Errors Tywell Control sensor error Display in the event of a Tywell Control sensor error.

  • Page 11: Troubleshooting (Rf 6700 Fp And Rf 6050+ Receiver)

    6.3 Troubleshooting (RF 6700 FP and RF 6050+ receiver) This Troubleshooting paragraph should be consulted if your Tywell Control is paired with an RF 6700 FP or RF 6050+ receiver. What the receiver LEDs mean Signal type Diagnosis/Solutions The green light is constantly on Power supply is on.
  • Page 12 Indicator light off mode (RF 6700FP only) This section should be consulted if your Tywell Control is paired with the RF 6700 FP receiver. When the function for switching off the LEDs is active: - When powering up (or restoring power), the LEDs are active.

  • Page 13: Description

    Use cases ❸ and ❹ 7. Description 7.1 Tywell Control environment The Tywell Control operates devices, optimises energy use and makes spaces more comfortable in the home. - Centralised control of shutters (by zone or all, depending on configuration in the application).

  • Page 14: Tywell Control Presentation

    ⑭- Confirm ⑱- Settings buttons System information icons: Battery error Wireless error Open window Outdoor temperature measured by the outdoor sensor. Weather service Some menus will only appear if the Tywell Control controls the thermal management (heating and/or air conditioning).

  • Page 15: Function Of The Tywell Control

    8. Function of the Tywell Control 8.1 Selecting the operating mode (use case 3) Choose the operating mode for your installation: Off / Heating / Air conditioning Tywell Control displays the menus available for your installation. Tywell Control Heating Heating...
  • Page 16 Example of a preset programme: AM, PM and wknd Week Present Night Weekend Absent Select You can also create a personalised programme for each day of the week using the Tydom application. In this case, select "Custom programming". If you don't want any programming, select "Custom programming", with no further action required on the Tydom App.

  • Page 17: Setting Zone Temperatures (Use Case 3)

    The Frost Protection set-point setting (absence mode ) is available depending on the version of your Tywell Control and the type of paired receiver. You can activate Absence mode from the Tywell Control interface or the Tydom application (see Absence mode section).

  • Page 18: Shutter Autopilot

    For optimum shutter autopilot results, a Tysense Sun sensor and a Tysense Thermo outdoor temperature sensor are recommended. If the sensors are replaced by "weather service data" from the Tydom app, the Tywell hub must be connected to the internet.
  • Page 19 2 hours. You can activate and deactivate this function directly Ex : 07h00 Ex : 20h30 from Tywell Control. Ouverture Fermeture automatique automatique You can set a limit for opening...
  • Page 20 Activate shutter autopilot Activate automatic opening and heat protection from the application or via the Tywell Control. With the Tywell Control With the Tydom application Tywell Control Mode Programme Temperatures Shu er Tywell Control Shu er autopilot Automatic opening Heat protection...

  • Page 21: System Settings

    8.5 System settings Download the user instructions Scan the QR Code to access the information page dedicated to Tywell. Tywell Control Se ings User manual Scan this code to download User manual the user manual. Control with a smartphone Mode...

  • Page 22: Shutter Management

    The shutters in the zone are closed. ① Press the Up button. ② Tywell Control tells you that the action has been initiated. All shutters start moving. (You can choose to exclude certain shutters controlled using the Tydom application). ③ You have the option of stopping the shutters from raising by pressing the  button.

  • Page 23: Heating Control

    10. Heating control 10.1 Heating: changing the current set-point temperature You can change the current set-point temperature at any time. Press the key to change the setting: Current setpoint temperature New set-point temperature Adjust the temperature Adjust the temperature Setpoint Cancel Confirm Cancel...

  • Page 24: Absence Mode

    During your absence (long-term), this mode sets all the zones in your home to "Frost Protection" (Frost Protection set-point adjustable depending on devices). In this mode, the thermal programming of the Tywell Control and the Tydom application is no longer taken into account. Tywell Control settings and heating and/or air conditioning controls are no longer available. Automatic opening and heat protection can be configured from the App to determine whether or not they are inactive while in Absence mode, while manual control remains possible.

  • Page 25: Standby Screen

    For installations with heating/air conditioning control (use case 3), it displays: - the outdoor temperature. - the ambient temperature. If Tywell Control only controls shutters (use case 4), the standby screen displays: - the outdoor temperature. - The "Roller shutter" symbol...

  • Page 26: Notifications

    You are informed by a notification displayed on the screen when an autopilot-related action is in progress on your installation. There's no need to validate a notification, Tywell Control confirms that the action has been carried out after one minute.

  • Page 27: Troubleshooting

    ❶ Unclip Tywell Control. ❷ Replace the batteries. ❸ Place Tywell Control back on its base. Click 3 x 1,5V - AAA LR03 Tywell Control is powered by 3 x 1.5V - AAA LR03 batteries Do not use rechargeable or lithium batteries.

  • Page 28: Errors

    Using the Tydom application, check that the weather service is activated or that an outdoor temperature sensor is paired. Tywell Control sensor error Display in the event of a Tywell Control sensor error. Consult your installer. Wireless communication error Display in the event of a wireless communication error.

  • Page 29: Troubleshooting (Rf 6700 Fp And Rf 6050+ Receiver)

    14.3 Troubleshooting (RF 6700 FP and RF 6050+ receiver) This Troubleshooting paragraph should be consulted if your Tywell Control is paired with an RF 6700 FP or RF 6050+ receiver. What the receiver LEDs mean Signal type Diagnosis/Solutions The green light is constantly on Power supply is on.
  • Page 30 Indicator light off mode (RF 6700FP only) This section should be consulted if your Tywell Control is paired with the RF 6700 FP receiver. When the function for switching off the LEDs is active: - When powering up (or restoring power), the LEDs are active.
