Summary of Contents for DELTA DORE Pack TYBOX 5000
- Page 1 Pack TYBOX 5000 Installation instructions...
-
Page 2: Table Of Contents
Composition Content Your PACK comprises: 1/ Location........................4 - 1 TYBOX 5000 connected room unit 2/ Connection ......................5 - 1 TYDOM Home and its connector 2.1 Circulator control ....................5 2.2 Control of the thermostat input of the boiler or heat pump (HP) no-reversible ................5 CHAUFFAGE 3/ Mounting ....................... -
Page 3: 1/ Location
1/ Location 2/ Connection Since the temperature measurement sensor is inside the box, you must install the The diagrams provided are simplified for greater clarity. Protections and other thermostat flush-mounting box: accessories required by standards are not illustrated. - Standard NF C15-100 - on an accessible wall at a height of 1.50 m and good practice must be complied with. -
Page 4: 3/ Mounting
2/ Connection 3/ Mounting ❶ Remove the terminal, on the back of the device, using a screwdriver. ❶ Remove the thermostat cover by pushing the pin using a screwdriver. ❷ Connect the terminal to the control wire (circulator, boiler or heat pump ❷... -
Page 5: 4/ Installation
4/ Installation 4.1 TYDOM Home 4.2 Associate the TYDOM application with the Connected TYBOX 5000 connecté 4.1.1 Box contents A. Tydom Home Go to the «Settings» page of your installation, select «Add a device», then B. Ethernet cable follow the instructions. C. Mains supply D. Important Product Information 4.1.2 Description E. -
Page 6: 5/ Configuration
5/ Configuration CF05 - Type of temperature displayed in AUTO mode This menu is used to determine all the settings adapted to your installation. Temperature setting display (default selection) ❶To enter configuration mode, press the MODE button for 10 seconds until the screen displays CF01. Display of the measured room temperature. ❷Press + or - to set. -
Page 7: 6/ Troubleshooting
5/ Configuration 6/ Troubleshooting CF09 - Reversal of relay direction 6.1 Signals and possible faults on the wireless room thermostat TYBOX 5000 The relay contact is normally open. It closes during a heating request. You can reverse the direction of operation. • When you press a button, the screen displays: ____ Normally open (default selection) Access to the settings is locked. -
Page 8: Signals And Possible Faults On The Tydom Home
6/ Troubleshooting Reset to factory settings 6.2 Signals and possible faults on the TYDOM Home Press the button for 30 seconds until the LED stops flashing. Release. System status - DHCP mode System accessible locally and remotely, user connected Flashing white System status - Clear product associations System accessible locally and remotely Steady white System accessible locally, user connected Flashing orange... -
Page 9: 7/ Technical Characteristics
7/ Technical characteristics Wireless room thermostat TYBOX 5000 • Contact output 2A (230V) • Ball test: 125 ° C • Rated surge voltage: 4000V • Powered by 2 lithium batteries 1.5 V, LR03/AAA (supplied) • Class III insulation • Radio frequency 868.7 MHz to 869.2 MHz •... - Page 10 www.deltadore.com...
